New Pagnell 2 Dr 2 Drw Wardrobe
Assembly Instructions
Dimensions
Width - 76cm
Depth - 54.5cm
Height - 180.5cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
601/9435
601/6524
601/8436
Version 1 Date: 08/11/16
Advertisement
Related Manuals for Argos Home New Pagnell 601/9435
Summary of Contents for Argos Home New Pagnell 601/9435
- Page 1 Width - 76cm Depth - 54.5cm Height - 180.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 1 Date: 08/11/16...
- Page 2 IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE • Argos Ltd. MK9 2 NW. • This product is intended for • Assembly of this product must children in the age 6 or above.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Top panel (76.2 x 54cm) Pilot holes for guidance only Right side panel...
- Page 4 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Bottom panel Drawer left side panel x 2 (73 x 11cm) (34 x 11.5cm)
-
Page 5: Tools Required
Components - Fittings Note: The quantities below are the correct amount to complete the assembly. In some cases mor may be supplied than are required. (This screw is included in the bag of runner) Runner x 4 12mm Screw x 12 Door hinge x 6 (This screws is included in the door hinge bag) - Page 6 Assembly Instructions Step 1 Middle hole Attaching runners and hinges Position Runners in front edge of the Right side panel 1.7cm Slide top of the Runner back. Runners on the Right side panel The front part of Note: the runner should be approximately 1.7cm from the front edge of the panel.
- Page 7 Assembly Instructions Step 1 - continued Middle hole Position Runners front edge of the Left side panel Slide top of the Runners 1.7cm on the Left Runners side panel The front part of Note: the runner should be approximately 1.7cm from the front edge of the panel.
- Page 8 Assembly Instructions Step 2 Fitting locking pins Screw Locking pins into the Right side panel and Left side panel Note: Insert locking pins as far as shown. Do not over tighten. Step 3 Fitting dowels Insert Dowels into the Bottom panel Bottom support Middle support Middle panel...
- Page 9 Assembly Instructions Step 4 Attaching plastic supports Plastic supports onto the Front panel back surface Front panel onto the Bottom panel Step 5 Attaching front panel 2 people are need Note: at this stage. Position Front panel and Bottom panel onto the unit.
- Page 10 Assembly Instructions Step 6 Attaching middle panel 2 people are Note: needed at this stage. Position Middle panel onto the unit. Insert 2 Locking nuts into the Middle panel Use a screwdriver to turn Locking nuts clockwise to lock. back edge Step 7 Attaching back support and bottom...
- Page 11 Assembly Instructions Step 8 Attaching left side panel Position Left side panel back edge onto the unit. Insert 5 Locking nuts into the Bottom panel Bottom support Middle support Middle panel Use a screwdriver to turn Locking nuts clockwise to lock. Step 9 Attaching top panel Door Stop...
- Page 12 Assembly Instructions Step 9 - continued Top panel onto the unit. back edge Step 10 Fixing back panel Apart the Ventilation holes covers rst. Attach Ventilation holes covers onto Back panel , comebine the covers. Continued on next page.
- Page 13 Assembly Instructions Step 10 - continued Attach Back panel onto the unit using Nails back surface Important: The unit MUST be ‘square’ when back is attached. Step 11 Drawer assembly Screw Locking pins into 4 holes shown on back of the Drawer front panel Insert Locking pins Note:...
- Page 14 Assembly Instructions Step 11 - continued Fix Drawer right side panel onto the Drawer front panel Insert 2 Locking nuts into the holes (they will only insert one way). Use a screwdriver to turn Locking nuts clockwise to lock. Insert 2 Locking nuts back surface into the holes (they will only insert one way).
- Page 15 Assembly Instructions Step 12 Note: Wall plugs supplied are for solid wall only. Fixing to wall wall be used for your wall, seek professional advice if in doubt Warning: In order to prevent overturning, this product must be used with the wall attachment device provided.
- Page 16 Assembly Instructions Step 13 Inserting drawers and clothes rail With help, carefully stand wardrobe upright. Place Clothes rail onto Rail supports Warning: The Wardrobe is heavy. Lift with care. Slide the drawers fully onto the runners so the runners butt up against the back of the drawer front.
- Page 17 Assembly Instructions Step 15 Hanging doors With help, slot Door hinges onto ‘hinge plates’. Tighten screw shown to lock hinges in position. Repeat opposite door. See ‘Hinge adjustment ’ in step 15 if the doors need adjusting. Step 16 Hinge adjustment To move doors up or down: loosen screws shown and move doors...
- Page 18 Before use allow Note : the glue to dry for 24 Door hours and make sure the unit is secure. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
-
Page 19: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
