Installation Instructions
Parts List
|
2
x fitting No. 20
4
x screws fitting No. 20
Fitting Kit
|
1
x uriLOCK 0.3 L
1
x uriCLEAN 0.5 L
*Toilet seat packed separately – incl. installation instructions
Note
|
EN
If you are retrofitting existing flushing urinals with uridan waterless urinals, please ensure that the sewer line
is jetted and clean of uric scale before installation. Please also remove any existing s-trap to avoid double trapping
the urinal.
The uridan urinals work without water and the urinals should be fitted to a 50 mm waste pipe.
Installation should be carried out by authorized plumbers in accordance with AZ/NZ3500.2.
PLEASE NOTE: The undiluted discharge from a waterless urinal must not be transported through copper or copper
alloy pipework.
GY-10 Installation Instructions – May 2020
1
x uriCLOTH
1
x Cover
1
x suction device
www.uridanaustralia.com.au
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SUMS uridan COMPASS GY-W
Summary of Contents for SUMS uridan COMPASS GY-W
- Page 1 Installation Instructions Parts List x fitting No. 20 x screws fitting No. 20 Fitting Kit x uriLOCK 0.3 L x uriCLEAN 0.5 L x uriCLOTH x Cover x suction device *Toilet seat packed separately – incl. installation instructions Note If you are retrofitting existing flushing urinals with uridan waterless urinals, please ensure that the sewer line is jetted and clean of uric scale before installation.
- Page 2 Installation Instructions COMPASS GY-W glass reinforced plastic (GRP) | vertical waste Installation 1. Mark holes for fitting No. (20) and install. 2. Hold the urinal against the wall and push firmly onto fitting No. (20). Slide the urinal down to connect to the 50mm waste outlet.
