How to Use the Gas Oven
• The range becomes very hot during operation.
• The oven door becomes very hot during operation. Keep children away.
General Features
The gas oven is provided with:
• Oven burner, mounted on the lower part of the oven (14000 BTU/hr).
• Broil burner, mounted on the upper part of the oven (11000 BTU/hr).
• Fan motor which can be used in combination with the oven burner.
It is not possible to use the fan motor in combination with the broil burner: a safety device switches off the fan
motor when the gas oven/broil control knob is turned on broil position.
• Light to illuminate the oven to enable visual checking of the food that is cooking.
The door is hot, use the handle.
Operating Principles
Heating and cooking are obtained in the following ways:
Normal Convection
The heat is produced by the oven burner.
Forced Convection
The heat produced by the oven burner is distributed throughout the oven by the fan. The hot air envelops the food in the
https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_...
Updated: Sun, 31 May 2020 20:19:05 GMT
Powered by
1
Advertisement
Related Manuals for Fisher & Paykel OR30SDBMX1
Summary of Contents for Fisher & Paykel OR30SDBMX1
- Page 1 The heat is produced by the oven burner. Forced Convection The heat produced by the oven burner is distributed throughout the oven by the fan. The hot air envelops the food in the https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
-
Page 2: Using The Oven For The First Time
The gas flow to the burner is regulated by a thermostat which allow to maintain the oven temperature constant. The control of the temperature is assured by a thermostatic probe positioned inside the oven. https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT... - Page 3 LIGHT & FAN position and counter-clockwise from OFF to LIGHT position. DO NOT TURN from LIGHT & FAN to LIGHT position or from LIGHT to LIGHT & FAN positions. DO NOT FORCE. https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
- Page 4 The thermostat allows the automatic control of the temperature. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and broil burners) with flame- failure device. https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
- Page 5 Check the cooking time and turn off the oven 5 minutes before the theoretical end time to utilize the stored heat. Recommended for: For foods which require the same cooking temperature both internally and externally, i.e. roasts, spare ribs, meringue, https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
- Page 6 A safety device switches off the fan motor when the gas oven/broil control knob is turned on “BROIL” position. Do not attempt to light the broil burner during power failure. • https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
- Page 7 The burner ignition procedure must always start with the control knob in the off position or it will not be possible to ignite the burner. Do always broil with oven door closed. The oven door becomes very hot during operation. Keep children away. https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
- Page 8 • Place the food to be cooked on the broiling pan. Fig. 3.6 • Introduce the broiling pan in the oven (fig. 3.6). Fig. 3.5 It is advisable to handle the oven accessories using oven gloves. https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
- Page 9 Fig. 3.8 Fig. 3.7 https://producthelp.fisherpaykel.com/us/Cook/Ranges/Gas/OR30SDBMX1/User_Guide_OR30SDBMX1/05_how_to_use_the_… Updated: Sun, 31 May 2020 20:19:05 GMT Powered by...
