Child Craft Soho F34001 Manual

4-in-1 convertible crib
Hide thumbs

Advertisement

Table of Contents

5216 Portside Dr., Medina, OH 44256 USA • PH: 1 330.722.5033 • FAX: 1 330.722.5037
THIS IS THE ASSEMBLY INSTRUCTIONS FOR CRIBS SOLD IN THE UNITED STATES
FOR CUSTOMER SERVICE CALL
1-877-716-2757
(outside of U.S. 330-722-5033). DO NOT CALL
RETAILER OR RESELLER FOR SERVICE
AS THEY ARE NOT AUTHORIZED TO
RESOLVE ANY SERVICE ISSUES.
FOR WARRANTY AND FEDERAL SAFETY STANDARD
COMPLIANCE CERTIFICATES,
PLEASE VISIT OUR WEBSITE AT
www.childcraftbaby.com

ASSEMBLY ASSISTANCE

IMPORTANT: retain for future reference read
carefully.
Foundations strives for the highest quality in our
products but occasionally a missing part or problem
can occur during assembly.
If any parts are missing or broken or you need
assistance with assembly, DO NOT return the
product to your dealer. Go to our website at
www.childcraftbaby.com or call Foundations
for assistance at 1-877-716-2757 (U.S. Only) or
1-330-722-5033 (Monday through Friday, 9:00 a.m.–
4:00 p.m. Eastern Time). Please have the model
number and manufacture date available when you
call or write us at:
Foundations, 5216 Portside Dr., Medina, OH. 44256

ASSEMBLY INSTRUCTIONS

• Adult assembly required.
• Read all instructions BEFORE assembly and USE
of product.
• Unpack carton, remove packing materials,
including poly bag. Identify and check all parts.

SUGGESTED TOOLS

#2 Medium Straight Screwdriver
Foundations Worldwide, Inc.
www.childcraftbaby.com
Soho
4-in-1 Convertible Crib
™
Models Covered: F34001
KEEP INSTRUCTIONS FOR FUTURE USE

Assembled as Crib

Assembled as Toddler Bed
Record the information for your product here:
Model number:
Manufacture date:
PO number:
1
.
AB20064_G3
AB20064_G4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Soho F34001 and is the answer not in the manual?

Questions and answers

Related Manuals for Child Craft Soho F34001

Summary of Contents for Child Craft Soho F34001

  • Page 1 Foundations Worldwide, Inc. 5216 Portside Dr., Medina, OH 44256 USA • PH: 1 330.722.5033 • FAX: 1 330.722.5037 www.childcraftbaby.com Soho 4-in-1 Convertible Crib ™ Models Covered: F34001 KEEP INSTRUCTIONS FOR FUTURE USE THIS IS THE ASSEMBLY INSTRUCTIONS FOR CRIBS SOLD IN THE UNITED STATES FOR CUSTOMER SERVICE CALL 1-877-716-2757 (outside of U.S.

  • Page 2: Parts List

    PARTS LIST Part Number Quantity Part Description A. Long Side Assembly 22303067 B. Long Headboard Assembly 22303068 C. Head - Foot Assembly 22303046 D. Spring 11201023 E. Leg Assembly 22303049 F. Toddler Bed Rail 22303056 G. Toddler Post Headboard 22303063 H.
  • Page 3 STEP 1 Construct Long Headboard Assembly to Head-Foot Assembly: Fill unused holes in Long Headboard Assembly with Connector Nuts (N) and Allen Head Bolts (L). Align Long Headboard Assembly (B) with Head-Foot Assembly (C) making sure the suffocation label on bottom rail of (C) is facing out.
  • Page 4 STEP 3 Add Mattress Spring to crib. There are 3 positions for the Spring (D) shown as (1), (2) and (3). Refer to warning section to determine appropriate height for the intended child. The position must be the same as for all the brackets attached to the crib.
  • Page 5 STEP 5 Assemble Leg Assembly to crib. Align Leg Assemblies (E) with holes in bottom of Long Side Assembly (A) and Long Headboard Assembly (B). Insert Allen Head Bolts (K) through Leg Assemblies (E) into Long Side Assembly (A) and Long Headboard Assembly (B). Tighten all Bolts securely.
  • Page 6 Toddler Bed Toddler bed conversion: Follow assembly instructions up to and including Step 3. Spring (D) should be assembled and installed in the lowest position as shown in Step 3. If the Long Side Assembly (A) is in place it must be removed.
  • Page 7 WARNING WARNINGS (For Toddler Bed) WARNING WARNING INFANTS HAVE DIED IN TODDLER BEDS FROM ENTRAPMENT. Openings in and between bed parts can entrap head and neck of a small child. NEVER use bed with children younger than 15 months. ALWAYS follow assembly instructions.
  • Page 8 Full Size Bed Configuration This Crib is designed to convert into a full size bed headboard. The following parts needed are not provided by Foundations but may be purchased from a furniture/ bedding store and hardware store. S. Full size Hollywood style Bed Frame. T.
  • Page 9 CAUTION ANY MATTRESS USED IN THIS CRIB SHALL BE AT LEAST • 27 1/4 BY 51 5/8 IN. WITH A THICKNESS NOT EXCEEDING 6 IN. IF YOUR CRIB IS DESIGNED TO CONVERT TO A TODDLER BED, THE MATTRESS MUST BE AT LEAST 4 IN. (100 MM ) THICK.
  • Page 10 WARNING FAILURE TO FOLLOW THESE WARNINGS AND THE ASSEMBLY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: WARNING Infants can suffocate on soft bedding. NEVER add a pillow or comforter. NEVER place additional padding under an infant. • Read all instructions before assembling crib. Keep instructions for future use. A pouch is attached to the crib for permanent storage of the instructional literature.
