Product Outlook

Display screen
Function softkeys
To perform the
function displayed
above each softkey.
Acquisition and
function controls
To access the scope,
meter, logger,
system, and help
functions.
Power key
Horizontal controls
To control the sweep speed
(sec/div) and horizontal position
of the waveform. Use
to zoom into the waveform.
8
Scope terminals
Keysight U1610/20A Quick Start Guide
USB interface
connector and
DC power
inlet
Directional keys
Vertical controls
To set the
vertical scaling
(volt/div) and
vertical offset.
Meter terminals
