- Page 1 LT -VOZ-W PORTABLE WAISTBAND AMPLIFIER INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Front And Side Panels
DESCRIPTION Ultralight portable waistband amplifier with wireless hands-free microphone headset. Approximately 70 m range in favourable conditions. Specially suitable for amplifying the voice in presentations, guided tours, sporting activities, teaching, etc. This model incorporates a USB/microSD/MP3 player/recorder. With tactile controls on the front panel of the device. -
Page 5: Wireless Microphone
3.- 12: in playback mode, plays/pauses the track. In recording mode, starts/pauses recording. 4.- M: allows the different operating modes to be changed: microphone, MicroSD card, USB memory device and recording. LED operating indicators. 6.- Speaker. 7.- USB PLAYER: USB storage device connection port. WIRELESS MICROPHONE 1.- DC 5V: 5 V DC 1 A power supply input. -
Page 6: Led Indicator Status
WIRELESS MICROPHONE SYNCHRONIZATION The process of synchronization between the wireless microphone and the amplifier is simple. - With the amplifier switched off and everything disconnected (wired microphone, MicroSD card and USB storage device), switch the wireless microphone on and press and hold the PAIR until the blue microphone LED starts to flash. -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS ALTA-VOZ-W CHARACTERISTICS Portable waistband amplifier. UHF wireless microphone. USB/microSD/MP3 recorder/player. Recording 128 Kbps. Up to 35 m between microphone and amplifier. Battery life: 9 hours volume midway. Long range. Ultralight. Soft touch and non-slip. POWER 18 W maximum... -
Page 8: Declaration Of Conformity
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
