Sauder Shoal Creek 408924 Manual

Lateral file
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Lateral File
Shoal Creek Collection | Model 408924
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Get all organized
and stuff .
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-25
Français pg 26-28
Español pg 29-32
Lot # 397206
10/11/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Shoal Creek 408924

Summary of Contents for Sauder Shoal Creek 408924

  • Page 1 Shoal Creek Collection | Model 408924 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 RIGHT DRAWER SIDE (1) TOP (1) LEFT FRONT/RIGHT REAR LEG (2) LEFT DRAWER SIDE (1) BOTTOM (1) DRAWER FRONT (1) D729 DRAWER BOTTOM (1) SHELF (1) DRAWER BOX FRONT (1) M63 DRAWER BRACE (1) BACK (1) END MOLDING (2) Page 2 408924 www.sauder.com/services...
  • Page 3 Now you know Part Identifi cation our ABCs. D729 www.sauder.com/services 408924 Page 3...
  • Page 4 SILVER 5/8" FLAT HEAD SCREW - 8 BLACK 9/16" FLAT HEAD SCREW - 6 BROWN 7/16" LARGE HEAD SCREW - 4 GOLD 5/16" FLAT HEAD SCREW - 8 30S BLACK 1-9/16" FLAT HEAD SCREW - 5 Page 4 408924 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1701...
  • Page 6 Step 2 Turn thirteen CAM SCREWS (8F) into the LEGS (H and I) å and DRAWER BOX FRONT (K). Remember: Righty tighty. Lefty loosey. (13 used) Page 6 408924 www.sauder.com/services...
  • Page 7 Step 3 Fasten one of the LEGS (H and I) to the ENDS (A and B). å Tighten six HIDDEN CAMS. Edge with CAM DOWELS Curved edge Curved edge www.sauder.com/services 408924 Page 7...
  • Page 8 Shoulder These edges should be even. Apply pressure with your hands as you guide the MOLDINGS over the SCREWS and onto the ENDS. BLACK 9/16" FLAT HEAD SCREW (6 used in this step) Page 8 408924 www.sauder.com/services...
  • Page 9 Step 5 Fasten the remaining LEGS (H and I) to the ENDS (A å and B). Tighten six HIDDEN CAMS. Curved edge Curved edge www.sauder.com/services 408924 Page 9...
  • Page 10 END. Turn a SCREW into this hole. Push the black lever in and pull the SLIDE from the RAIL. GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Hole Open end Open end Page 10 408924 www.sauder.com/services...
  • Page 11 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 408924 Page 11...
  • Page 12 Fasten the BOTTOM (D) to the BACK (F). Tighten two å HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Finished edge i t h f a c S u r D E N H I D Page 12 408924 www.sauder.com/services...
  • Page 13 Fasten the ENDS (A and B) to the BOTTOM (D) and å SHELF (E). Tighten eight HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Surface with HIDDEN CAMS S u r f a c H I D D E N i t h o www.sauder.com/services 408924 Page 13...
  • Page 14 Meet Part (C2). This component has been engineered to be lighter, stronger, faster… well ok. Not technically faster. But defi nitely makes for a sturdier Lateral File that’ s easier to assemble and friendlier to the environment. Page 14 408924 www.sauder.com/services...
  • Page 15 Step 11 Fasten four HINGES (AA) and four HINGE SPACERS (CC) å to the DOORS (G). Use eight SILVER 5/8" FLAT HEAD SCREWS (II). SILVER 5/8" FLAT HEAD SCREW (8 used in this step) www.sauder.com/services 408924 Page 15...
  • Page 16 Then tighten the mounting screw. hardware kits available Fasten one of the DOORS (G) to the LEFT END (B). Use on sauder.com. å the screws in the HINGES. Peel the BUMPER from the BUMPER CARD (OO). Stick å...
  • Page 17 To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) www.sauder.com/services 408924 Page 17...
  • Page 18 Fasten the DRAWER BACK (D61) to the DRAWER Fasten the DRAWER BRACE (M63) to the DRAWER å å SIDES (D87 and D88) and DRAWER BRACE (M63). Use BOX FRONT (K). Tighten one HIDDEN CAM. five BLACK 1-9/16" FLAT HEAD SCREWS. (30S). Page 18 408924 www.sauder.com/services...
  • Page 19 Step 15 Fasten the DRAWER FRONT (J) to the DRAWER å BOX FRONT (K). Use four BLACK 1-1/8" PAN HEAD SCREWS (GG). BLACK 1-1/8" PAN HEAD SCREW (4 used in this step) www.sauder.com/services 408924 Page 19...
  • Page 20 SLIDE. Open end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Open end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 20 408924 www.sauder.com/services...
  • Page 21 Use two BROWN 7/16" LARGE HEAD SCREWS (KK). Fasten a FILE BRACKET (12B) to the DRAWER BACK (D61). Use å two BROWN 7/16" LARGE HEAD SCREWS (KK). BROWN 7/16" LARGE HEAD SCREW (4 used in this step) www.sauder.com/services 408924 Page 21...
  • Page 22 FILE GLIDE (6B) on the LEFT DRAWER SIDE (D88) as shown in the upper diagram. Slide another FILE GLIDE (6B) onto the other end of the FILE å RODS (T), then press this FILE GLIDE over the RIGHT DRAWER SIDE (D87) as shown in the lower diagram. Page 22 408924 www.sauder.com/services...
  • Page 23 SILVER 1-1/4" MACHINE SCREWS (FF) through Almost time to the DRAWER BOX FRONT (K), through the DRAWER celebrate! With a nap. FRONT (J), and into the PULLS. SILVER 1-1/4" MACHINE SCREW (4 used in this step) www.sauder.com/services 408924 Page 23...
  • Page 24 The drawer will push in hard until it is all the way in, then it will slide in and out easier. 50 lbs. 30 lbs. 40 lbs. Page 24 408924 www.sauder.com/services...
  • Page 25 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. www.sauder.com/services 408924 Page 25...
  • Page 26 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 TIGE DE DOSSIER ............2 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 TRINGLE POUR DOSSIERS ........2 en ce qui concerne cet DESSUS ................1 ARMATURE POUR DOSSIERS ......2 élément, faire référence...
  • Page 27 VIS dans le trou indiqué dans le schéma agrandi. Ensuite, enfi ler la cartouche interne de la GLISSIÈRE D'EXTENSION vers l'extérieur pour trouver l'autre trou qui est aligné sur le trou dans l'EXTRÉMITÉ. Faire tourner une VIS dans ce trou. www.sauder.com/services 408924 Page 27...
  • Page 28 Ceci complète l'assemblage. Pour nettoyer l’unité, humidifi er un Fixer une CONSOLE POUR DOSSIERS (DD) au DEVANT DE chiff on avec de l’eau du robinet et essuyer. CAISSON DE TIROIR (K). Utiliser deux VIS TÊTE LARGE 11 mm MARRON (KK). Page 28 408924 www.sauder.com/services...
  • Page 29 EXTREMO DERECHO ..........1 CORRIMIENTO DE ARCHIVERO.....2 et conserver le livret pour future référence. 12B MÉNSULA DE ARCHIVERO .........1 EXTREMO IZQUIERDO ..........1 Pour contacter Sauder EXCÉNTRICO ESCONDIDO ......31 PANEL SUPERIOR ............1 en ce qui concerne cet PASADOR DE EXCÉNTRICO ......18 FONDO .................1 élément, faire référence...
  • Page 30 Fije el FONDO (D) al DORSO (F). Apriete dos los EXTREMOS. Con las manos, aplique presión sobre las EXCÉNTRICOS ESCONDIDOS. MOLDURAS mientras guía las MOLDURAS sobre los EXTREMOS. NOTA: Si las MOLDURAS vienen salidas de los TORNILLOS, retírelas y vuelva a deslizarlas otra vez. Page 30 408924 www.sauder.com/services...
  • Page 31 Repita este paso para la otra PUERTA (G). NEGROS DE CABEZA PERDIDA de 40 mm (30S). PASO 15 Fije la CARA DE CAJÓN (J) al FRENTE DE CAJÓN (K). Utilice cuatro TORNILLOS NEGROS DE CABEZA REDONDA de 28 mm (GG). www.sauder.com/services 408924 Page 31...
  • Page 32 Deslice otro CORRIMIENTO DE ARCHIVERO (6B) sobre el otro extremo de las VARILLAS DE ARCHIVERO (T) y presione este CORRIMIENTO DE ARCHIVERO sobre el LADO DERECHO DE CAJÓN (D87) como se muestra en el diagrama inferior. Page 32 408924 www.sauder.com/services...
  • Page 33 Les téléviseurs peuvent être très un téléviseur. téléviseur. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 408924 Page 33...
  • Page 34 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y hacerlos propensos a volcarse hacia adelante. Page 34 408924 www.sauder.com/services...
  • Page 35 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 36 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
