French Country Hall Table
HARDWARE LIST
CODE
NAME
CAM LOCKS
A
(Ø15x9mm)
CAM BOLTS
B
(Ø6.5x35mm)
RAIL SCREW
C
(Φ1/4"*51mm)
SPRING WASHER
D
( Φ1/4")
FLAT WASHER
E
(Φ1/4"*16mm)
ALLEN WRENCH
F
HANDLE SCREW
G
(22mm)
HANDLE
H
Please do not return to the store
. Broken or Missing Parts?
. Need help with Assembly?
If you have any questions just call 1-800-468-6447 or email us
parts@convenience-concepts.com
Item No. 6042188
6042188BL
M6042189
FIGURE
Q'TY
CODE
4PCS
4PCS
8PCS
8PCS
8PCS
1PC
1PCS
1PCS
PARTS LIST
NAME
TOP PANEL
1
BOTTOM PANEL
2
LEG
3
FIGURE
Q'TY
1PC
1PC
4PCS
Advertisement
Table of Contents
Related Manuals for convenience concepts French Country Hall Table
Summary of Contents for convenience concepts French Country Hall Table
- Page 1 French Country Hall Table Item No. 6042188 6042188BL M6042189 HARDWARE LIST PARTS LIST CODE NAME FIGURE Q'TY CODE NAME FIGURE Q'TY CAM LOCKS TOP PANEL 4PCS (Ø15x9mm) CAM BOLTS BOTTOM PANEL 4PCS (Ø6.5x35mm) RAIL SCREW 8PCS 4PCS (Φ1/4"*51mm) SPRING WASHER 8PCS ( Φ1/4")
- Page 2 STEP B × 4pcs 1.) Screw Cambolts ( B ) into Legs ( 3 ). STEP 2 A × 4pcs 1.) Place Cam Locks ( A ) into Bottom Panel ( 2 ). **Arrow On Cam Lock Faces Outward Opening **** 2.) Insert Legs into Bottom Panel ( 2 ) and Lock into position by turning Cam Locks ( A ) Clockwise.
- Page 3 STEP 4 C × 8pcs D × 8pcs E × 8pcs F × 1pc 1.) Assemble Rails Screws ( C ) with Spring Washer ( D ) and Flat Washer ( E ) in order as shown. 2.) Using Allen Wrench ( F ), fasten Rail Screw Assembly to secure Top Panel ( 1 ) to Leg Assembly.
