essential
home
TM
OWNER'S MANUAL
Grayson Night Stand
5533301KP
caution
carefully read instructions and procedures for safe operation
product code
0-07049243-4
upc code
0-2998655332-4
date of purchase
_____/_____/_____
Please Recycle
receipt of purchase
Recicle Por Favor
Réutilisez SVP
attach here
B345533301KP00
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Essential Home Grayson 5533301KP
Summary of Contents for Essential Home Grayson 5533301KP
- Page 1 essential home OWNER'S MANUAL Grayson Night Stand 5533301KP caution carefully read instructions and procedures for safe operation product code 0-07049243-4 upc code 0-2998655332-4 date of purchase _____/_____/_____ Please Recycle receipt of purchase Recicle Por Favor Réutilisez SVP attach here B345533301KP00...
- Page 3 PARTS - PIEZAS left panel right panel bottom panel izquierdo panel derecho cime fondo 35533301011 35533301021 35533301031 35533301041 left drawer side drawer front right drawer side kick cajon del frente lado del cajón izquierdo lado del cajón derecho retroceso 35533302070 35533302080 35533301060 35533301051...
- Page 4 PARTS - PIEZAS left cabinet member right cabinet member right drawer runner left drawer runner corredera de mueble izquierda corredera de mueble derecha deslizador izquierdo de cajón deslizador derecha de cajón #A56030 #A54220 #A51401 drawer bracket knob soporte de caón perilla #A22510 #A11600...
- Page 5 This illustration shows how the CAM fastening system works. Esta ilustración muestra el sistema de fijación de leva y como funciona. Tighten to fully seat. Do not over tighten. Proper orientation of cam. Apriétese a totalmente asiento. No La orientación apropiada de leva. haga encima de apriétese.
- Page 6 Proper orientation of CAM LOCK Posición correcta de la cerradura de leva. Finished Edge Borde Acabado page 6 B345533301KP00...
- Page 7 Proper orientation of CAM LOCK Posición correcta de la cerradura de leva. Finished Edge Borde Acabado page 7 B345533301KP00...
- Page 8 Finished Edge Borde Acabado page 8 B345533301KP00...
- Page 9 Proper orientation of CAM LOCK Posición correcta de la cerradura de leva. 7/16" Approx. 1/8" Finished Edge Borde Acabado page 9 B345533301KP00...
- Page 10 Finished Edge Borde Acabado LOCK UNLOCK APRETAR DESAPRETAR Finished Edge Borde Acabado Finished Edge Borde Acabado LOCK UNLOCK APRETAR DESAPRETAR page 10 B345533301KP00...
- Page 11 Carefully place unit on its front side. Con cuidado, coloque la unidad sobre WARNING su parte frontal. Please make sure that the Back Panel is attached securely. All nails must be driven into the parts straight. Failure to do so could cause instability, product collapse, product collapse, and/or serious injury.
- Page 12 Lay the drawer sides down on a flat hard surface. Carefully line up the drawer bracket with the holes in the drawer side as shown. Using a hammer, tap each drawer bracket stem part way into each hole. Repeat this process until the drawer bracket is fully seated on the drawer side. Coloque los lados del cajón sobre una superficie plana y dura.
- Page 13 Finished Surface Superficie Acabado page 13 B345533301KP00...
- Page 14 page 14 B345533301KP00...
- Page 15 roller cabinet member rodillo corredera de mueble drawer runner roller deslizador de cajon rodillo MAXIMUM LOADS – CARGA MAXIMA This unit has been designed to support the maximum loads 15 lbs. 40 lbs. shown. Exceeding these load 6.8 kg. 18.1 kg. limits could cause sagging, instability, product collapse, and/or serious injury.
- Page 16 Certificate of Conformity 1. This certificate applies to the Ameriwood Industries Inc. product identified by this instruction manual. 2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303). 3. This product is distributed by: Ameriwood Industries Inc. 410 East First Street South Wright City, MO 63390 1-636-745-3351...
