- Page 1 Gazebo GZ3D Aluminium Composite Roof Panels Assembly Instructions 7’1” 9’4.7” Systems Trading Corporation 450 7th Avenue Suite 2809, New York, NY 10123 Customer service: (877)782 4482 of 24 www.stcny.com...
-
Page 2: Table Of Contents
Introduction Table of Contents Safety Advice Thank you for purchasing the Gazebo GZ3D. Introduction..........• The gazebo must be positioned and fixed When properly assembled and maintained, this gazebo will provide many years of enjoyment! Table of Contents......... on a flat level surface. List of Parts..........These instructions include helpful hints and important information needed to safely assemble and properly •... - Page 3 Place all the parts for each step in staging areas, checking that you have all parts as you go. Screw M6*8 Ground Spike If any parts are missing or damaged, contact STC customer service before beginning assembly: Customer service: (877)782 4482 Email: easygrow@stcaustin.com Profile...
- Page 4 STEP 1 Assembling the Corner Profiles Slide support frames (2) over lower end of corner profiles (1). Attach support plates (3) to corner profiles as shown, using four screws (21) for each plate. Place all the parts on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. Components Corner profile (1) Support frame (2)
-
Page 5: Step 2 Assembling The Rails
STEP 2 Assembling the Rails Attach two outer roof connectors (8) to each rail set at pre-drilled screw holes, using screws (20). NOTE: The Rails (5) have a preassembled connecting parts to be inserted into Rails (6). VIEW FROM SIDE Components Inner Roof Connector (7) Screw (18) x 16 Rail (5) Rail (6) -
Page 6: Step 3 Attaching The Rails To The Corner Profiles
Attaching the Rails to the Corner STEP 3 Using at least 3 people, attach the remaining two roof Profiles profile sets (5+6) to corner profiles (1), connecting all four corner profiles (1). Fasten with four screws (20) and supplied magnetic hex key (30) on each side. Attach one roof profile set (5+6) to two corner Components Close holes in profile sets with plastic caps #3 (25). profiles (1) as shown, using screws (20) and supplied magnetic hex key (30) through holes in profile set. -
Page 7: Step 4 Securing The Gazebo To The Ground
STEP 4 Securing the Gazebo to the Ground STEP 5 Installing the Lower Roof Gable Profiles Fasten the gazebo frame to the ground, using four spikes (28) for each ATTENTION: support plate. DO NOT ATTEMPT TO ASSEMBLE THIS ALONE ! Lower support frames (2) to cover support plates (3). Components Components Ground spike (28) - Page 8 Install roof gable profiles (10). Using screws (19), connect all eight roof top VIEW FROM BELOW Using screws (20) connect profiles (10) to inner roof connectors (7) on profile sets (5,6)and the connectors (34) to roof top cover (15) as shown. other end to remaining connectors (34) on roof top cover (15). Using screws (22) and nuts (24), connect roof gable profiles (9) to roof connectors (4) on top of corner profiles (1). Using screws (20), connect roof gable profiles (9) to roof top connectors (34) on the four corners of roof top cover (15). ILLUSTRATION Attach T-connectors A (32) to underside of roof gable profiles (10), using screws (20) as shown.
- Page 9 STEP 6 Installing the Horizontal Roof Profiles STEP 7 Installing the Roof Panels and Upper Roof Profiles IMPORTANT: Remove protective plastic from both sides of roof panels. Place with black surface toward the sun facing out when installing. Components Components Attach roof gable profiles (16,17) to T- connectors A (32) and B (33), placing ends black into cut-outs on gutter profiles 9 and 10 as black black black...
- Page 10 Components Fit roof panel (14) on top of roof profiles (9,10 and 17) towards top of gazebo Screw (22) as shown. x 56 Roof Profile (16A) Roof Profile (17A) Roof Gable Profile (9A) Roof Gable Profile (10A) 998mm 998mm 2107mm 1537mm Fit roof panel (12) on top of roof profiles(9,10 and 16) as shown and fasten with one screw (23) from be- low to outer roof connector (8). Place roof profile (16A) on top of roof profile (16) as shown and fasten with three screws (22) from below (inside gazebo).
- Page 11 Continue in a clock-wise direction as Slide roof profile (9A) into rails on top of roof profile (9) shown, until the last two panels: from lower end towards top of gazebo as shown. Place the upper roof panel. Fasten with four screws (22) from below. Place the lower roof panel, secure with one screw (23) from below.
-
Page 12: Step 8 Installing The Plastic Caps
Slightly lifting the roof gable profiles (9A and 10A), place the lower roof panel (12) and secure with one screw (23) from below. Fasten the roof gable profiles (9A and 10A) at their lower end with screws (22) from below. Place the horizontal roof profile (17A) carefully from above as shown, fasten with three screws (22) from below. STEP 8 Installing the Plastic Caps Components... - Page 13 Gazebo GZ3D Aluminium Composite Roof Panels Assembly Instructions WARRANTY: Warranty covers damage due to manufacturing defects only. Warranty does not cover weather inflicted damage (Force Majeure) and/or damages caused by not following assembly instructions and adhering to warnings in manual. ATTENTION: Roof profiles, roof panels and gables must be aligned properly during assembly to minimize any possibility of leaking.
