Rational LM1 Series Original Installation Manual page 61

6-2/1 G (2 AC 208 V)
10-1/1 G (2 AC 208 V)
10-2/1 G (2 AC 208 V)
20-1/1 G (2 AC 208 V)
20-2/1 G (2 AC 208 V)
6-1/1 G (2 AC 220 V)
6-2/1 G (2 AC 220 V)
10-1/1 G (2 AC 220 V)
10-2/1 G (2 AC 220 V)
20-1/1 G (2 AC 220 V)
20-2/1 G (2 AC 220 V)
6-1/1 G (2 AC 230 V)
6-2/1 G (2 AC 230 V)
10-1/1 G (2 AC 230 V)
10-2/1 G (2 AC 230 V)
20-1/1 G (2 AC 230 V)
20-2/1 G (2 AC 230 V)
6-1/1 G (2 AC 240 V)
6-2/1 G (2 AC 240 V)
10-1/1 G (2 AC 240 V)
10-2/1 G (2 AC 240 V)
20-1/1 G (2 AC 240 V)
20-2/1 G (2 AC 240 V)
80.06.070_iCombi Pro-iCombi Classic_IM_V01_en-GB
Hz Current
consump-
tion (A)
60 4.3
60 4.3
60 7.2
60 6.3
60 10.6
Hz Current
consump-
tion (A)
50/60 2.7
50/60 4.1
50/60 4.1
50/60 6.8
50/60 5.9
50/60 10
Hz Current
consump-
tion (A)
50/60 2.6
50/60 3.9
50/60 3.9
50/60 6.5
50/60 5.7
50/60 9.6
Hz Current
consump-
tion (A)
50/60 2.5
50/60 3.8
50/60 3.8
50/60 6.3
50/60 5.4
50/60 9.2
6 | Electrical connection
Power (kW) Fuse (A)
0.9 15
0.9 15
1.5 15
1.3 15
2.2 15
Power (kW) Fuse (A)
0.6 15
0.9 15
0.9 15
1.5 15
1.3 15
2.2 15
Power (kW) Fuse (A)
0.6 15
0.9 15
0.9 15
1.5 15
1.3 15
2.2 15
Power (kW) Fuse (A)
0.6 15
0.9 15
0.9 15
1.5 15
1.3 15
2.2 15
RCD type
B
B
B
B
B
RCD type
B
B
B
B
B
B
RCD type
B
B
B
B
B
B
RCD type
B
B
B
B
B
B
