Linear Technology DC1662A Quick Start Manual page 4

Item Qty Reference
1 0 C1-C8,C14,C17,C23-C28,R5-R8,R16
2 0 C9
3 7 C10,C11,C31-C35
4 2 C13,C19
5 3 C15,C36,C37
6 1 C16
7 2 C12,C18
8 4 C21,C22,C29,C30
9 10 E1-E6,E8-E10,E13
10 3 E7,E11,E12
11 6 J1-J6
12 1 JP1
13 6 XJP1 (6 LOCATION FOR JP1)
14 8 L1-L4,R1-R4
15 1 L5
16 1 L6
17 5 PT1-PT5
18 4 R9,R11,R13,R14
19 1 R15
20 1 T1
21 1 U1
Preliminary
Part Description
OPT, 0402
OPT, 0603
CAP., X7R, 0.1uF, 10%, 16V, 0402
IND., MULTILAYER, 5.1nH, +/-0.3nH, 0402
CAP., C0G, 1000pF, 5%, 50V, 0402
CAP., X7R, 4.7uF, 10%, 16V, 0805
RES., CHIP, 0 Ohm, 0402
CAP., X5R, 1uF, 10%, 10V, 0402
TESTPOINT, TURRET, .063"
TESTPOINT, TURRET, .094"
CONN., SMA, 50-OHM, EDGE-LANCH
HEADER, 6 X 2 PIN, 2MM
SHUNT
RES., CHIP, 0 Ohm, 0805
CAP., C0G, 1.0pF, +/-0.05pF, 0402
CAP., C0G, 1.2pF, +/-0.05pF, 0402
POT., 4mm SMD, 500 Ohm
RES., CHIP, 100 Ohm, 1%, 1/16W, 0402
RES., CHIP, 1 Ohm, 1%, 1/8W, 0805
TRANSFORMER, RF BALUN
IC, LT5585IUF#PBF, QFN 4mm X 4mm
Linear Technology Confidential
Manufacturer / Part #
MURATA, GRM155R71C104KA88D
MURATA, LQG15HS5N1S02D
MURATA, GRM1555C1H102JA01D
MURATA, GRM21BR71C475KA73L
VISHAY, CRCW04020000Z0
MURATA, GRM155R61A105KE15D
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
E.F.JOHNSON, 142-0701-851
SAMTEC, TMM-106-02-L-D
SAMTEC, 2SN-BK-G
VISHAY, CRCW08050000Z0
MURATA, GJM1555C1H1R0WB01D
MURATA, GJM1555C1H1R2WB01D
BOURNS, 3214X-1-501-E
VISHAY, CRCW0402100RFKED
VISHAY, CRCW08051R00FNEA
ANAREN, BD0826J50200A00
LINEAR TECH., LT5585IUF#PBF
4
