Installation Instructions

Parts List

|
2
x screws fitting No. 4
1
x fitting No. 4

Fitting Kit

|
1
x uriCLEAN 0.5 L
1
x uriLOCK 0.3 L
Note
|
Installation of the uridan waterless urinal is very
simple.
If you are retrofitting existing flushing urinals with uridan
waterless urinals, please ensure that the sewer line is jetted and
clean of uric scale before installation. Please also remove any
existing s-trap to avoid double trapping the urinal.
The uridan urinals work without water, and must be fitted to a
50mm waste pipe. Installation should be carried out by
authorized plumbers in accordance with AZ/NZS3500.2.
PLEASE NOTE: The undiluted discharge from a waterless urinal
must not be transported through copper or copper alloy
pipework.
GHC-10 Installation Instructions – May 2020
1
x 87° bend
1
x uriCLOTH
1
x Cover
1
x suction device
www.uridanaustralia.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the uridan CADET GHC-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SUMS uridan CADET GHC-10

  • Page 1 Installation Instructions Parts List x screws fitting No. 4 x 87° bend x fitting No. 4 Fitting Kit x uriCLEAN 0.5 L x uriCLOTH x Cover x suction device x uriLOCK 0.3 L Note Installation of the uridan waterless urinal is very simple.
  • Page 2 Installation Instructions CADET GHC-10 glass reinforced plastic (GRP) | horizontal Installation Measure distance from the floor and mark holes for fitting No. (4). Drill holes and mount fitting No. (4). Install the 87 ° bend, maintaining a distance of 107 mm from the wall to the middle of the pipe. Adjust fitting No.
