Installation Instructions
Parts List
|
2
x screws fitting No. 20
1
x fitting No. 20
Fitting Kit
|
1
x uriLOCK 0.3 L
1
x uriCLEAN 0.5 L
Note
|
Installation of the uridan waterless urinal is very simple.
If you are retrofitting existing flushing urinals with uridan waterless urinals, please ensure that the sewer line
is jetted and clean of uric scale before installation. Please also remove any existing s-trap to avoid double
trapping the urinal.
The uridan urinals work without water, and must be fitted to a 50mm waste pipe. Installation should be carried
out by authorized plumbers in accordance with AZ/NZS3500.2.
PLEASE NOTE: The undiluted discharge from a waterless urinal must not be transported through copper or
copper alloy pipework.
GX-10 Installation Instructions – May 2020
|
1
x uriCLOTH
1
x suction device
1
x Cover
www.uridanaustralia.com.au
Advertisement
Table of Contents
Related Manuals for SUMS Uridan CAPTAIN GX-10
Summary of Contents for SUMS Uridan CAPTAIN GX-10
- Page 1 Installation Instructions Parts List x screws fitting No. 20 x fitting No. 20 Fitting Kit x suction device x uriLOCK 0.3 L x uriCLEAN 0.5 L x uriCLOTH x Cover Note Installation of the uridan waterless urinal is very simple. If you are retrofitting existing flushing urinals with uridan waterless urinals, please ensure that the sewer line is jetted and clean of uric scale before installation.
- Page 2 Installation Instructions CAPTAIN GX-10 glass reinforced plastic (GRP) | vertical Installation Mark holes for fitting No. (20) and install. Hold the urinal against the wall and push firmly onto fitting No. (20). Slide the urinal down to the 50 mm waste outlet. Fill the waste trap (Poisition B) with water.
