- Page 1 HDMI® Audio & Video Scaler Vanco Part Number: 280563 Technical Support www.vanco1.com • techsupport@vanco1.com • 800-626-6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters. - Page 3 S/PDIF equipped audio receiver and amplifier, and make the highest compatibility to your home theater devices. HDMI & Audio Scaler and Converter Part # 280563 • HDMI Resolution Scaler with Audio Embedding/ • Maximum pixel rate : 165MHz De-embedding and Video Calibration • Deinterlacer supported...
-
Page 4: Specifications
Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton: • Part # 280563 HDMI & Audio Scaler and Converter • 5V/2A power supply unit • Installation software CD • Product Manual... - Page 5 PANEL DISCRIPTIONS 1. STEREO AUDIO OUT: connect to analog stereo audio component 2. S/PDIF AUDIO OUT: connect to digital S/PDIF audio component 3. DIP SWITCH: For firmware update: ON (switch pointing up) firmware update mode OFF (switch pointing down) normal mode 4.
-
Page 6: Connect And Operate
CONNECT AND OPERATE 1. Connect a source such as a Blu-Ray player, game console, Cable/Satellite receiver, etc. to the HDMI input. 2. Connect either a SPDIF digital coaxial audio cable or 3.5mm analog stereo cable from the source device to the SPDIF or Stereo Input ports on the unit. - Page 7 OSD MENU 1.Output Setup Out Res. Output Mode RGB, YCbCr444, YCbCr422 Default Pattern Disable, White, Cross, Hatch, Color, Gray, Windows, H-Ramp, W-HRamp, W-VRamp, Diagonal Audio Source Stereo, SPDIF 2.Image Contrast 0~255 of Contrast Level Brightness 0~255 of Brightness Level Saturation 0~255 of Saturation Level 0~255 of Hue Level B/W Extension...
- Page 8 CONTROL CONTINUED Method B: IR Remote Control Button Function FREEZE Freeze video ASPECT RATIO Aspect ratio change BLANK Blank video EXIT Exit OSD ENTER Enter key Up key LEFT Left key RIGHT Right key DOWN Down key MENU Menu on INPUT INFO Source resolution information 1080p60...
- Page 9 1. COM Port Selection - Please select the application COM Port Selection COM Port Detection Button Output Setup Button Image Button Adjustment Button System Button Input / Output Resolution Info 2. COM PORTCOM Port Detection Button Refresh Input / Output Resolution Info Button Output Quick Selection Button Click this button...
- Page 10 5. Adjustment Button 6. System Button 1. In-Sync Info: To view the current input resolution 2. Factory Reset Button 3. Firmware Update Button www.vanco1.com...
- Page 11 The steps of firmware update: 1. Unplug Mini-USB connector from device 2. Set the Dip Switch to ON 3. Connect the device to PC via USB to mini-USB cable 4. Click the FW Update button on software 5. Click “Load File” button to select the FW file 6.
-
Page 12: Troubleshooting
4. If you are still encountering issues, attempt the “hot-plug” concept. With all of the HDMI cables disconnected, turn on the source and plug in the HDMI cable into it’s output, then power up the Vanco unit and plug the HDMI cable into it’s input, finally turn on the display and plug the HDMI cable from the receiver into it. -
Page 13: Technical Support
NOTICE 1. Vanco High Speed HDMI cables are strongly recommended for use with this product to ensure best results. 2. Incorrect placement of IR Blaster and Receiver may result in the failure of the unit. Please check carefully before plugging in the IR accessories into the respective IR sockets. -
Page 14: Limited Warranty
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco regarding warranty repair or replacement. -
Page 15: Liability Statement
LIABILITY STATEMENT Every effort has been made to ensure that this product is free of defects. The manufacturer of this product cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. It is the responsibility of the user and installer of the hardware to check that it is suitable for their requirements and that it is installed correctly. - Page 16 Vanco® International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
