Note:
The Top Box mounting kits detailed above must only be used with the Triumph Accessory Top Box Kit
A9508192.
Thank you for choosing this Triumph genuine accessory kit. This accessory kit is the product of Triumph's use of
proven engineering, exhaustive testing, and continuous striving for superior reliability, safety and performance.
Completely read all of these instructions before commencing the installation of the accessory kit in order to
become thoroughly familiar with the kit's features and the installation process.
These instructions should be considered a permanent part of your accessory kit, and should remain with it even
if your accessory-equipped motorcycle is subsequently sold.
Publication part number 9900839 issue 3
© Triumph Designs Ltd. 2018
Accessory Fitting Instructions
Top Box Mounting Kit, Black
Models Affected
Street Twin, Street Scrambler
Bonneville T100 and Bonneville T100 Black from VIN 759204,
Bonneville T120, Bonneville T120 Black
Top Box Mounting Kit, Graphite
Models Affected
Street Twin, Street Scrambler
Top Box Mounting Kit, Chrome
Models Affected
Bonneville T100 and Bonneville T100 Black from VIN 759204,
Bonneville T120, Bonneville T120 Black
1 of 10
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the A9758306 and is the answer not in the manual?

Questions and answers

Summary of Contents for Triumph A9758306

  • Page 1 The Top Box mounting kits detailed above must only be used with the Triumph Accessory Top Box Kit A9508192. Thank you for choosing this Triumph genuine accessory kit. This accessory kit is the product of Triumph's use of proven engineering, exhaustive testing, and continuous striving for superior reliability, safety and performance.
  • Page 2 Parts supplied: A9758306, A9758307 Mounting rack 1 off Lock nut, M6 4 off Screw, M8 x 20 mm 2 off Square washer 4 off Washer, M8 2 off Mounting platform 1 off Bolt, M8 x 16 mm 4 off Cover plate...
  • Page 3 Parts supplied: A9758308, A9758309 Mounting rack 1 off Screw, M6 x 25 mm 2 off Screw, M8 x 20 mm 2 off Retaining clip 1 off Washer, M8 2 off 10. Square washer 4 off Bolt, M8 x 16 mm 4 off Mounting platform 1 off...
  • Page 4 Triumph Genuine Accessories, applicable are listed at the start of the instruction. always refer to the instructions supplied with the They should not be fitted to any other Triumph respective accessory kit. model or to any other manufacturer’s motorcycle.
  • Page 5 Collect the mounting rack from the kit and Loosely fit the four M8 x 16 mm bolts from the kit carefully feed the front of the rack over the rear to the rear mounting rack fixing points, as mudguard and inside the motorcycle frame past shown.
  • Page 6 Reconnect the battery, positive (red) lead first Remove the four rear mudguard fixings leaving and tighten the battery terminals to 4.5 Nm. the flanged sleeves in place. Discard the fixings. Carefully lower the rear mudguard to rest on the 10. Refit the seat, as described in the Owner’s rear tyre.
  • Page 7 Loosely fit the four M8 x 16 mm bolts from the kit Caution to the mounting rack fixing points, as shown. Care should be taken to ensure the mounting rack does not contact any part of the motorcycle frame or rear mudguard when it is positioned over the mudguard and inside the frame.
  • Page 8 Refit the rear mudguard using the new screws Mounting Platform Installation provided in the kit. Fit the M6 x 25 mm screws to the two rear fixing positions and the M6 x 20 mm Street Twin and Street Scrambler Models screws to the two front fixing positions.
  • Page 9 All Models Collect the cover plate from the top box mounting kit. Align the location tangs on the Fit the four square washers from the top box cover plate with the recess points on the mounting kit into the mounting platform fixing mounting platform and clip the cover plate onto point recesses.
  • Page 10 Warning motorcycle, which may result in loss of motorcycle control and an accident. Only operate this Triumph motorcycle at high speed in closed-course, on-road competition or on closed- course racetracks. High-speed operation should Warning only be attempted by riders who have been...
