Spring Assembly; Attachment Of Spring To Crib - Child Craft Legacy Crib Assembly Directions And Parts List

6
S 6- D 6: S
TEP IAGRAM
Install (4) Spring Mounting
Brackets B to ends of Spring
W using (8) Pan Head Ma-
chine Screws I and (8) Lock
Nuts G , (metal threads of Lock
Nut to be inserted first over
Screw as shown in EN-
LARGED VIEW.)
Tighten all (8) Pan Head Ma-
chine Screws I while holding
Lock Nuts G with a 7/16 inch
wrench. After tightening se-
curely, loosen 1/4 turn on all
screws I so that Spring Mount-
ing Brackets B will be loose
enough to slide freely in their
mounting slots. Note: These
(8) Panhead Machine Screws
I will always remain 1/4 turn
loose.
Plastic insert in
Lock Nut G
S 7- D 7: A
TEP IAGRAM
proceeding.) Lower the spring assembly down into the inside of the crib. Be careful to position the Spring Mounting Brackets B between the crib posts
and the first spindle. You may choose any of the three adjustable height positions shown for mounting the Spring by using the (4) Socket Head Shoulder
Screws K . Tighten Socket Head Shoulder Screws K
notice that Spring Mounting Brackets B are able to move freely on Screw K . This is normal. Check periodically to see that Screws K are securely
tightened down against metal inserts. As your child grows and becomes more active, relocate Spring by relocating Socket Head Shoulder Screws
K in a lower position location.
X
Locate the (4) Casters H , insert one into each socket in each lower corner post of Headboard A
to your particular model. CAUTION: If crib is placed on exceptionally thick carpet, take care when crib is rolled as Casters could catch on thick carpet
pile and possibly cause breakage to lower corner posts of crib.
A .
PRING SSEMBLY
W
B
W
S
TTACHMENT OF PRING TO
securely as shown. (After Socket Head Shoulder Screws K
H
Z
I
ENLARGED VIEW
First, slip the (4) Bracket Caps B
C .
RIB
Brackets B attached to Spring W
Y
B
I
W
B
K
K
B B
W
G
W
After tightening securely,
loosen 3 turn on all Screws I
so that the Spring Mounting
Brackets B will be loose
enough to slide freely in their
mounting slots.
B onto the ends of the Spring Mounting
as shown. (Lower Dropside X
B
Z
Three
Adjustable
Heights
Make sure Socket Head Shoulder
Screw K tightens securely against
the metal threaded insert.
K
B
ENLARGED VIEW
NOTE: After Screw K is
tightened, you will notice the
Spring Mounting Brackets B
are able to move freely on the
Socket Head Shoulder
B B
Screw K. This is normal.
A and Footboard Z . Caster design may vary according
LH01796:12/00
B
I
I
B
before
are tightened down, you will
Z
Corner post of Z
