- Page 1 OWNER'S MANUAL HAVERHILL FAUX GRANITE 5 PIECE DINING SET Caution: This instruction booklet contains important safety information. Please read and keep for future reference. Product code: 0-05283416-5 UPC code: 065867159820 Date of purchase:____/____/____...
-
Page 2: Maintenance
CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part. Customer Service Department No. -
Page 3: Hardware List
HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 HARDWARE LIST Ø1/4" X 19MM Ø5/16" X 23MM FLAT WASHER FLAT WASHER 16 PCS 28 PCS Ø5/16" X 3" Ø5/16" X 1-1/2" HEX SOCKET HEAD BOLT HEX SOCKET HEAD BOLT 16 PCS 4 PCS ALLEN KEY ALLEN KEY... - Page 4 HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 PARTS LIST (Table & Chair) TABLE TOP CHAIR LEG 1 PC 8 PCS BACK FRAME SEAT FRAME 4 PCS 4 PCS SEAT CUSHION TABLE LEGS 4 PCS 4 PCS...
- Page 5 HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 STEP 1 Place table top (A) upside down on a clean, smooth surface to avoid scratches. Attach table legs (F) with nuts (7), spring washers (9) and flat washers (2). Use Allen wrench (8) to tighten nuts (7). With the help of another person, turn the table upright.
- Page 6 HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 STEP 2 Attach seat frame (D) to back frame (C) with hex socket head bolts (3), spring washers (9) and flat washers (2). Use Allen key (6) to tighten hex socket head bolts (3). Secure the center of seat frame (D) to back frame (C) with hex socket head bolts (4), spring washers (9) and flat washers (2).
- Page 7 HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 STEP 3 Attach seat cushion (E) to seat frame (D) with wood screws (12). Use a Phillips head screw driver (not included) tighten all wood screws (12).
- Page 8 HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 STEP 4 Attach chair legs (B) to seat frame (D) with hex socket head bolts (10), spring washers (11) and flat washers (1). Use Allen key (5) to install all hex socket head bolts (10). NOTE: Once all bolts have been installed, apply a downward force on the chair.
-
Page 9: Need Help
HAVERHILL FAUX GRANITE 5 PC DINING SET DAKM5415 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Product Maximum Weight... -
Page 10: Customer Service
FAUX GRANITE 5 PC DINING SET Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name:... - Page 11 Please refer to part numbers when reordering For questions or comments about product: Email: das@dorel.com or Call toll-free: 1-800-295-1980 Made in / Hecho en VIETNAM for Kmart Corporation, Hoffman Estates, IL 60179 SHOP kmart.com...
