- Page 1 MULTI-FORMA T VIDEO WALL PROCESSOR with HDMI® Loop-out Vanco Part Number: EVSP14VW 1X4 Multi-format Video Wall Processor with HDMI® Loop-out www.vanco1.com • 800.626.6445...
- Page 2 DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters.
- Page 3 USB media player, analog and digital audio breakouts, and IR, TCP/IP and RS-232 control, allows one video signal across multiple displays to create a video wall! Out of the box, the EVSP14VW can handle up to four displays, in any configuration, or with the built in loop-out can be expanded by daisy chaining multiple units together to create an even larger video wall system.
-
Page 4: Specifications
SPECIFICATIONS Video Bandwidth ............225MHz/6.75Gbps Input ports ............... (1) HDMI (Female type), (1) USB, (1) VGA,(1) CVBS+L/R Video Resolutions……………………………....up to 1080p@60Hz Output ports ............(5) HDMI (Female type),(1) Coaxial, (2) L/R HDMI cable distance ..........26ft/8-bit 1080p USB formats…………………………………………. MPEG, H.264, RM/RMVB movie decode, JPEG, BMP, PNG Picture decode and MPEG1/2, MP3 audio decode Audio Formats…………………………………... -
Page 5: Panel Descriptions
9. DC 12V IN: Connect the included power supply to power the unit EDID The EVSP14VW is equipped with EDID management, however there is no need to adjust any dip switches or dials, the unit automatically reads the EDID from the display(s) and saves it internally. This feature was created for the installer in mind, for a plug and play installation! 800.626.6445... -
Page 6: Remote Control
REMOTE CONTROL 1. POWER BUTTON: Push button switch that turns the unit ON or OFF 2. DISPLAY ROTATE ADJUSTMENT: This button rotates the video image 90 degrees each time clockwise; will only adjust in 1x2, 1x3, and 1x4 video wall modes 3. -
Page 7: Connection Diagram
USB or HDMI 2. Connect displays such as an HDTV or HD Projector to the HDMI output(s) of the unit 3. Connect an additional EVSP14VW to the “LOOP OUT” port to add more displays for a larger video wall setup (OPTIONAL) 4. - Page 8 ADDITIONAL VIDEO WALL CONFIGURATIONS The EVSP14VW out of the box can handle up to 4 displays in multiple video wall configurations, including the following: www.vanco1.com...
- Page 9 ADDITIONAL VIDEO WALL CONFIGURATIONS 1x2 (H) 1x3 (H) 1x4 (H) 1x2 (V) 1x3 (V) 1x4 (V) 800.626.6445...
-
Page 10: General Page
SOFTWARE AND USER INTERFACE CONTROL VIA RS-232 The EVSP14VW can be controlled via RS-232, and includes a user interface to do so, simply connect the included RS-232 cable to a PC running Windows operating system. Windows XP or Windows 7 is recommended. -
Page 11: Mode Page
SOFTWARE AND USER INTERFACE CONTROL VIA RS-232 Mode Page Setting the Video Wall configuration. Simply click on the video wall configuration desired, bezel adjustment can also be changed. 1. Select the video wall configuration desired 2. Adjust height and width of the video signal across the video wall configuration, this will adjust for bezel size of the displays 800.626.6445... -
Page 12: Setup Page
SOFTWARE AND USER INTERFACE CONTROL VIA RS-232 Setup Page Selecting the input source, adjusting the output resolution and mode, and audio output 1. Select the source input 2. Select the output resolution desired 3. Select the output mode (HDMI or DVI) 4. -
Page 13: Upgrade Page
Download the available Scaler firmware on www.vanco1.com • Save the file onto a USB flash or hard drive • Insert the USB flash or hard drive to the USB port on the EVSP14VW • Click on “Upgrade Scaler” to begin firmware upgrade process 3. Software Version •... -
Page 14: Troubleshooting
If you are still encountering issues, attempt the “hot-plug concept. With all of the HDMI cables disconnected, turn on the source and plug in the HDMI cable into it’s output, then power up the Vanco unit and plug the HDMI cable into it’s input, finally turn on the display and plug the HDMI cable from the receiver into it. -
Page 15: Limited Warranty
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco regarding warranty repair or replacement. - Page 16 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
