It also does not apply if the serial nameplate has been removed or unauthorized service personnel perform service. The prices charged by Bloomfield Industries for its products are based upon the limitations in this warranty. obligation under this warranty is limited to the repair of defects without charge by a Bloomfield Industries Authorized Service Agency or one of its sub-agencies.
SERVICING INSTRUCTIONS Deliming Instructions EXPLODED VIEW & PARTS LIST WIRING DIAGRAMS MODEL STYLE AUTOMATIC 0420 LO-PROFILE AIRPOT Also meets Canadian Standards This manual applies to the following Bloomfield Industries product: 0420 SPECIFICATIONS FEATURES VOLTS WATTS WATER 120 VAC 1500 DISPENSER APPLICABILITY Thank You for purchasing this Bloomfield Industries appliance.
PRECAUTIONS AND GENERAL INFORMATION WARNING: ELECTRIC SHOCK HAZARD All servicing requiring access to non-insulated components must be performed by qualified service personnel. Do not open any access panels which require the use of tools. Failure to heed this warning can result in electrical shock. WARNING: INJURY HAZARD All installation procedures must be performed by qualified personnel with full knowledge of all...
INSTALLATION READ THIS CAREFULLY BEFORE STARTING THE INSTALLATION IMPORTANT: To enable the installer to make a quality installation and to minimize installation time, the following suggestions and tests should be done before the actual unit installation is started: CAUTION: ELECTRICAL DAMAGE DO NOT plug in or energize this appliance until all Installation...
NOTE: Water supply inlet line must meet certain minimum criteria to insure successful operation of the brewer. Bloomfield recommends 1/4" copper tubing for installation of less than 12 feet and 3/8" for more than 12 feet from a 1/2" water supply line.
Page 8
INSTALLATION (continued) WARNING: SHOCK HAZARD Brewer must be properly grounded to prevent possible shock hazard. DO NOT assume a plumbing line will provide such a ground. Electrical shock will cause death or serious injury. IMPORTANT: Supply power must match nameplate for voltage and phase.
Fig. 4 Water Flow Diagram A. START-UP For initial start-up, or if the brewer has not been used for an extended period of time: ♦ Be sure spray disk and brew gasket are properly installed in the brew head. ♦ Be sure the water supply is properly connected and the water supply valve is turned before connecting brewer to electric power.
OPERATION (continued) B. PROGRAM BREW VOLUMES 1. Place an empty airpot under the brew head. Install the brew 2. Press and hold BREW key until beep sounds and the indicator 3. Press and release the VOLUME SELECT KEY to be programmed. Fig.
A. PREPARATION Place one (1) genuine Bloomfield paper filter in the brew chamber. Add a pre-measured amount of fresh coffee grounds. Gently shake the brew chamber to level the bed of grounds. Slide the brew chamber into place under the brew head.
CLEANING INSTRUCTIONS CAUTION: BURN HAZARD Brewing and serving temperatures of coffee are extremely hot. Hot coffee will cause serious skin burns. CAUTION: SHOCK HAZARD Do not submerge or immerse brewer in water. IMPORTANT: DO NOT use steel wool, sharp objects, or caustic, abrasive or chlorinated cleansers to clean the brewer or airpots.
Examine wiring & connectors, controller, water level probe and heating element Repair/replace as needed Program volume keys Use one (1) genuine Bloomfield filter per brew Thoroughly clean brew chamber Use correct grind and amount of coffee Program vol. key for pulse brew...
SERVICING INSTRUCTIONS CAUTION: SHOCK HAZARD Opening access panels on this brew may expose uninsulated electrical components. Disconnect brewer from electrical power before removing any panel. Trouble shooting instructions, component views and parts lists in this manual are included for general reference, and are intended for use by qualified service personnel only.
TEMPERATURE ADJUSTMENT Disconnect brewer from electric power. Remove top panel. Remove button plug from front panel. Pull vent tube out of tank lid and insert a thermometer of known accuracy in hole. Reconnect brewer to electrical power. Place empty container under brew chamber. Energize brewer and allow unit to heat.
Page 16
SERVICING INSTRUCTIONS (continued) IMPORTANT: Before setting assembly into tank, make sure tank lid gasket is properly seated on flange of lid. DO NOT OVER-TIGHTEN. IMPORTANT: When mounting thermostat, be sure to insert sensing bulb to the bottom of the bulb well. Tighten capillary lock nut only enough to ensure no water leakage.
REPLACE SOLENOID Symptom: Brewer will not flow water; or, brewer drips continuously from brew head. NOTE: Wrench p/n 86660 is designed to allow easy removal of flare nuts from the water inlet fitting IMPORTANT: Shut-off water to brewer and disconnect brewer from electric power before removing hoses or wiring.
Page 18
SERVICING INSTRUCTIONS (continued) IMPORTANT: The two keypad ribbon cables connectors are not polarize, and can easily be installed on the wrong location on the board. Be sure to mark the ribbon cable connectors s as to location and orientation. REPLACE CONTROLLER Disconnect brewer from electric power.
NOTE: Repeat steps 4 thru 5 as required to remove all scale and lime build-up. NOTE: Normally, silicone hoses do not need to be delimed. Should deliming hoses become necessary, Bloomfield recommends replacing the hoses.
Page 24
Bloomfield Industries proudly supports CFESA Commercial Food Equipment Service Association Bloomfield Industries, Inc. Division of Carrier Commercial Refrigeration In US and Canada Telephone: 775-689-5700 Fax: 888-492-2783 Fax: 800-356-5142 ( for orders only website: www.wellsbloomfield.com PRINTED IN CHINA...
