User Manual
Swing Barrier SBTL5000 series
Applicable Models: SBTL5000/5200, 5011/5211, 5022/5222
Version: 1.1
Date: August 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBTL5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZKTeco SBTL5000 Series

  • Page 1 User Manual Swing Barrier SBTL5000 series Applicable Models: SBTL5000/5200, 5011/5211, 5022/5222 Version: 1.1 Date: August 2019...
  • Page 2: Table Of Contents

    Content 1. Product Introduction ................................1 1.1 Model number and access control ........................1 1.2 Chassis design and dimensions ..........................1 1.3 Mechanical system of the swing barrier......................2 1.4 Electronic control system ............................2 1.5 The working principle of swing barrier ......................2 1.6 System composition of the product ........................
  • Page 3: Product Introduction

    √ 1.2 Chassis design and dimensions SBTL5000 series is with SUS304 housing, provides simple and beautiful design with anti-corrosion. It provides legal access to the persons while eliminating illegal personnel access. In case of emergency, it ensures that evacuation passage runs smoothly and is convenient for personnel.
  • Page 4: Mechanical System Of The Swing Barrier

    And then, the reader sends signals to the access controller to request permission to pass through the lane. The access controller will send the signal to the master control panel. SBTL5000 series User Manual P a g e...
  • Page 5: System Composition Of The Product

    Including normal working mode, normally open and normally close mode, testing mode. After powered on, the LCD screen on control board will display a default state, which displays currently work mode. SBTL5000 series User Manual P a g e...
  • Page 6: Specification

    1.7 Specification Dimension(mm) SBTL5000 Series : L=1400, W=180, H=1000 Communication RS485 Input voltage AC100~240V, 50-60Hz Switching Input control signal Output voltage DC 24V signal Time of 0.8S(adjustabl Relative 20%-95%(Non-condensing) opening/closing humidity -28℃-60℃ Temperature Passage rate Maximum 30/minute Working Infrared sensor...
  • Page 7: Installation Position Of The Swing Barrier

    The reference figure as below: Figure 2-2 SBTL5000 series dual-lane 2.3 Cables installation and fixing For the outlets of the concealed cables, please refer to the drawing showing the mounting holes. The input voltage for this swing barrier turnstile is AC100-120V/200-240V and its master and slave are connected by a 5-core cable (signal) and a 2-core cable (power).
  • Page 8 OK, tighten the screws. It is recommended that a warning line be marked out on the ground after the machine is installed, so as to prompt the pedestrian to stand behind the warning line when swiping the card. As shown in Figure 2-3b: Figure 2-3b SBTL5000 series User Manual P a g e...
  • Page 9: Menu Introduction

    UP or DOWN to choose a menu item and then press ENT to enter the interface and adjust function or value. 3.2 Menu introduction 1. Barrier positioning Zero position (Default). SBTL5000 series User Manual P a g e...
  • Page 10 5. Speed of barrier closing and opening Low speed. Middle speed (Default). High speed. 6. Anti-tailgate Alarm disabled. Voice alarm (Default). Close door and voice alarm. 7. Reset counter Exit counter (Default). Entry counter. Both. SBTL5000 series User Manual P a g e...
  • Page 11 1~16 (The default is 5). 14. Exchange voice of door opening No (Default). Yes. 15. IR anti-pinch setting Disable. Stop turning for anti-pinch (Default). Open the barrier for anti-pinch. 16. Memory function Disable (Default). Enable. SBTL5000 series User Manual P a g e...
  • Page 12 19. Slave device speed compensation 0~20 (The default is 0). 20. Swiping card mode Allow to swipe card in passage (Default). Not allow to swipe card in passage. 21. Version V6.0.3. | 10 SBTL5000 series User Manual P a g e...
  • Page 13: Functions Introduction Of Wiring And Terminal

    Access control power supply: Supplies power for the access board. RS485 communication port: Receiving external signals. Master/slave terminal: It is connected to the master and slave boards to transfer signals. | 11 SBTL5000 series User Manual P a g e...
  • Page 14: Troubleshooting

    When power on, the swing arm can’t Ensure that no obstacle in the passway, then turn back to the initial position restart the equipment. | 12 SBTL5000 series User Manual P a g e...
  • Page 15: Product Maintenance

    (Attention: Above swing barrier maintenance must be maintained by professional personnel. Especially the movement and the electric control part, first cut off the power supply, ensure the operation safety. | 13 SBTL5000 series User Manual P a g e...
  • Page 16 ZK Building, Wuhe Road, Gangtou, Bantian, Buji Town, Longgang District, Shenzhen China 518129 Tel: +86 755-89602345 Fax: +86 755-89602394 www.zkteco.com Copyright©2019 ZKTECO CO., LTD. All rights reserved.
