GEN2 Universal / GEN2 Printer – Reference Points for Procedures
Presenter Rollers
Ticket Taken Sensor
GEN3 Evolution Printer – Reference Points for Procedures
Ticket Taken Sensor
Printer Open Sensor
ã 2010 – 2012 FutureLogic, Incorporated. All Rights Reserved.
(GEN2™, GEN2 Universal™, and GEN3 Evolution® Printers)
Pinch Roller
Platen Roller
Print Head
Main Release Lever
Pinch Roller
Platen Roller
Print Head
Main Release Lever
Printer Cleaning Guide
Printer Open Sensor
Presenter Rollers
