SUMS uridan CADET GVC-10 Installation Instruction

Advertisement

Installation Instructions

Parts List

|
1
x fitting No. 4
2
x screws fitting No. 4

Fitting Kit

|
1
x uriLOCK 0.3 L
1
x uriCLEAN 0.5 L
Note
|
Installation of the uridan waterless urinal is very
simple.
If you are retrofitting existing flushing urinals with uridan
waterless urinals, please ensure that the sewer line is jetted
and clean of uric scale before installation. Please also remove
any existing s-trap to avoid double trapping the urinal.
The uridan urinals work without water, and must be fitted to
a 50mm waste pipe. Installation should be carried out by
authorized plumbers in accordance with AZ/NZS3500.2.
PLEASE NOTE: The undiluted discharge from a waterless
urinal must not be transported through copper or copper
alloy pipework.
GVC-10 Installation Instructions – May 2020
2
x 45° bend
1
x uriCLOTH
1
x Cover
1
x suction device
www.uridanaustralia.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the uridan CADET GVC-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for SUMS uridan CADET GVC-10

  • Page 1 Installation Instructions Parts List x fitting No. 4 x screws fitting No. 4 x 45° bend Fitting Kit x uriLOCK 0.3 L x uriCLEAN 0.5 L x uriCLOTH x Cover x suction device Note Installation of the uridan waterless urinal is very simple.
  • Page 2 Installation Instructions CADET GVC-10 glass reinforced plastic (GRP) | vertical Installation Measure distance from floor and mark holes for fitting No. (4). Drill holes and mount fitting No. (4). Mount the wastewater pipes as per drawing. The distance from the wall to the center of the waste pipe should be close to 107 mm.
