Page 2 This manual is intended for use by qualified service personnel. The technical content of this manual represents Bloomfield coffee brewers are intended exclusively for commercial use current production models and are designed expressly to brew beverage products for human as of October, 2003.
Page 3: Table Of Contents
TABLE OF CONTENTS INSTALLATION PROCEDURES …………………………………….. BREWER OVERALL CHECKOUT ……………………………………. 4 BREWING COFFEE …………………………………………………… 5 CLEANING INSTRUCTIONS …………………………………………. THEORY OF OPERATION WATER FLOW ………………………………………...………….… 7 HOT WATER FAUCET …………………………………………….. BREW WATER TEMPERATURE CONTROL …………………… 9 TROUBLESHOOTING GUIDE QUICK GUIDE ………………………………………………………. 10 BREW WATER SYSTEM - AUTOMATIC OPERATION ...……...
Page 4 NOTE: Water supply inlet line must meet certain minimum criteria to insure successful operation of the brewer. Bloomfield recommends 1/4" copper tubing for installation of less than 12 feet and 3/8" for more than 12 feet from a 1/2" water supply line.
Page 5: Installation Procedures
NSF requires that the brewer be able to be moved for cleaning underneath. A flex line or loops of copper tubing will satisfy this requirement. See Figure 2 below. In some areas, local codes require a backflow preventer (check valve) to be installed on the inlet water line. If a backflow preventer is used, you must install a water hammer arrester in the incoming line, between the backflow preventer and the brewer inlet, as far away from the brewer as space will allow.
Page 6: Brewer Overall Checkout
BREWER OVERALL CHECK-OUT CAUTION: SHOCK HAZARD Always disconnect the brewer fro electrical power before servicing or cleaning. CAUTION: BURN HAZARD Brew water is extremely hot. Exposed surfaces of the brew chamber and airpot ,decanter or thermal server may be HOT to the touch, and can cause serious burns.
Page 7: Brewing Coffee
PREPARATION Place one (1) genuine Bloomfield paper filter in the brew chamber. Add a pre-measured amount of fresh coffee grounds. Gently shake the brew chamber to level the bed of grounds. Slide the brew chamber into place under the brew head.
Page 8: Cleaning Instructions
CLEANING INSTRUCTIONS CAUTION: BURN HAZARD Brewing and serving temperatures of coffee are extremely hot. Hot coffee will cause serious skin burns. CAUTION: SHOCK HAZARD Do not submerge or immerse brewer in water. IMPORTANT: DO NOT use steel wool, sharp objects, or caustic, abrasive or chlorinated cleansers to clean the brewer or airpots.
Page 9: Theory Of Operation
THEORY OF OPERATION WATER FLOW Typical Brew Water Delivery System POUR-OVER FEATURE Pouring any amount of cold water into the pour-over opening and into the basin pan forces an identical amount of hot water out of the tank and through the spray head into the brew chamber.
Page 10: Hot Water Faucet
THEORY OF OPERATION (continued) HOT WATER FAUCET Typical Hot Water Faucet System The faucet water coil is submerged in the hot water tank and draws heat from the brew water. Faucet water flows through the bypass side of the water inlet and is not controlled by the solenoid valve. The faucet is at supply water pressure any time the faucet shut-off valve is OPEN.
Page 11: Brew Water Temperature Control
THEORY OF OPERATION (continued) The heating elements are energized when line power is applied to the element terminals. Water temperature is sensed by a thermobulb inserted into the water tank. This temperature signal is fed to the thermost Heat Control Diagram...
Page 12: Troubleshooting Guide Quick Guide
TROUBLESHOOTING GUIDE QUICK GUIDE The first step in troubleshooting is to determine where to start. A few simple checks should quickly point to the major area of concern. STEM PAGE...
Page 13: Brew Water System - Automatic Operation
TROUBLESHOOTING GUIDE (continued) BREW WATER SYSTEM - AUTOMATIC OPERATION...
Page 14: Brew Water System - Pour-Over
TROUBLESHOOTING GUIDE (continued) BREW WATER SYSTEM - AUTOMATIC OPERATION...
Page 16 TROUBLESHOOTING GUIDE (continued) BREW WATER SYSTEM - AUTOMATIC OR POUR-OVER OPERATION...
Page 17: Faucet Water System
TROUBLESHOOTING GUIDE (continued) BREW WATER SYSTEM - POUR-OVER OPERATION...
Page 18 TROUBLESHOOTING GUIDE (continued) FAUCET WATER SYSTEM...
Page 19 TROUBLESHOOTING GUIDE (continued) FAUCET WATER SYSTEM...
Page 20 TROUBLESHOOTING GUIDE (continued) FAUCET WATER SYSTEM...
Page 21: Electrical System - Brew
ELECTRICAL SYSTEM - BREW TROUBLESHOOTING GUIDE (continued) Exposed electric circuits. Use due caution when working near live electric circuits. CAUTION: ELECTRIC SHOCK HAZARD...
Page 22: Electrical System - Heating
TROUBLESHOOTING GUIDE (continued) ELECTRICAL SYSTEM - HEATING CAUTION: ELECTRIC SHOCK HAZARD Exposed electric circuits. Use due caution when working near live electric circuits.
Page 23: Electrical System - Warmers
TROUBLESHOOTING GUIDE (continued) CAUTION: ELECTRIC SHOCK...
Page 24: Servicing Instructions Temperature Adjustment
SERVICING INSTRUCTIONS CAUTION Electric Shock Hazard These procedures involve exposed electrical circuits. These procedures are to be performed by qualified technical personnel only. NOTE: Optimum brewing temperature range is 195ºF to 205ºF (90ºC to 96ºC). IMPORTANT: A mechanical thermostat will maintain temperature within ±5ºF.
Page 25: Timer Adjustment
TIMER ADJUSTMENT The amount of water dispensed automatically during a brew cycle is controlled by the timer. Place empty decanter under brew chamber. Press BREW button. Brewer should dispense one decanter of water. To adjust amount: Remove brew chamber and button plug. Adjust knob on timer; clockwise increases time.
Page 26: Replace Fill Solenoid
SERVICING INSTRUCTIONS (continued)
Page 27: Replace Timer Assembly
REPLACE TIMER ASSEMBLY Unplug power cord or turn circuit breaker OFF. Remove front panel. Remove knob and three screws holding timer to bracket. Disconnect wiring to timer. Reassemble in reverse order. Adjust timer as described on page 13 REPLACE HOT WATER FAUCET COIL Symptom: Brewer drips continuously from brew head, except when faucet valve is turned OFF.
Page 28: Delime Water Tank
CAUTION - CHEMICAL BURN HAZARD Deliming chemicals are caustic. Wear appropriate protective gloves and goggles during this procedure. Never siphon deliming chemicals or solutions by mouth. This operation should only be performed by qualified and ex- perienced service personnel. IMPORTANT: DO NOT spill, splash or pour water or deliming solution into or over any internal component other than the inside...
Page 29 Run at least three full brew cycles and discard all water generated. 12. Brewer is ready to use. SERVICING INSTRUCTIONS (continued) NOTE: Normally, silicone hoses do not need to be delimed. Should deliming hoses become necessary, Bloomfield recommends replacing the hoses.
Page 30 Bloomfield Industries proudly supports CFESA Bloomfield Industries, Inc. Division of Carrier Commercial Refrigeration In US and Canada Telephone: 775-689-5700 Fax: 888-492-2783 Fax: 800-356-5142 ( for orders only website: www.wellsbloomfield.com...
