6. Select Use the following IP Address for static IP addressing and fill in the details as
shown in Figure
For TCP/IPv4 you can use any IP address in the range 192.168.1.1 to 192.168.1.255
(excluding 192.168.1.39) that is provided by your IT department.
7. Click OK.
8. Click Close.
Connecting the Ethernet Port via a Network Hub or Switch
You can connect the Ethernet port of the
using a straight-through cable with RJ-45 connectors.
Control Configuration via Ethernet Port
To control several units via Ethernet, connect the Master unit (Device 1) via the Ethernet port
to the Ethernet port of your PC. Use your PC provide initial configuration of the settings (see
Connecting VS-44H2A via ETHERNET Port
VS-44H2A – Connecting VS-44H2A
Figure 7: Internet Protocol Version 6 Properties Window
8.
Figure 8: Internet Protocol Properties Window
VS-44H2A to the Ethernet port on a network hub or
on page 8).
