  • Page 1 BG-BPTZ-10XU HD Color Video Camera User Manual...
  • Page 2 Attention Electric Safety Installation and operation must accord with electric safety standard Caution to transport Avoid stress, vibration and soakage in transportation, storage and installation. Polarity of power supply The power supply of the product is ±12V, the max electrical current is 2A. Polarity of the power supply drawing. Careful of installation Never move the camera by seizing the camera head.

  • Page 3: Table Of Contents

    Content 1.FAST INSTALLATION ............................4 1.1 C ........................4 AMERA NTERFACE XPLANATION 1.2 P ........................4 OWER ON INITIAL CONFIGURATION 1.3 V ............................... 4 IDEO UTPUT 2. PRODUCT OVERVIEW ............................7 2.1 P ..........................7 RODUCT NTRODUCTION 2.1.1 Dimension ............................7 2.1.2 Accessories ............................
  • Page 4 4.3 P ........................27 ELCO PROTOCOL COMMAND LIST 5. CAMERA MAINTENANCE AND TROUBLESHOOTING ..................28 5.1 C ..........................28 AMERA AINTENANCE 5.2 T ............................28 ROUBLESHOOTING 6. W ..............................30 ARRANTY 7. M ............................31 ISSION TATEMENT 8. C ............................32 OPYRIGHT OTICE...

  • Page 5: Fast Installation

    1.Fast Installation 1.1 Camera Interface Explanation Figure 1.1 Interface Camera Lens 6. RS232 Control Interface (output) Remote Controller Receiver Light 7. RS232 Control Interface (input) Camera Base 8. RS485 Input (left +, right-) Tripod Screw Hole 9. USB2.0 Interface Mounting hole 10.
  • Page 6 1.4 Bracket mount Note: Bracket can only be wall mounted or upside down mounted on template and concrete wall, but cannot be installed on plasterboard. 1) Wall mount step...
  • Page 7 2). Upside down mount step...

  • Page 8: Product Overview

    2. Product overview 2.1 Product Introduction 2.1.1 Dimension Figure 2.2 Camera dimension...

  • Page 9: Accessories

    Accessories Power adapter 1piece USB2.0 cable 1 piece Standard User manual 1 piece IR Remote controller 1 piece BG-BPTZ-10XU Rubber pad Warranty card 1 piece Optical Wall mount bracket Ceiling mount bracket USB2.0 Video cable: If need USB2.0 cable to provide power but not a power adapter, USB2.0 Video cable with two ports is needed, among which red port is for power supply and black port for transmitting USB video signals.

  • Page 10: Technical Specification

    2.3 Technical Specification Model Camera Parameter Sensor 1/2.9-inch high quality HD CMOS sensor Effective Pixels 2.07 megapixel、16:9 H264/H265/MJPG:1920*1080P@30/25/20/15/10/5fps；1280*720P@30/25/20/15/10/5fps； Video Format 960*540@30/25/20/15/10/5fps；800*600@30/25/20/15/10/5fps； 720*576@30/25/20/15/10/5fps；720*480@30/25/20/15/10/5fps； 640*480@30/25/20/15/10/5fps；640*360@30/25/20/15/10/5fps； 352*288@30/25/20/15/10/5fps；320*240@30/25/20/15/10/5fps； YUY2:1280*720@10/5fps；800*600@10/5fps；640*480@30/25/20/15/10/5fps； 640*360@30/25/20/15/10/5fps； View Angel 34.1°～85° 8.8°～ 66° F Value f=3.35mm～10.05mm f=4.34mm～41.66mm F1.7～3.0 F1.85 – F2.43 Optical Zoom Minimum Illumination 0.5Lux (F1.8, AGC ON) 2D﹠3D DNR...

  • Page 11: Interface Instruction

    Consumption 5W(max) Store Temperature -40℃～+70℃ Store Humidity 20%～90% Working Temperature -10℃～+50℃ Working Humidity 20%～80% 156.8mm×112.6mm×139.5mm Dimension Weight Working Environment Indoor Accessory Power Supply、Remote Controller、USB2.0 cable、Manual、Warranty card、Packing list Optional Accessory Bracket 2.4 Interface Instruction 2.4.1 External Interface ：RS232 in \out、USB2.0、A-in、DC12V External interface Figure 2.4 external interface diagram...

  • Page 12: Rs-232 Interface

    2.4.2 RS-232 Interface 1)RS-232 Interface Computer or keyboard and camera connection method Camera WindowsDB-9 1.DTR 1.DCD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND 4.DTR 5.RXD 5.GND 6.GND 6.DSR 7.IR OUT 7.RTS 8.NC 8.CTS 9.RI 2)RS-232 Mini-DIN 8-pin Port Definition Port Definition Data Terminal Ready Data Set Ready Transmit Data System Ground...

  • Page 13: Application Instruction

    Request to Send Clear to Send Ring Indicator 4)VISCA networking as shown below: Camera cascade connection method Camera1 Camera 2 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD 4.GND 4.GND 5.RXD 5.RXD 6.GND 6.GND 7.IR OUT 7.OPEN 8. NC 8.OPEN Note: this model has RS232 input and output interface, so you can cascade as the above way. 3.

  • Page 14: Keys Instruction

    3.2.1 Keys Instruction 3.2.1 Keys Instruction 1. Standby Key After 3S long press, the camera will step into standby mode. Long press 3S again, the camera will self-test again and back to HOME position. (Note: If power-on mode is turned on and Preset 0 is set, and there is no operation within 12s, it will automatically point to the specified preset position.
  • Page 15 1. In this instruction, “press the key” means a click rather than a long-press, and a special note will be given if a long-press for more than one second is required. 2. When a key-combination is required, do it in sequence. For example,“ 【 *】+【#】+【F1】”means press“【*】”first and then press“【#】”...

  • Page 16: Menu Setting

    1. Preset setting: to set a preset position, the users should press the “【SET PRESET】” key first and then press the number key 0-9 to set a relative preset, Note: 10 preset positions in total are available by remote controller. 2.

  • Page 17: System Setting

    MENU ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ （Setup） （Camera） （P/T/Z） （Version） （Restore Default） [↑↓]Select [← →]Change Value [Menu]Back[Home]OK SETUP: System setting CAMERA : Camera setting P/T/Z：Pan tilt setting VERSON: camera version setting Restore Default: Reset setting [↑↓] Select: for selecting menu [← →] Change Value: for modify parameters [MENU] Back: Press [MENU] to return [Home] OK: Press [Home] to confirm 3.3.2 System Setting...

  • Page 18: Camera Setting

    VISCA ADDRESS: VISCA=1~7 Pelco-P=1~255 Pelco-D = 1~255 BAUD RATE : 2400/4800/9600/115200 VISCA ADDRESS FIX : On/Off 3.3.3 Camera Setting Move the pointer to the (CAMERA) in the Main Menu, click the【HOME】key and enter the (CAMERA) as follow: CAMERA ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ （Exposure） （Color）...
  • Page 19 Compensation Level: -7~7 (only available in auto mode when EV is ON) BLC: ON/OFF for options (only available in auto mode) Anti-Flicker: OFF/50Hz/60Hz for options (only available in Auto/Iris priority/Brightness priority modes) Gain Limit: 0~15(only available in Auto/ Iris priority /Brightness priority mode) WDR: Off,1~8 Shutter Priority:1/25,1/30,1/50,1/60,1/90,1/100,1/120,1/180,1/250,1/350,1/500,1/1000,1/2000,1/3000,1/4000,1/6000,1/10000(only...
  • Page 20 IMAGE ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Brightness Contrast Sharpness Flip-H Flip-V B&W-Mode Color Gamma Default Close Low-Light Mode [← →]Change Value [↑↓]Select [Menu]Back Brightness: 0~14 Contrast: 0~14 Sharpness: 0~15 Flip-H: On/Off Flip-V: On/Off B&W Mode: color, black/white Gamma: default, 0.47, 0.50, 0.52, 0.55 DZoom: digital zoom options: On/Off DCI: Dynamic Contrast: Off,1～8 4) FOCUS Move the pointer to the (FOCUS) in the Menu, click the【HOME】and enter the (FOCUS) as follow,...

  • Page 21: P/T/Z

    NOISE REDUCTION ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ NR-2D Auto NR-3D Dynamic Hot Pixel [← →]Change [↑↓]Select Value [Menu]Back 2D Noise Reduction: Auto, close, 1~7 3D Noise Reduction: Close, 1~8 Dynamic Hot Pixel: Close, 1~5 3.3.4 P/T/Z Move the pointer to the (P/T/Z) in the Main Menu, click the【HOME】and enter the (P/T/Z) as follow, P/T/Z ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝...

  • Page 22: Restore Default

    VERSION ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ MCU Version 3.1.0 2019-09-26 Camera Version 1.0.5 2019-09-27 AF Version 1.0.0 2019-09-07 [← →]Change Value [↑↓]Select [Menu]Back [Home]OK MCU Version: Display MCU version information Camera Version: Display camera version information AF Version: Display the focus version information Lens: Display the lens zoom 3.3.6 Restore Default Move the pointer to the (RESTORE DEFAULT) in the Main Menu, click the【HOME】and enter the (RESTORE DEFAULT) as follow, RESTORE DEFAULT...

  • Page 23: Camera Control Command

    Ack/Completion Message Command packet Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. z = camera address + 8 Error Messages Command packet Note Returned when the command format is different or when a Syntax Error z0 60 02 FF command with illegal command parameters is accepted...
  • Page 24 Command Function Command packet Note 5500K 8x 01 04 35 09 FF 6000K 8x 01 04 35 0A FF 7000K 8x 01 04 35 0B FF Reset 8x 01 04 03 00 FF 8x 01 04 03 02 FF Manual Control of R Gain CAM _RGain Down 8x 01 04 03 03 FF...
  • Page 25 Command Function Command packet Note 50HZ 8x 01 04 23 01 FF 50HZ 60HZ 8x 01 04 23 02 FF 60HZ Reset 8x 01 04 02 00 FF 8x 01 04 02 02 FF Aperture Control CAM_Aperture Down 8x 01 04 02 03 FF Direct 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain...

  • Page 26: Inquiry Command

    Command Function Command packet Note 8x 01 06 03 VV WW RelativePosition 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF Home 8x 01 06 04 FF Reset 8x 01 06 05 FF 8x 01 06 07 00 0W W:1 UpRight 0:DownLeft 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF Pan-tiltLimitSet YYYY: Pan Limit Position(TBD)
  • Page 27 y0 50 00 FF CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 04 FF B&W CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p: Memory number last operated. y0 50 02 FF SYS_MenuModeInq 8x 09 06 06 FF y0 50 03 FF y0 50 02 FF CAM_LR_ReverseInq...

  • Page 28: Pelco -Dprotocol Command List

    4.2 Pelco-D protocol command list Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00...

  • Page 29: Camera Maintenance And Troubleshooting

    Zoom In 0xA0 Address 0x00 0x20 0x00 0x00 0xAF Zoom Out 0xA0 Address 0x00 0x40 0x00 0x00 0xAF Focus Far 0xA0 Address 0x01 0x00 0x00 0x00 0xAF Focus Near 0xA0 Address 0x02 0x00 0x00 0x00 0xAF Set Preset 0xA0 Address 0x00 0x03 0x00...
  • Page 30 4) Remote controller can not work a. Remote control address is set to 1 (if the machine is set back to the factory defaults, remote control addresses need to be back to 1, too) b. Check whether the battery is installed on the remote controller or low. c.

  • Page 31: Warranty

    6. Warranty BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple: 1.

  • Page 32: Mission Statement

    7. Mission Statement BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank.

  • Page 33: Copyright Notice

    8. Copyright Notice All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change without notice.
