Sauder Shoal Creek 422191 Instruction Booklet

L-desk
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
L-Desk
Shoal Creek Collection | Model 422191
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
For all your
newfangled gadgetry.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 510498
11/07/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Shoal Creek 422191

Summary of Contents for Sauder Shoal Creek 422191

  • Page 1 Shoal Creek Collection | Model 422191 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-28 Hammer Not actual size Français 29-32 Español 33-36 Skip the power trip. Safety 37-38 This time. Warranty Page 2 422191 www.sauder.com/services...

  • Page 3: Table Of Contents

    LEFT MODESTY PANEL (1) REAR LEG (3) LEFT DRAWER SIDE (1) BOTTOM (1) LEFT FRONT/RIGHT REAR LEG (3) DRAWER BACK (1) RIGHT END MOLDING (2) BACK (1) D716 DRAWER BOTTOM (1) LEFT END MOLDING (1) D716 www.sauder.com/services 422191 Page 3...
  • Page 4 30S BLACK 1-9/16" FLAT HEAD SCREW - 4 BLACK 9/16" FLAT HEAD SCREW - 6 102S GRAY 1-3/8" MACHINE SCREW - 4 SILVER 1" LARGE HEAD SCREW - 2 113S BLACK 1-15/16" FLAT HEAD SCREW - 13 Page 4 422191 www.sauder.com/services...
  • Page 5 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push twenty-eight SAUDER å TWIST-LOCK® FASTENERS (7F) into the large holes in the ENDS (A and B), RIGHT UPRIGHT (E), SUPPORTS (G and F), MODESTY PANELS (H and I), SHELF (M), PURSE SHELF (N), and BACK (S).
  • Page 6 Step 2 Turn eighteen CAM SCREWS (8F) into the LEGS (Q and R). å Page 6 422191 www.sauder.com/services...
  • Page 7 Push eighteen HIDDEN CAMS (1F) into the ENDS (A and B) å and UPRIGHT (E). Arrow Arrow Arrow (18 used) Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. www.sauder.com/services 422191 Page 7...
  • Page 8 å remove it and slide it on again. BLACK 9/16" FLAT HEAD SCREW (2 used in this step) Shoulder Apply pressure with your hands as you guide the MOLDINGS over the SCREWS and onto the ENDS. Page 8 422191 www.sauder.com/services...
  • Page 9 NOTE: Be sure the WOOD DOWELS insert into the END. å TWIST-LOCK® Edge with Angled edge FASTENERS D E N H I D i t h f a c S u r These surfaces should be even. Angled edge www.sauder.com/services 422191 Page 9...
  • Page 10 NOTE: The EXTENSION SLIDES (35MC) will be used later for the DRAWER. å 35MC 35MA Push the black lever in and pull the SLIDE from the RAIL. Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Open end Page 10 422191 www.sauder.com/services...
  • Page 11 FASTENERS H I D D E N These surfaces should be even. D E N H I D i t h f a c TWIST-LOCK® Edge with S u r FASTENERS These surfaces should be even. www.sauder.com/services 422191 Page 11...
  • Page 12 Lay the RIGHT END (A) on the fl oor as shown. å How to use the SAUDER TWIST-LOCK® FASTENER Fasten the SHELF (M) and BACK (S) to the RIGHT END (A). 1. Insert the dowel end of the FASTENER into the å...
  • Page 13 Step 9 Fasten the RIGHT UPRIGHT (E) to the SHELF (M) and å BACK (S). Tighten four TWIST-LOCK® FASTENERS. Angled edge www.sauder.com/services 422191 Page 13...
  • Page 14 å Fasten the BOTTOM (J) to the RIGHT END (A) and å RIGHT UPRIGHT (E). Use four BLACK 1-15/16" FLAT HEAD SCREWS (113S). 113S opening 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) Page 14 422191 www.sauder.com/services...
  • Page 15 END and UPRIGHT. Shoulder Apply pressure toward the END with your hands as you guide the MOLDING over the SCREWS and onto the END. Shoulder BLACK 9/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 422191 Page 15...

  • Page 16: Right End

    RIGHT END (A) and the LEFT FRONT/RIGHT REAR LEG (R) to the RIGHT UPRIGHT (E). Tighten six HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the LEGS insert å into the holes in the END and UPRIGHT. Page 16 422191 www.sauder.com/services...

  • Page 17: Right Top

    Step 13 Fasten the RIGHT END (A) and RIGHT UPRIGHT (E) to the å RIGHT TOP (C). Tighten four TWIST-LOCK® FASTENERS. Opening This large hole must be here. www.sauder.com/services 422191 Page 17...
  • Page 18 Fasten the RIGHT MODESTY PANEL (H) to the RIGHT å your drink. UPRIGHT (E). Use two BLACK 1-15/16" FLAT HEAD SCREWS (113S). 113S BLACK 1-15/16" FLAT HEAD SCREW (2 used in this step) Page 18 422191 www.sauder.com/services...
  • Page 19 Use three BLACK 1-15/16" FLAT HEAD SCREWS (113S). BLACK 1-15/16" FLAT HEAD SCREW (5 used in this step) Fasten the RIGHT SUPPORT (F) to the RIGHT å MODESTY PANEL (H). Use two BLACK 1-15/16" FLAT HEAD SCREWS (113S). www.sauder.com/services 422191 Page 19...
  • Page 20 Step 16 Fasten four PLATES (41G) to the RIGHT TOP (C) Use å eight BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (8 used in this step) Page 20 422191 www.sauder.com/services...
  • Page 21 Fasten the PURSE SHELF (N) to the LEFT MODESTY å PANEL (I). Tighten three TWIST-LOCK® FASTENERS. N E R S T E ® F A - L O I S T i t h f a c S u r www.sauder.com/services 422191 Page 21...

  • Page 22: Shelf

    Step 18 Fasten the LEFT MODESTY PANEL (I) and PURSE å SHELF (N) to the LEFT END (B). Tighten four TWIST-LOCK® FASTENERS. Page 22 422191 www.sauder.com/services...
  • Page 23 Step 19 Fasten the LEFT END (B) and LEFT MODESTY å PANEL (I) to the LEFT TOP (D). Tighten four TWIST-LOCK® FASTENERS. www.sauder.com/services 422191 Page 23...
  • Page 24 Fasten the LEFT MODESTY PANEL (I) to the LEFT å SUPPORT (G). Use two BLACK 1-15/16" FLAT HEAD SCREWS (113S). 113S BLACK 1-15/16" FLAT HEAD SCREW (2 used in this step) BLACK 9/16" LARGE HEAD SCREW (8 used in this step) Page 24 422191 www.sauder.com/services...

  • Page 25: Drawer Front

    Slide the DRAWER BOTTOM (D716 ) into the grooves in Fasten the DRAWER BACK (D78) to the DRAWER the DRAWER SIDES (D14 and D15) and INNER DRAWER SIDES (D14 and D15). Use four BLACK 1-9/16" FLAT FRONT (P). HEAD SCREWS (30S). www.sauder.com/services 422191 Page 25...
  • Page 26 Fasten the EXTENSION SLIDES (35MC) to the DRAWER å SIDES (D14 and D15). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. Open end Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 26 422191 www.sauder.com/services...
  • Page 27 D15) as shown. Almost time to Fasten two PULLS (7K) to the DRAWER FRONTS (O and P). å celebrate! With a nap. Use four GRAY 1-3/8" MACHINE SCREWS (39S). GRAY 1-3/8" MACHINE SCREW (4 used in this step) www.sauder.com/services 422191 Page 27...
  • Page 28 This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? 60 lbs. 35 lbs. 25 lbs. 30 lbs. (7 used) (8 used) 35 lbs. To cover HIDDEN CAMS To cover screws Page 28 422191 www.sauder.com/services...
  • Page 29 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 ARRIÈRE .................1 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 35MA GLISSIÈRE D'EXTENSION .......2 en ce qui concerne cet DESSUS DROIT .............1 35MC COULISSE D'EXTENSION .......2 élément, faire référence...
  • Page 30 Pour commencer l'assemblage, enfoncer vingt-huit FIXATIONS DROITE (A) et au MONTANT DROIT (E). Utiliser quatre VIS TÊTE TWIST-LOCK® SAUDER (12F) dans les gros trous des PLATE 8 mm DORÉES (3S). EXTRÉMITÉS (A et B), le MONTANT DROIT (E), les SUPPORTS (G et F), les VOILES DE FOND (H et I), la TABLETTE (M), la REMARQUE : Pour chaque GLISSIÈRE D'EXTENSION, faire tourner...
  • Page 31 ÉTAPE 14 Fixer le VOILE DE FOND DROIT (H) au DESSUS DROIT (C). Serrer deux FIXATIONS TWIST-LOCK®. Fixer le VOILE DE FOND DROIT (H) au MONTANT DROIT (E). Utiliser deux VIS TÊTE PLATE 49 mm NOIRES (113S). www.sauder.com/services 422191 Page 31...
  • Page 32 Enfoncer les ARMATURES POUR DOSSIERS (4B) sur chaque CÔTÉ DE TIROIR (D14 et D15) comme il l’est indiqué. Fixer deux POIGNÉES (7K) aux DEVANTS DE TIROIR (O et P). Utiliser quatre VIS À MÉTAUX 35 mm GRISES (39S). Page 32 422191 www.sauder.com/services...
  • Page 33 (JUEGO DE EXTENSIÓN SE MUESTRA POR pour future référence. EXTREMO IZQUIERDO ........1 SEPARADO) Pour contacter Sauder PANEL SUPERIOR DERECHO .......1 en ce qui concerne cet CORRIMIENTO DE ARCHIVERO ....2 PANEL SUPERIOR IZQUIERDO ....1 élément, faire référence EXCÉNTRICO ESCONDIDO ......
  • Page 34 Para comenzar el ensamblaje, empuje veintiocho SUJETADORES y al PARAL DERECHO (E). Utilice cuatro TORNILLOS DORADOS DE TWIST-LOCK® SAUDER (7F) dentro de los agujeros grandes de los CABEZA PERDIDA de 8 mm (3S). EXTREMOS (A y B), el PARAL DERECHO (E), los SOPORTES (G y F), los VELOS DE FONDO (H e I), el ESTANTE (M), el ESTANTE PARA NOTA: Para cada RIEL DE EXTENSIÓN, atornille un TORNILLO...
  • Page 35 Fije el ESTANTE PARA BOLSAS (N) al SOPORTE IZQUIERDO (G). Apriete el SUJETADOR TWIST-LOCK®. Fije el VELO DE FONDO IZQUIERDO (I) al SOPORTE IZQUIERDO (G). Utilice dos TORNILLOS NEGROS DE CABEZA PERDIDA de 49 mm (113S). www.sauder.com/services 422191 Page 35...
  • Page 36 Fije los CORRIMIENTOS DE ARCHIVERO (4B) sobre cada LADO DEL CAJÓN (D14 y D15) como se muestra. Fije dos TIRADORES (7K) a las CARAS DE CAJÓN (O y P). Utilice cuatro TORNILLOS GRISES PARA METAL de 35 mm (39S). Page 36 422191 www.sauder.com/services...
  • Page 37 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 422191 Page 37...
  • Page 38 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 38 422191 www.sauder.com/services...
  • Page 39 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 40 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
