Rational LM1 Series Original Installation Manual page 59

6-1/1 E (3 AC 480 V)
6-2/1 E (3 AC 480 V)
10-1/1 E (3 AC 480 V)
10-2/1 E (3 AC 480 V)
20-1/1 E (3 AC 480 V)
20-2/1 E (3 AC 480 V)
6-2/3 (3 NAC 400 V)
6-1/1 E (3 NAC 400 V)
6-2/1 E (3 NAC 400 V)
10-1/1 E (3 NAC 400 V)
10-2/1 E (3 NAC 400 V)
20-1/1 E (3 NAC 400 V)
20-2/1 E (3 NAC 400 V)
6-2/3 (3 NAC 415 V)
6-1/1 E (3 NAC 415 V)
6-2/1 E (3 NAC 415 V)
10-1/1 E (3 NAC 415 V)
10-2/1 E (3 NAC 415 V)
20-1/1 E (3 NAC 415 V)
20-2/1 E (3 NAC 415 V)
iCombi Pro, iCombi Classic Gas units
6-1/1 G (1 NAC 100 V)
10-1/1 G (1 NAC 100 V)
20-1/1 G (1 NAC 100 V)
6-1/1 G (1 NAC 110 V)
10-1/1 G (1 NAC 110 V)
20-1/1 G (1 NAC 110 V)
80.06.070_iCombi Pro-iCombi Classic_IM_V01_en-GB
Hz Current
consump-
tion (A)
60 16
60 32
60 27
60 52
60 54
60 96
Hz Current
consump-
tion (A)
50/60 9.2
50/60 15.6
50/60 32.3
50/60 27.3
50/60 54
50/60 53.7
50/60 98
Hz Current
consump-
tion (A)
50/60 9.5
50/60 15
50/60 33.7
50/60 28.5
50/60 56.5
50/60 56.2
50/60 102.7
Hz Current
consump-
tion (A)
50/60 3.8
50/60 7.5
50/60 12
Hz Current
consump-
tion (A)
50/60 5.5
50/60 8.3
50/60 11.8
6 | Electrical connection
Power (kW) Fuse (A)
10.8 25
22.4 40
18.9 35
37.4 70
37.2 70
67.9 125
Power (kW) Fuse (A)
5.7 10
10.8 16
22.4 35
18.9 32
37.4 63
37.2 63
67.9 125
Power (kW) Fuse (A)
6.3 10
10.8 16
24.2 35
20.5 32
40.6 63
40.4 63
73.8 125
Power (kW) Fuse (A)
0.38 15
0.75 15
1.2 15
Power (kW) Fuse (A)
0.61 15
0.91 15
1.3 15
RCD type
B
B
B
B
B
B
RCD type
F
F
B
F
B
F
B
RCD type
F
F
B
F
B
F
B
RCD type
F
B
F
RCD type
F
B
F
