Summary of Contents for Omega OCC64TZTGG
- Page 1 INSTRUCTION MANUAL FOR OMEGA COOKTOP OCC64TZTGG...
-
Page 3: Table Of Contents
The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. Due to continual product development, Omega reserves the right to alter specifications and appearances without notice. -
Page 4: Important Safety Warnings
A means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • If the supply cord is damaged, it must be replaced by the authorised Omega service center in order to avoid a hazard. -
Page 5: Installation
INSTALLATION WARNING: This appliance must be installed by an authorised service person or qualified technician, according to the instructions in this guide and in compliance with the current local regulations. • Incorrect installation may cause harm and damage, for which the manufacturer accepts no responsibility and the warranty will not be valid. - Page 6 INSTALLATION Installation of the Hob The appliance is supplied with an installation kit including adhesive sealing material, fixing brackets and screws. • Cut the aperture dimensions as indicated in the figure. Locate the aperture on the worktop so that, after the hob is installed, the following requirements are followed.
- Page 7 INSTALLATION Electrical Connection WARNING: The electrical connection of this appliance should be carried out by an authorised service person or qualified electrician, according to the instructions in this guide and in compliance with the current local regulations. WARNING: THE APPLIANCE MUST BE EARTHED. •...
-
Page 8: Operating Instructions
OPERATING INSTRUCTIONS The hob is controlled by pressing the appropriate electronic button. Each button pressed is followed by a buzzer sound. 1. Heater display 2. Activate/Deactivate heater 3. Heat setting decrease 4. Heat setting increase 5. Decimal point 6. Key lock indicator 7. - Page 9 OPERATING INSTRUCTIONS Set Cooking Level with and without Heat Boost • All heaters are equipped with the heat boost function. • If the heat boost is required, set the heat from the current level to level 9 by pressing the button only.
- Page 10 OPERATING INSTRUCTIONS Child Lock The child lock function is used to lock the appliance in a complicated, multi-step process. Child lock (and unlocking) is only available in S-Mode. First, must be pressed until the buzzer sounds, then must be pressed simultaneously for at least 0.5 seconds, but no longer than 1 second.
- Page 11 OPERATING INSTRUCTIONS Operating Time Limitations The hob control unit has a limitation on the operating time. If the heat setting for a heater has not been changed for a certain time, the heater will switch off automatically. A “0” will be displayed for 10 seconds; however there may be some residual heat present.
-
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING: Switch off the appliance and allow it to cool before cleaning is to be carried out. • Check whether the cleaning materials are appropriate and recommended by the manufacturer before use on your appliance. • Use cream cleaners or liquid cleaners which do not contain particles. Do not use caustic (corrosive) creams, abrasive cleaning powders, rough wire wool or hard tools as they may damage the cooker surfaces. -
Page 13: Warranty
WHAT IS COVERED: By Our Warranty During the warranty period, Omega or its authorised Service Centre will, at no extra charge, if your appliance is readily accessible without the need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defective.
