  • Page 3: Table Of Contents

    Contents 1. INTRODUCTION ...5 Features...5 Software Features ...6 Package Contents ...8 Ethernet Switching Technology ...9 2. HARDWARE DESCRIPTION...11 Physical Dimension ...11 Front Panel ...11 LED Indicators ...11 Rear Panel...12 Desktop Installation ...12 Rack-mounted Installation ...13 3. NETWORK APPLICATION...15 4. CONSOLE MANAGEMENT...18 Login in the Console Interface...18 Main Menu ...19 Function Description ...21...
  • Page 4 Trunk Configuration...30 Port Mirroring Configuration...31 VLAN Configuration ...33 VLAN Configure ...33 Create VLAN Group...34 Edit / Delete VLAN Group...37 Group Sorted Mode ...38 Priority Configuration...40 MAC Address Configuration ...41 Static MAC Address...42 Filtering MAC Address...43 Misc Configuration ...45 Protocol Related Configuration ...48 STP ...48 STP Setup...49 System Configuration ...50...
  • Page 5 TFTP Configuration...69 Update Firmware ...70 TFTP Restore Configuration...70 TFTP Backup Configuration ...71 X-modem Upgrade ...72 5. WEB-BASED MANAGEMENT ...74 About Web-based Management...74 Preparing for Web Management ...74 Online Help ...75 System Login ...75 Port status...76 View the Port Information ...77 Port Statistics...78 Administrator...79 IP Address ...80...
  • Page 6 Per Port Configuration... 104 Port Mirroring... 105 SNMP Management ... 107 Security Manager ... 108 802.1X ... 110 System Configuration... 110 Per port Configuration ... 110 Misc Configuration ... 112 TFTP Update Firmware ... 112 Configuration Backup ... 113 TFTP Restore Configuration ... 113 TFTP Backup Configuration ...

  • Page 7: Introduction

    1. Introduction The TEG-S3000i chassis switch is a modular switch that can be used to build high-performance switched workgroup networks. This switch is a store-and-forward device that offers low latency for high-speed networking. The Switch is designed for workgroup, department or backbone computing environments.

  • Page 8: Software Features

    High back-plane bandwidth 8.8Gbps Support IEEE802.3ad Port trunk with LACP Broadcast storm filter supported Stack management via one IP address, easy management by Web GUI IGMP support for Multi Media application Support IEEE 802.1p class of service Port security supported Port bandwidth control supported Support IEEE 802.1d Spanning tree protocol Supports GVRP function...
  • Page 9 RFC 1157 SNMP, RFC 1213 MIB II, RFC 1643 Ethernet RFC Standard like, RFC 1493 Bridge MIB, RFC 1757 RMON 1, RFC 1215 Trap, RFC 2674 VLAN MIB, private MIB Cold start, link down, link up, authorization fail, fan fail trap. SNMP Trap Trap station up to 3 Support IEEE802.3ad with LACP function and provide...

  • Page 10: Package Contents

    RADIUS server. 802.1x DHCP DHCP Client Packet filter Broadcast storm Package Contents Unpack the contents of the checklist below. TEG-S3000i chassis switch Power Cord Four Rubber Feet RS-232 cable Reject Accept Authorize Disable TEG-S3000i chassis switch and verify them against the...

  • Page 11: Ethernet Switching Technology

    Rack-mounted kit User Guide TEG-S3000i chassis switch Rack-mounted Kit Compare the contents of your TEG-S3000i chassis switch package with the standard checklist above. IF any item is missing or damaged, please contact your local dealer for service. Ethernet Switching Technology...
  • Page 12 Auto-negotiation regulates the speed and duplex of each port based on the capability of both devices. Flow-control allows transmission from a 100Mbps node to a 10Mbps node without loss of data. Auto-negotiation and flow-control may need to be disabled when networking with legacy equipment.

  • Page 13: Hardware Description

    The TEG-S3000i chassis switch physical dimension is 440mm(W) x 280mm(D) x 44mm(H). Front Panel The Front Panel of the TEG-S3000i chassis switch consists of 3 10/100Mbps module slots. One Gigabit module slot is located at the rear-panel of the switch. LED Indicators The LED Indicators give real-time, status information of system operation.

  • Page 14: Rear Panel

    A module slot, 3-pronged power plug, 2 fans, a power switch button, and a console port are located at the rear Panel of the TEG-S3000i chassis switch as shown in Figure 2-1. The Switch will work with AC power in the range of 100-240V AC, 50-60Hz.

  • Page 15: Attaching Rubber Feet

    Switch from shock/vibration. Rack-mounted Installation The TEG-S3000i chassis switch comes with a rack-mounted kit that can be mounted in an EIA standard size, 19-inch Rack. The Switch can be placed in a wiring closet with other equipment.
  • Page 16 power indicator on the front panel to see if power is properly supplied.

  • Page 17: Network Application

    This section provides you a few samples of network topology in which the Switch is used. In general, the TEG-S3000i chassis switch is designed as a segment switch. That is, with its large address table (8000 MAC address) and high performance, it is ideal for interconnecting networking segments.

  • Page 18: Stacking Workgroup

    Stacking Workgroup Stackable technology unites up to eight individual stackable switches into a single logical unit using cables and stacking software. The stack behaves as a single switching unit that is managed by a master switch. The master switch automatically creates and updates all the switching tables.

  • Page 19: Connecting To The Switch

    The stackable switch (Master) Cable connection (Cat. 5 cable) The stackable switch (Slave 01) Cable connection (Cat. 5 cable) The stackable switch (Slave 02) Can units up to 8 stackable switches The stackable switch (Slave 08) Figure 3-2. A stacking workgroup application Connecting to the Switch The Console port is a female DB-9 connector that enables a connection to a PC or terminal for monitoring and configuring the Switch.

  • Page 20: Console Management

    4. Console Management Login in the Console Interface When the connection between the Switch and PC is ready, turn on the PC and run a terminal emulation program or Hyper Terminal and configure its communication parameters to match the following default characteristics of the console port: Baud Rate: 9600 bps Data Bits: 8 Parity: none...

  • Page 21: Main Menu

    Console login screen Main Menu There are five selections as follow. Status and Counters: Show the status of the switch. Switch Static Configuration: Configure the switch. Protocol Related Configuration: Configure the protocol function. System Reset Configuration: Restart the system or reset switch to default configuration.
  • Page 22 Main menu line interface Control Key description: The control keys provided in all menus: Tab: Move the cursor to next item. Backspace: Move the cursor to previous item. Enter: Select item. Space: Toggle selected item to next configure or change the value. Esc: to exit the current action mode.

  • Page 23: Function Description

    Function Description Status and Counters In Status and Counters, you can view Port status, counters, and configure system parameter. You can press the “Tab” or “Backspace” to choose item, and press “Enter” key to select item. Port Status It displays status of port. Select the <Previous Page> action to display previous page. And, select the <Next page>...

  • Page 24: Port Counters

    Speed Duplex: display port duplex mode. State: The port current status. Negotiation: display the auto negotiation status. FC: display the flow control status is “enable” or “disable”. BP: display backpressure status. Bandwidth In/Out: display bandwidth In/out control status. Priority: display the port priority status. Security: display the port security status.

  • Page 25: System Information

    Port counter information interface System Information It displays the system parameter. System Name: the name of device. System Location: where the device is located. System Description: the name of device type. Firmware Version: the switch’s firmware version. Kernel Version: the system kernel software version. Hardware Version: the switch’s Hardware version.
  • Page 26 System Information interface...

  • Page 27: Switch Static Configuration

    Switch Static Configuration In Switch Static Configuration, it has 8 main functions – Administration, Port, Trunk, Port Mirroring, VLAN, Priority, MAC Address, and Misc Configuration. Under each function, there are more sub-functions. We will describe in following paragraph. Switch Configuration interface Administration Configuration In Administration Configuration, you can configuration system parameter, IP, login username and password.

  • Page 28: Device Information

    Administration Configuration main interface Device Information You can configure the device information. Select <Edit> action to configure. Name: assign the name for the switch. Description: a short description for the switch. Location: the switch location, ex: Taipei. Contact: the contact person or information. Select <Save>...

  • Page 29: Ip Configuration

    Device Information interface IP Configuration You can configure the IP for this switch. The system has the default IP address. You can re-configure or use the default value. 1. Select the <Edit> 2. DHCP Client: disable or enable the DHCP client function. 3.

  • Page 30: User Name Configuration

    IP Configuration interface User Name Configuration You can change the console and web management login user name. 1. Select the <Edit> 2. Enter the new user name 3. Select the <Save>...

  • Page 31: Password Configuration

    User Name Configuration interface Password Configuration You can change the console and web management login password. 1. Select the <Edit> 2. Old Password: enter the old password. 3. New Password: enter the new password. 4. Enter Again: reenter the new password for confirmation. 5.

  • Page 32: Trunk Configuration

    Negotiation: set auto negotiation status of port. Speed/Duplex: set the port link speed and duplex mode. FC: enable or disable Flow control function (Flow control for full duplex link mode). BP: enable or disable Back Pressure function (Backpressure for half duplex mode).

  • Page 33: Port Mirroring Configuration

    to Static. 5. Save the configuration by selecting <Save>. Trunk Configuration interface Port Mirroring Configuration The port mirroring is a method for monitor traffic of switched networks. The specific port can monitor traffic through the mirror ports. The monitored ports in or out traffic will be duplicated into monitoring port.
  • Page 34 3. Analysis port: Set the destination port of mirroring packet. All of the packets of mirroring port will be duplicated and sent to Analysis port. 4. Port State: use “Space” key to mark the port that wanted to be mirrored. 5.

  • Page 35: Vlan Configuration

    VLAN Configuration You can configure VLAN in VLAN Configuration. There are four functions in VLAN Configuration mode: VLAN Configuration, Create a VLAN Group, Edit/Delete VLAN Group and Group Sorted Node. Follow the below description to configure VLAN. VLAN Configuration Main interface VLAN Configure Before starting to configure VLAN, you must select the VLAN mode in VLAN Configure function.

  • Page 36: Create Vlan Group

    this port’s configured VID. Acceptable Frame type: It matches that Ingress Filtering Rule 2 on web. Drop untagged frame. Press “Space” key to select drop or forward the untagged frame. 3. Select <Save> to save the configuration. Create VLAN Group Create Port-Based VLAN Select <Edit>.
  • Page 37 Select <Save> to save the configuration. NOTE: If you had configured the trunk groups, you can see it (ex: Trunk1, Trunk2…) in the port list. You also can configure the trunk group as the VLAN member. Create VLAN Group: PortBase interface Create 802.1Q VLAN Enable security VLAN setting: select to enable or disable security VLAN group.
  • Page 38 Create VLAN Group: 802.1Q interface Select <Edit>. VLAN Name: Type a name for the new VLAN, ex: VLAN01. VLAN ID: Type a VID (between 1~4094). The default is 1. There are 256 VLAN groups to provided configure. Protocol VLAN: Press “Space” key to choose protocols type. Member: Press “Space”...

  • Page 39: Edit / Delete Vlan Group

    Create VLAN Group: 802.1Q interface Edit / Delete VLAN Group User can edit or delete a VLAN group. Select <Edit> or <Delete> action. Select the VLAN group that you want to edit or delete, then press enter. In <Edit> action, user can modify the member port and remove some member ports from this VLAN group.

  • Page 40: Group Sorted Mode

    Edit/Delete a VLAN Group interface (802.1Q VLAN group) Group Sorted Mode You can select VLAN groups sorted mode: (1) Name (2) VLAN ID. In the Edit/Delete a VLAN group page will display the result. Select <Edit> Use “Space” key to select the sort mode Select <Save>...
  • Page 41 Group Sorted Mode interface...

  • Page 42: Priority Configuration

    Priority Configuration You can configure port priority level. There are 0~7-priority level can map to high or low queue. Select <Edit>. Press “Space” key to select the priority level mapping to high or low queue. Qos Mode: select the mode to process incoming packets. First comes first service: the switch will process the packet that is coming first.

  • Page 43: Mac Address Configuration

    Priority Configuration interface MAC Address Configuration When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.

  • Page 44: Static Mac Address

    MAC Address Configuration interface Static MAC Address Add the Static MAC Address You can add static MAC address in switch MAC table. Select <Add> <Edit> key to add the static MAC address. MAC Address: Enter the MAC address of the port that should permanently forward traffic, regardless of the device network activity.

  • Page 45: Filtering Mac Address

    Add Static MAC Address interface Edit static MAC address Select <Edit>. Choose the MAC address that you want to modify and then press “Enter”. Press <Edit> key to modify. Press “ESC” to go back action menu line. Select <Save> to save all configure value. Delete static MAC address Select <Delete>...
  • Page 46 Filtering MAC Address interface Add the Filtering MAC Address Select <Add> <Edit> key to add the static MAC address. MAC Address: Enter the MAC address that you want to filter. VLAN ID: enter the Mac address’ VLAD ID, if the Mac address belongs to any VLAN group.

  • Page 47: Misc Configuration

    Add Filtering MAC Address interface Edit Filtering MAC address Select <Edit> key to modify a static Filtering address. Choose the MAC address that you want to modify and then press “Enter”. Select <Edit> key to modify. Press “ESC” to go back action menu line Select <Save>...
  • Page 48 provides you can centralize the control of the switch in the network. For the manager personal, he/she can save the time and easily on switches controlling. MAC Address Ageing Time: MAC address table refresh time setting. Type the number of seconds that an inactive MAC address remains in the switch’s address table.
  • Page 49 stacking group. You can only assign one switch to be the master switch in one stacking group. When the stacking group is set up, the master switch will control all switches in the stacking group. Slave: besides the master switch, rest of the switches are called slave switch in stacking group.

  • Page 50: Protocol Related Configuration

    Protocol Related Configuration You can configure Spanning Tree Protocol, SNMP, LACP, IGMP/GVRP, and 802.1x in Protocol Relate Configuration section. Protocol Relate Configuration interface Spanning tree is a link management protocol that provides path redundancy while preventing undesirable loops in the network.

  • Page 51: Stp Setup

    STP Configuration interface STP Setup You must enable Spanning Tree function before configure STP function. Select <Edit> Use “Space” key to select the option. Select <Save>.

  • Page 52: System Configuration

    System Configuration You can configure the STP system parameter after enable the STP function. view spanning tree information about the Root Bridge on the left. Select <Edit> Priority: assign path priority number. Max Age: the maximum path age Hello Time: the time that controls switch sends out the BPDU packet to check STP current status.

  • Page 53: Per Port Setting

    STP System Configuration interface Per Port Setting Select <Edit>. Path Cost: specifies the path cost of the port that switch uses to determine which port are the forwarding ports. Priority: This is mean port priority; you can make it more or less likely to become the root port.

  • Page 54: Snmp

    Per Port Setting interface SNMP To define management stations as trap managers and to enter SNMP community strings. You can also define a name, location, and contact person for the switch.
  • Page 55 SNMP Configuration interface...

  • Page 56: Snmp System Options

    SNMP System Options Press <Edit>. Name: assign a name for the switch. Contact: Type the name of contact person or organization. Location: Type the location of the switch. Press “ESC” goes back action menu line. Press <Save> to save configure value. SNMP System Options interface Community Strings Add Community Strings...
  • Page 57 MIB-object information. Read/Write: Read write, enables requests accompanied by this string to display MIB-object information and to set MIB objects. Add Community Strings interface Edit Community Name Select <Edit> Choose the item that you want to modify and then press “Enter”. Community Name: type the new name.

  • Page 58: Trap Managers

    Edit Community Strings interface Delete Community Name Select <Delete>. Choose the community name that you want to delete and then press “Enter”. When pressing “Enter” will complete deletion. Trap Managers A trap manager is a management station that receives traps, the system alerts generated by the switch.
  • Page 59 Add the trap manager Select <Add> <Edit> to add the trap manager. IP: enter the IP address of trap manager. Community Name: enter the community string. Press “ESC” go back to actions menu line Select <Save> to save all configure. Trap Managers interface...

  • Page 60: Lacp

    Add Trap Manager interface Delete Trap Manager Select <Delete> Choose the trap manager that you want to delete and then press “Enter”. When pressing “Enter” will complete deletion. LACP The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems on a link to allow their Link Aggregation Control instances to reach agreement on the identity of the Link Aggregation Group to which the link belongs, move the link to that Link Aggregation...

  • Page 61: Working Ports Setting

    LACP Configuration interface Working Ports Setting Select <Edit> Group: Display the trunk group ID. LACP: Press “Space” key to enable or disable LACP (Link Aggregation Control Protocol) support. When LACP enable, the group is LACP static trunk group. When LACP disable, the group is local static trunk group. Working Port Num: The max number of ports can be aggregated at the same time.

  • Page 62: Lacp State Activity

    LACP Working Ports configuration interface LACP State Activity Select <Edit> Use “Space” key to select the Port State Activity. Active: The port automatically sends LACP protocol packets. Passive: The port does not automatically send LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. Select <Save>.

  • Page 63: Group Status

    LACP State Activity configuration interface Group Status When you setting trunk group, you can see the relation information in here. LACP Group State interface...

  • Page 64: Igmp/Gvrp

    IGMP/GVRP You can enable or disable the IGMP/GVRP (GARP VLAN Registration Protocol). Select <Edit> Use “Space” key to change the value Select <Save> IGMP/GVRP Configuration interface 802.1x...

  • Page 65: 802.1X Setup

    802.1x Configuration interface 802.1x Setup Select <Edit> Use “Space” key to Enable or Disable the 802.1x. Select <Save>...

  • Page 66: System Configuration

    System Configuration After enabling the IEEE 802.1X function, you can configure the parameters of this function. Select <Edit> Radius Server IP: set the Radius Server IP address. Shared Key: set an encryption key for using during authentication sessions with the specified radius server. This key must match the encryption key used on the Radius Server.

  • Page 67: Per Port Configuration

    802.1x System Configuration interface Per Port Configuration You can configure 802.1x authentication state for each port. The State provides Disable, Accept, Reject and Authorize. Use “Space” key change the state value.
  • Page 68 802.1x Per Port Setting interface...

  • Page 69: Misc Configuration

    Misc Configuration Select <Edit> Quiet period: set the period during which the port doesn’t try to acquire a supplicant. TX period: set the period the port wait for retransmit next EAPOL PDU during an authentication session. Supplicant timeout: set the period of time the switch wait for a supplicant response to an EAP request.

  • Page 70: System Reset Configuration

    System Reset Configuration System Reset Configuration interface Factory Default Reset switch to default configuration. Press “Y”, switch will load default setting. After finished load default setting, switch will reboot automatically.

  • Page 71: System Reboot

    Factory Default interface System Reboot Reboot the switch in software reset. TFTP Configuration It provides user to update firmware or restore EEPROM value or upload current EEPROM value.

  • Page 72: Update Firmware

    TFTP Update Firmware interface Update Firmware It provides user uses TFTP to update firmware. 1. Start the TFTP server, and copy firmware update version image file to TFTP server. 2. Select <Edit>. 3. TFTP Server IP: type the IP of TFTP server. 4.

  • Page 73: Tftp Backup Configuration

    Start the TFTP server. Select <Edit>. TFTP Server IP: type the IP of TFTP server. Restore File Name: type the image file name. Press “ESC” back to action menu line. Select <Save>, it will start to download the image file. When save successfully, the image file download finished too.

  • Page 74: X-Modem Upgrade

    5. Press “ESC” back to action line. 6. Select <Save> key, it will start to upload the image file. 7. When save successfully, the image file upload finished too. 8. Restart switch. TFTP Backup Configuration interface X-modem Upgrade Before using X-modem upgrade, disconnect terminal and modify baud rate to 57600bps, then connect again.
  • Page 75 Select “send file" under Transfer menu from menu bar. Select "browse" button to select the path. Select "1K X-modem" of protocol and click "Send" button. After successfully upgraded the new firmware, please modify baud rate to 9600bps.

  • Page 76: Web-Based Management

    5. Web-Based Management This section introduces the configuration and functions of the Web-Based management. About Web-based Management Inside the CPU board of the switch exists an embedded HTML web site residing in flash memory. It offers advanced management features and allow users to manage the switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.

  • Page 77: Online Help

    Online Help You can click Help button when you have any configuration question during the configuring. System Login Launch the Internet Explorer. Type http:// and the IP address of the switch. Press “Enter”. The login screen appears. Key in the user name and password. The default user name and password is “...

  • Page 78: Port Status

    State: display port statuses “disable” or “enable”. “Unlink” will be treated as “off ”. Auto Negotiation: display the auto negotiation mode: auto/force/Nway-force. “Config” means the value that user configured. “Actual” means the current value of the port. TEG-S3000i chassis switch...

  • Page 79: View The Port Information

    Speed Duplex: display port connection speed. “Config” means the value that user configured. “Actual” means the current value of the port. Flow Control: Full: display the flow control status is “enable” or “disable” in full mode. “Config” means the value that user configured. “Actual” means the current value of the port.

  • Page 80: Port Statistics

    You can direct click the port on the Switch figure on the top of web page. Then, you will see the port information. Port information interface Port Statistics The following information provides a view of the current port statistic information. Click Clear button to clean all counts.

  • Page 81: Administrator

    Port Statistics Administrator In Administrator function, it provides the following functions: IP Configuration, Switch Settings, Console Port Information, Port Controls, Trunking, Forwarding and Filtering, VLAN Configuration, Spanning Tree, Port Mirroring, SNMP Management, Security Manager, and 802.1x Configuration.

  • Page 82: Ip Address

    Administrator interface IP Address User can configure the IP Settings and DHCP client function, than clicks Apply button. After reset the IP address, you must reboot the switch. IP configuration interface...

  • Page 83: Switch Setting

    Switch Setting In Switch setting, it has three parts of setting – Basic, Advance, and Misc Config. We will describe the configure detail in following. Basic Switch Settings In Basic Switch Setting, it displays the switch basic information. System Name: the name of switch. System Location: the switch physical location.

  • Page 84: Advanced Setting

    Switch basic setting interface Advanced Setting In Advanced setting, it has two sections – MAC Table Address Entry and Priority Queue Service. After the configuration, click Enable MAC address Aging Out: to enable the MAC address age out function. When it is disabling, the following configure item will not function. Age-out Time: fill in the number of seconds that an inactive MAC address remains in the switch's address table.
  • Page 85 Switch Advanced setting interface Priority Queue Service settings: select the priority queue service type. First Come First Service: the sequence of packets sent is depend on arrive order. All High before Low: the high priority packets sent before low priority packets. Weighted Round Ratio: select the preference given to packets in the switch's high-priority queue.

  • Page 86: Miscellaneous Setting

    Miscellaneous Setting Collisions Retry Forever: disable is in half duplex. If happen collision will retry 48 times and then drop frame. Enable is in half duplex. If happen collision will retry forever. Hash Algorithm: CRC Hash or Direct Map for MAC address learning algorithm IFG Compensation: Internal Packet Gap time compensation configure.
  • Page 87 a network: 2. IGMP needs to be enabled when the router’s IP address is not smaller than other switches in the subnet. This Router supports IGMP protocol, but IGMP has to be enabled, and the Router has to be the Querier. 1.
  • Page 88 3. The following topology must be set when the IP address of the switch is not the smallest in the subnet. The network will cause a multi-cast storm from the IGMP client report if it is in Auto mode. All switches must be in disable mode when the VOD server is configured for IGMP Querier.

  • Page 89: Console Port Information

    Console Port Information Console is a standard UART interface to communicate with Serial Port. User can use windows HyperTerminal program to link the switch. Please refer to Console Management Console login for detail steps. Console port information shows as follow: Bits per seconds: 9600 Data bits: 8 Parity: none...

  • Page 90: Trunking

    1Mbps, ingress rate is 500Kbps. The switch will perform flow control or Back Pressure to confine the ingress rate to meet the specified rate. In: fill in the port effective ingress rate. The valid range is 0 ~ 1000. The unit is 100K.

  • Page 91: Aggregator Setting

    Aggregation Group to which the link belongs, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner. Link aggregation lets you group up to eight consecutive ports into a single dedicated connection.

  • Page 92: Aggregator Information

    Trunking—Aggregator Setting interface Aggregator Information When you had setup the LACP aggregator, you will see relation information in here. Trunking – Aggregator Information interface...

  • Page 93: Aggregator Information State Activity

    Aggregator Information State Activity When you had setup the LACP aggregator, you can configure port state activity. You can mark or un-mark the port. When you mark the port and click state activity will change to Active. Opposite is Passive. Active: The port automatically sends LACP protocol packets.

  • Page 94: Forwarding And Filtering

    Forwarding and Filtering IGMP Snooping The switch support IP multicast, you can enable IGMP protocol on web management’s switch setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.

  • Page 95: Static Mac Address

    Static MAC Address When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
  • Page 96 Static MAC Address interface MAC filtering MAC address filtering allows the switch to drop unwanted traffic. Traffic is filtered based on the destination addresses. In MAC Address box, enter the MAC address that wants to filter. VLAN ID: If tag-based (802.1Q) VLAN are set up on the switch, in the VLAN ID box, type the VID to associate with the MAC address.

  • Page 97: Vlan Configuration

    MAC Filtering interface VLAN configuration A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.

  • Page 98: Port-Based Vlan

    VLAN Configuration interface Port-based VLAN Packets can go among only members of the same VLAN group. Note all unselected ports are treated as belonging to another single VLAN. If the port-based VLAN enabled, the VLAN-tagging is ignored. In order for an end station to send packets to different VLANs, it itself has to be either capable of tagging packets it sends with VLAN tags or attached to a VLAN-aware bridge that is capable of classifying and tagging the packet with different VLAN ID based on not only default PVID but also other information about the packet, such as the protocol.
  • Page 99 VLAN – PortBase interface Add>> Click to create a new VLAN group. Enter the VLAN name, group ID and select the members of VLAN group. Click Apply...
  • Page 100 Add PortBase VLAN interface You will see the VLAN displays.

  • Page 101: 802.1Q Vlan

    PortBase VLAN group list interface If the groups’ list is over one page, you can click groups. Delete button to delete unwanted VLAN. button to modify existing VLAN group. Edit 802.1Q VLAN Tagged-based VLAN is an IEEE 802.1Q specification standard. Therefore, it is possible to create a VLAN across devices from different switch venders.
  • Page 102 Basic Click button. Enable GVRP Protocol: check the check box to enable GVRP protocol. Group Name: assign a name for the new VLAN. VLAN ID: fill in a VLAN ID (between 2-4094). The default is 1. Protocol VLAN: choose the protocol type. Default is NONE. From the Available ports box, select ports to add to the switch and click button.
  • Page 103 Add 802.1q VLAN interface -1 Click Next . Then you will see the page as follow. Add 802.1q VLAN interface -1...
  • Page 104 To set the outgoing frames are VLAN-Tagged frames or untagged. Then click Apply Tag: outgoing frames with VLAN-Tagged. Untag: outgoing frames without VLAN-Tagged. Port VID: Configure port VID settings Port VLAN ID: enter the port VLAN ID. Ingress Filtering: Ingress filtering lets frames belonging to a specific VLAN to be forwarded if the port belongs to that VLAN.

  • Page 105: Spanning Tree

    802.1q VLAN – Port VLAN ID interface Spanning Tree The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1d) for avoiding loops in switched networks. When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. We are recommended that you enable STP on all switches ensures a single active path on the network.

  • Page 106: System Configuration

    Spanning Tree – System Configuration interface System Configuration You can view spanning tree information about the Root Bridge. You can view spanning tree status about the switch. You can modify STP state. After modification, click Priority: assign path priority number. Max Age: the maximum path age Hello Time: the time that controls switch sends out the BPDU packet to check STP current status.

  • Page 107: Port Mirroring

    Assign the Path Cost. The value range is from 1 to 65535. Assign the port priority value. The value range is from 0 to 255. The lowest value has higher priority. Click button. Apply SPT – Per Port Configuration interface Port Mirroring The Port mirroring is a method for monitor traffic in switched networks.
  • Page 108 ports will be duplicated into mirror port. Port Mirroring State: set mirror mode: Disable, RX, TX, and Both. Analysis Port: It’s mean mirror port can be used to see all monitor port traffic. You can connect mirror port to LAN analyzer or Netxray. Monitor Port: the ports you want to monitor.

  • Page 109: Snmp Management

    SNMP Management The SNMP is a Protocol that governs the transfer of information between management and agent. The switch supports SNMP V1. You can define management stations as trap managers and to enter SNMP community strings. You also can define a name, location, and contact person for the switch. Fill in the system options data, and then click Apply to update the changes.

  • Page 110: Security Manager

    Community strings Serve as a password between trap manager and switch. String: fill the name of string. RO: Read only. Enables requests accompanied by this string to display MIB-object information. RW: Read write. Enables requests accompanied by this string to display MIB-object information and to set MIB objects.
  • Page 111 Security Manager interface...

  • Page 112: 110

    802.1X When enabling the IEEE 802.1X function, you can configure the parameters of this function. System Configuration Radius Server IP: set the Radius Server IP address. Server Port: set the UDP destination port for authentication requests to the specified Radius Server. Accounting Port: set the UDP destination port for accounting requests to the specified Radius Server.
  • Page 113 Reject: the specified port is required to be held in the Unauthorized state. Accept: the specified port is required to be held in the Authorized state. Authorized: the specified port is set to the Authorized or Unauthorized state in accordance with the outcome of an authentication exchange between the Supplicant and the authentication server.

  • Page 114: Misc Configuration

    Misc Configuration Quiet period: Set the period during which the port doesn’t try to acquire a supplicant. TX period: Set the period the port waits to retransmit next EAPOL PDU during an authentication session. Supplicant timeout: Set the period of time the switch waits for a supplicant response to an EAP request.

  • Page 115: Configuration Backup

    server. TFTP Server IP Address: fill in your TFTP server IP. Firmware File Name: the name of firmware image. Click Apply Configuration Backup In Configuration Backup, you can restore the backup configuration into the switch. Also, you can backup the configuration to TFTP server. TFTP Restore Configuration You can restore EEPROM value from TFTP server, but you must put back image in TFTP server, switch will download back flash image.

  • Page 116: Tftp Backup Configuration

    TFTP Restore Configuration interface TFTP Backup Configuration You can save current EEPROM value from the switch to TFTP server, then go to the TFTP restore configuration page to restore the EEPROM value. TFTP Server IP Address: fill in the TFTP server IP Backup File Name: fill the file name Click Apply...

  • Page 117: System Reboot

    Default Gateway: 192.168.16.254 Subnet mask: 255.255.255.0 The other setting value is back to disable or none. Click button to reset switch to default setting. Default System Reboot Reboot the Switch in software reset. Click Panel List Display the switch panel GUI. When the switch is in stacking status, it display the slaves panel GUI.

  • Page 118: Ip Stacking

    IP Stacking This function allows switch to stack up to 8 stackable switches as a unit group. When configuring the stacking function, beware the following points. Any port on the switch can be used to stack. Before configuring the stacking function, make sure all stack switches are in the same network.
  • Page 119 Apply Click button to apply the configuration. When the master switch has configured, you will see the following screen. IP Stacking master switch configure finished interface After you have configured the stacking function, use Cat. 5 cable to connect each IP Stacking interface...
  • Page 120 switch in the stacking group. And wait for few minutes for the master switch to communicate and collect the data from the slave switches. Connect to the master switch through the Web. You will see the following screen display. Click any function in the menu bar of the master switch to configure the switch in the stacking group.
  • Page 121 Stacking group configuration interface...

  • Page 122: Troubleshooting

    6. Troubleshooting This section is intended to help you solve the most common problems on the TEG-S3000i chassis switch. Incorrect connections The switch port can auto detect straight or crossover cable when you link switch with other Ethernet device. For the RJ-45 connector should use correct UTP or STP cable, 10/100Mbps port use 2 pairs twisted cable and Gigabit 1000T port use 4 pairs twisted cable.

  • Page 123: Diagnosing Led Indicators

    path loops. Between any two ends nodes, there should be only one active cabling path at any time. Data path loops will cause broadcast storms that will severely impact your network performance. Diagnosing LED Indicators The Switch can be easily monitored through panel indicators to assist in identifying problems, which describes common problems you may encounter and where you can find possible solutions.

  • Page 124: Technical Specification

    7. Technical Specification This section provides the specifications of the TEG-S3000i chassis switch, and the following table lists these specifications. Standard Switch architecture Back plane LED Indicators IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX/100BASE-FX IEEE802.3z Gigabit SX/LX IEE802.3ab Gigabit 1000T IEEE802.3x Flow Control and Back pressure IEEE802.3ad Port trunk with LACP...
  • Page 125 8-port 10/100TX module: RJ-45 8-port 100FX(Multi /Single Mode) module: SC Connector 2-port Gigabit SX/LX module: SC 2-port Gigabit 1000T module: RJ-45 Expansion module MAC address 8K MAC address table with Auto learning function Memory 3Mbits for packet buffer ARM-7 32 bits RISC processor Flash ROM 512Kbytes x 1 System memory...
  • Page 126 -40 ℃ ~70 ℃ , 95% RH Storage temperature FCC Class A, CE Safety UL, cUL, CE/EN60950...

  • Page 127: Limited Warranty

    Limited Warranty TRENDware warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. Wired Products – 5 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDware shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
  • Page 128 TRENDWARE SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

Table of Contents
