- Page 1 User Manual EKI-6333AC-M12 Series EN50155 Industrial M12 Wi-Fi AP...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable.
- Page 3 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters (7.87 inches) between the radiator and your body. EKI-6333AC-M12 Series User Manual...
- Page 4 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. EKI-6333AC-M12 Series User Manual...
- Page 6 Always disconnect the power from the device before servicing it. Before plugging a cable into any port, discharge the voltage stored on the cable by touching the electrical contacts to the ground surface. About the Device This device is for indoor use only. EKI-6333AC-M12 Series User Manual...
-
Page 7: Table Of Contents
Contents Chapter Introduction ......... 1 Overview ....................2 Device Features..................2 Specifications.................... 2 Dimensions ....................3 Chapter Getting Started ........4 Hardware ....................5 2.1.1 Front View..................5 2.1.2 Top View..................5 2.1.3 Bottom View.................. 6 2.1.4 LED Indicators ................6 Connecting Hardware ................ - Page 8 M12 X-Coded Connector Pin Assignment..............9 Figure 2.9 M12 A-Coded Connector Pin Assignment..............9 Figure 2.10 M12 A-Coded Connector Pin Assignment ..............10 Figure 2.11 Power Wiring for EKI-6333AC-M12 Series..............11 Figure 2.12 Grounding Connection....................12 Figure 2.13 Installing the Power Cable................... 13 Figure 2.14 Removing the Power Cable..................
-
Page 9: Introduction
Chapter Introduction... -
Page 10: Overview
Overview EKI-6333AC-M12 Series Industrial Wi-Fi AP is designed for railway applications, including rolling stock. EKI-6333AC-M12 Series support AP/Bridge/Client mode and is designed with dual 2.4GHz/5GHz wireless module, support IEEE 802.11 a/b/g/n/ac concurrent dual band with M12 connector to provide a reliable wireless connectivity for Industrial environments. -
Page 11: Dimensions
CE, FCC Part 15 Subpart B (Class B) Approvals Rail Traffic EN 50155 Dimensions WLAN 2 WLAN 2 WLAN 1 WLAN 1 Ø5 [0.20] hole-4pcs 156.40 [6.16] 50.10 [1.97] 63.40 [2.50] 173 [6.81] 186 [7.32] 15.20 [0.60] Figure 1.1 Dimensions EKI-6333AC-M12 Series User Manual... -
Page 12: Getting Started
Chapter Getting Started... -
Page 13: Hardware
M12 5-pin (female) port to access the managed switch's software. 2.1.2 Top View WLAN 2 WLAN 2 WLAN 1 WLAN 1 Figure 2.2 Top View No. Item Description Antenna connectors Connectors for WLAN2 antennas. Antenna connectors Connectors for WLAN1 antennas. EKI-6333AC-M12 Series User Manual... -
Page 14: Bottom View
Power 2 is on Power 2 is off or power error condition exists Either Power 1 or Power 2 is off Power 1, Power 2 are on ETH2 Green, blinking Ethernet port 2 is transmitting or receiving data EKI-6333AC-M12 Series User Manual... -
Page 15: Connecting Hardware
C - M S ta tu s E T H E T H M / C Figure 2.5 Wall Mount Installation Once the device is installed on the wall, tighten the screws to secure the device. EKI-6333AC-M12 Series User Manual... -
Page 16: Wireless Connection
The location and position of the antenna is crucial for effective wireless connectivity I - 6 3 3 3 A C - M S ta tu s E T H E T H M /C Figure 2.7 Positioning the Antenna EKI-6333AC-M12 Series User Manual... -
Page 17: Network Connection
The managed USB models have Fast USB ports (5-pin shielded M12 connector with A coding) circular connectors. The USB port located on the switch's front side are used to connect to USB-enabled devices. 2.2.4.1 M12 A-Coded Connector Pin Assignment Figure 2.9 M12 A-Coded Connector Pin Assignment Description VBUS EKI-6333AC-M12 Series User Manual... -
Page 18: Console Connection
The console port, used to access the managed switch’s software, has an 5-pin M12 (male) port. A console cable with the mating M12 (female) port and both a DB-9 and / or a USB connector is available for purchase from Advantech. 2.2.5.1 M12 A-Coded Connector Pin Assignment Figure 2.10 M12 A-Coded Connector Pin Assignment... -
Page 19: Figure 2.11 Power Wiring For Eki-6333Ac-M12 Series
EKI-6333AC-M12 Series support 24 to 110 V . Dual power inputs are supported and allow you to connect a backup power source. Single DC Power Redundant DC Power P2 P1 P2 P1 Chassis Chassis (pane) (pane) One DC Supply Dual DC Supplies Figure 2.11 Power Wiring for EKI-6333AC-M12 Series... -
Page 20: Figure 2.12 Grounding Connection
The device only supports the voltage outlined in the type plate. Do not use any other power components except those specifically designated for the device. Warning! Power down and disconnect the power cord before servicing or wiring the device. EKI-6333AC-M12 Series User Manual... -
Page 21: Figure 2.13 Installing The Power Cable
Make sure the power is not connected to the device or the power converter before proceeding. Loosen the screws securing the connector to the power cable receptor. Remove the power cable from the device. Figure 2.14 Removing the Power Cable EKI-6333AC-M12 Series User Manual... -
Page 22: Figure 2.15 Standard M12 5-Pin Female Dc Power Input Connector
RD24, female connector. Simply align the keyed female connector to the male connector and twist the threaded to secure. Figure 2.15 Standard M12 5-Pin Female DC Power Input Connector Description EKI-6333AC-M12 Series User Manual... -
Page 23: Web Interface
Chapter Web Interface... -
Page 24: Log In
Enter the default user name and password (admin/admin) to log into the management interface. You can change the default password after you have successfully logged in. Click Login to enter the management interface. Figure 3.1 Login Screen Note! Screen may differ depending on Web browsers. EKI-6333AC-M12 Series User Manual... -
Page 25: Changing Default Password
Enter the username of the profile to change (currently logged in user displays), then enter the new password under the Password field. Re-type the same password in the Confirm Password field. Click Apply to change the current account settings. Figure 3.2 Administration > HTTP EKI-6333AC-M12 Series User Manual... -
Page 26: Overview
Displays the assigned netmask of the device. MAC Address Displays the MAC address of the device. System Status Memory Utilization Displays the total memory utilization in terms of percentage. CPU Utilization Displays the total CPU utilization in terms of percentage. EKI-6333AC-M12 Series User Manual... -
Page 27: Network Settings
Enter in the value designating the lease time for the DHCP server. Submit Click Submit to save the values and update the screen. Note! All new configurations will take effect after rebooting. To reboot the device, click Administration > Tools > Reboot. EKI-6333AC-M12 Series User Manual... -
Page 28: Wireless Settings
Enter the name to distinguish it from other networks in your neighborhood. SSID Broadcast Click the drop-down menu to enable or disable the SSID broadcast function. AP Isolation Click the drop-down menu to enable or disable the AP Isolation function. EKI-6333AC-M12 Series User Manual... -
Page 29: Figure 3.7 Wireless Settings > Wlan > Advanced
Transmission Power Use the scroll bar to set the transmission power of the WiFi. By default the AP transmits at full power: Full, Half, Quarter. Submit Click Submit to save the values and update the screen. EKI-6333AC-M12 Series User Manual... -
Page 30: Figure 3.8 Wireless Settings > Wlan > Security
MAC address. Signal level Displays the power level measure in decibel-milliwatts of the listed BSSID. Connected time Displays the total uptime period. Tx/Rx rate Displays the transmit (Tx) to receive (Rx) rate of the connected client. EKI-6333AC-M12 Series User Manual... -
Page 31: Figure 3.10 Wireless Settings > Wlan > Access Control
Disable, Deny or Allow. In the Deny or Allow menu, enter the MAC address of the target device - support for up to 32 target devices. Submit Click Submit to save the values and update the screen. EKI-6333AC-M12 Series User Manual... -
Page 32: Figure 3.11 Wireless Settings > Wlan > Log
Figure 3.11 Wireless Settings > WLAN > Log The following table describes the items in the previous figure. Item Description Download Click Download to download the log file. Auto Scroll Click the checkbox to enable the Auto Scroll function. EKI-6333AC-M12 Series User Manual... -
Page 33: Administration
Displays the system date and time. Manual Time Set the system date and time. NTP Service Click the drop-down menu to enable the NTP server. Time Zone Click the drop-down menu to select a system time zone. EKI-6333AC-M12 Series User Manual... -
Page 34: Http
Display the user name. Password Enter the character set for the define password type. Confirm Password Retype the password entry to confirm the profile password. Submit Click Submit to save the values and update the screen. EKI-6333AC-M12 Series User Manual... -
Page 35: Configuration Manager
Figure 3.16 Administration > Upgrade Manager The following table describes the items in the previous figure. Item Description Upgrade Manager Click Choose File to select the configuration file. Upload Click Upload to upload to the current version. EKI-6333AC-M12 Series User Manual... -
Page 36: Reset System
Apply and Reboot Click Apply and Reboot to have configuration changes you have made to be saved across a system reboot. All changes submitted since the previous save or system reboot will be retained by the switch. EKI-6333AC-M12 Series User Manual... -
Page 37: Tools
Host names are composed of series of labels concatenated with periods. Each label must be between 1 and 63 characters long, maximum of 64 characters. Ping Click Ping to display ping result for the IP address. EKI-6333AC-M12 Series User Manual... - Page 38 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...
