- Page 3 Thank you for choosing Newline collaboration touch screen. The symbol of the crossed out wheeled bin indicates this product should not be placed in municipal waste. Instead, dispose of waste equipment by handing it over to a designated collection point for the recycling of electrical and electronic equipment.
-
Page 4: Symbol Conventions
Symbol Conventions Symbols are used in this document to indicate operations that require special attention. The symbols are defined as follows: Used to supplement explanations or descriptions of current operations. NOTE Used to signal equipment or environmental safety warnings. Not taking heed of said warnings could result in potential danger, equipment CAUTION damage, data loss, reduced equipment performance, or other... -
Page 5: Safety Instruction
Safety Instruction For your safety, please read the following instructions before you use the product. Improper operations may cause severe injury or property damage. Please refrain from repairing the product on your own. WARNING If major failures occur, disconnect the product from power source immediately. - Page 6 WARNING Do not install the product in an improper place. Do not install the product in humid places, such as the bathroom, the shower ● room, near windows, or outdoor environments that experience rain, snow or other harsh weather. Avoid installation near hot spring vapor. The preceding environments may cause faults in the product or electric shock under extreme conditions.
- Page 7 CAUTION Keep away from the product when using a radio. The product complies with the international EMI standard regarding prevention of radio interference. However, interference may still exist and cause noises to the radio. If noise occurs in the radio, try the following solutions. Adjust the direction of the radio antenna to avoid the interference from the product.
-
Page 8: Product Overview
Product Overview CAUTION There are electronic components in the plastic parts at the bottom of the product. If the plastic parts are damaged, the camera or the product may malfunction. To avoid damage to the plastic parts, please pay attention to the following: ●... -
Page 9: Front Buttons
Touch screen Microphone Speaker Light sensor Camera Rear port 1 Power button Camera indicator Rear port 2 IR receiver Power socket Internal PC Bottom plastic part Power switch Bar interface Front Buttons Button Function description Power on/off. In power-on state, press it to enter the sleep state, ●... - Page 10 Network reset button...
- Page 11 Name Function description Microphone input port. Audio input port, used in combination with “VGA In”. Audio In VGA signal input port. Used in combination with “USB 3.0 Touch” to operate the PC in touch VGA In mode. HD signal input port 1. Used in combination with “USB 3.0 Touch”...
-
Page 12: Remote Control Buttons
Remote Control Remote Control Buttons ◆ Buttons Function Buttons Function Lock/unlock screen touch Power on/off. function. Enter/exit the standby Switch to HDMI1 signal Standby mode. source. Switch to HDMI2 signal Mute or unmute. source. Microphone switch. Takeascreenshot. Up/Down/Left/Right SwitchtoVGAsignal selection button. source. - Page 13 Remote Control Usage Instructions ◆ CAUTION To avoid potential malfunctions, please read the following instructions and use the remote control appropriately. ● Do not drop or smack the remote control. ● Do not spill liquids on the remote control. ● Do not place the remote control on a wet object. ●...
-
Page 14: Installation
Installation Precautions Environment ◆ Keep Temperature Below 120 F ( ≤50 c) Keep Away From Indoor Use Only Combustible Gas Direction ◆ Hang the Product Horizontally No Vertical Installation Do Not Install Tilted Do Not Lay Flat... -
Page 15: Vertical Installation
Load Bearing You can select moveable installation or wall mounting according to your own needs. Wall mounting can help users significantly reduce occupied space. When using moveable installation, use the mobile stand specified by the manufacturer. If you use a self-made mounting bracket, its carrying capacity should be at least 4 times the actual carrying weight. - Page 16 Ventilation Distance from mounting surface (mm) Left and right sides Bottom Rear CAUTION ● In addition to the above requirements, the area of the bottom, side and top vents should not be less than 50% of the sealing area and good air circulation must be maintained when the product is embedded in the wall and a cabinet.
- Page 17 Step 1: (Optional) Unscrew the M3 screws by hand to remove the internal PC shielding cover. Note This step is optional and suitable for models with the internal PC shielding cover. Step 1: Push the internal PC horizontally into the interface port. Step 3: Pass the fixing screws through the upper and lower lugs and tighten them.
-
Page 18: Power On/Off
Power On/Off Power On Step 1:Use AC power (100V~240V, 50Hz/60Hz) as the product power source. Make sure the power plug fully inserted and that the ground wire of the outlet is properly connected. Step 2: Turn on the rocker switch (on the rear side of the screen, next to the power socket) after a power source has been connected. - Page 19 CAUTION ● When the product enters sleep mode or shutdown, the system will first detect whether the internal PC is turned off. If not, it first turns off the internal PC before it enters sleep mode or shutdown. ● Please shut down the product before disconnecting the power source or it may damage the machine.
- Page 20 For more product information, please visit https://newline-interactive.com National Service Hotline: +1 888 233 0868 The company is committed to product updates and technical improvements. The technical parameters and specifications are subject to change without prior notice. The pictures in this manual are for reference only.
