essential
home
TM
OWNER'S MANUAL
Belmont Headboard
5537026KP
caution
carefully read instructions and procedures for safe operation
product code
0-06791334-3
upc code
0-2998655372-0
date of purchase
_____/_____/_____
Please Recycle
receipt of purchase
Recicle Por Favor
attach here
B345537026KP01
Advertisement
Related Manuals for Essential Home 5537026KP
Summary of Contents for Essential Home 5537026KP
- Page 1 OWNER'S MANUAL Belmont Headboard 5537026KP caution carefully read instructions and procedures for safe operation product code 0-06791334-3 upc code 0-2998655372-0 date of purchase _____/_____/_____ Please Recycle receipt of purchase Recicle Por Favor attach here B345537026KP01...
- Page 3 PARTS - PIEZAS left panel right panel cima panel izquierdo panel derecho 35537026030 35537026010 35537026020 fixed shelf left partition right partition adjustable shelf estante fijo particion iquierdo particion derecho estante ajustable 35537026040 35537026050 35537026060 35537026070 back panel panel trasero K553702600 front panel 2 doors panel frente...
- Page 4 PARTS - PIEZAS #A12210 #A80250 #A21500 #A21520 #A17300 #A22500 #A22510 steel dowel shelf support 3/4" bolt 1/2" pan head cam lock compression dowel cam bolt clavija de acero soporte de estante perno 3/4" perno de leva clavija de compresion cerradura de leva cabeza redondo 1/2"...
- Page 5 proper orientation of cam lock orientación apropiada de la leva page 5 B345537026KP01...
- Page 6 loosen this screw, separate the hinge from the plate aflojar este tornillo, separar la bisagra de la placa FINISHED EDGE BORDE ACABADO FINISHED EDGE BORDE ACABADO page 6 B345537026KP01...
- Page 7 7/16" Approx. page 7 B345537026KP01...
- Page 8 proper orientation of cam lock orientación apropiada de la leva proper orientation of cam lock orientación apropiada de la leva page 8 B345537026KP01...
- Page 9 all finished edges are facing downwards todos los bordes acabados se encuentra hacia abajo RAW SURFACE SUPERFICIE CRUDO LOCK APRETAR page 9 B345537026KP01...
- Page 10 all finished edges are facing downwards todos los bordes acabados se encuentra hacia abajo compression dowels at this end clavijas de compresión en este extremo page 10 B345537026KP01...
- Page 11 all finished edges are facing downwards todos los bordes acabados se encuentra hacia abajo 12 x 20 RAW SURFACE SUPERFICIE CRUDO page 11 B345537026KP01...
- Page 12 page 12 B345537026KP01...
- Page 13 Slide hinge arm onto hinge plate and tighten screw “C”. Deslícese el brazo de bisagra hacia el plato de la bisagra y aprieta el tornillo "C". repeat the procedure for the other door repetir el procedimiento para la otra puerta page 13 B345537026KP01...
- Page 14 This unit has been designed to Esta unidad se ha diseñado support the maximum loads para apoyar las cargas shown. Exceeding these load máximas demostradas. limits could cause sagging, Exceder estos límites de instability, product collapse, carga podía causar ceder, and/or serious injury.
- Page 15 Use this step if you are fastening the Headboard to a metal Bed Frame (sold separately) Utilice este paso si la fijación de la Cabecera en una Estructura Metálica (se vende por separado) page 15 B345537026KP01...
- Page 16 Use this step if you are fastening the Headboard to Mates Bed #5536026KP (sold separately) Utilice este paso si la fijación de la Cabecera a la Cama #5536026KP (se vende por separado) page 16 B345537026KP01...
