INSTRUCTION MANUAL FOR OMEGA
CERAMIC COOKTOP
OCC64TCOM

Advertisement

loading

Related Manuals for Omega OCC64TCOM

Summary of Contents for Omega OCC64TCOM

  • Page 1 INSTRUCTION MANUAL FOR OMEGA CERAMIC COOKTOP OCC64TCOM...

  • Page 3: Table Of Contents

    The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. Due to continual product development, Omega reserves the right to alter specifications and appearances without notice.

  • Page 4: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.

  • Page 5: Appliance Details

    The appliance has been designed to exhaust cooking fumes externally. Before installation, please ensure that the following have been supplied and that the tools listed below are readily available. Specifications Model OCC64TCOM Cooking Zones 4 Zones 220-240V~ 50 / 60Hz...

  • Page 7: Installation

    INSTALLATION Cut out the work surface according to the sizes shown in the image below. Ensure that there is a minimum of 50mm of space around the cutout. The thickness of the bench should be at least 30mm. Please select heat-resistant and insulated bench materials (Wood and similar fibrous or hygroscopic materials should not be used as the bench material unless impregnated) to avoid the electrical shock and larger deformation caused by heat radiation from the hotplate.
  • Page 8 INSTALLATION In order to avoid accidentally touching the hot underside of the cooktop, or getting an unexpected electric shock, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the cooktop.

  • Page 9: Electrical Connection

    ELECTRICAL CONNECTION The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below. 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. • Use the pad of your finger, not the tip. • You will hear a beep each time a touch is registered. •...
  • Page 11 OPERATING INSTRUCTIONS Using the Cooktop When the power is connected you will hear a beep and all the lights will come on for one second and then go out. This indicates that the cooktop has entered standby mode. Turn the cooktop on by touching the On / Off button.
  • Page 12 OPERATING INSTRUCTIONS Using the Timer The timer can be used in two different ways: • You can use it as an alarm. In this case it will not turn any cooking zones off. • You can use it to automatically turn off a cooking zone after the timer has finished. The timer can be set to a maximum of 99 minutes.
  • Page 13 OPERATING INSTRUCTIONS Setting the Timer to turn one or more Cooking Zones Off Touch the “+” or “-“ button of the cooking zone you wish to set the timer for. Set the timer as described on the previous page. A red dot next to the power level for the corresponding cooking zone will illuminate to indicate that the timer has been set for it.

  • Page 14: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Cleaning Problem Resolution Important • When the power to the cooktop is switched off, there will be no ‘hot surface’ indication but the cooking zone may still be hot! Take extreme 1. Switch the power to the cooktop off. care.
  • Page 15 MAINTENANCE AND CLEANING Troubleshooting Problem Possible causes What to do Make sure the ceramic hob is connected to the power supply and that it is switched on. The cooktop cannot be Check whether there is a power outage in No power. turned on.

  • Page 16: Warranty

    WHAT IS COVERED: By Our Warranty During the warranty period, Omega or its authorised Service Centre will, at no extra charge, if your appliance is readily accessible without the need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defective.
