TRENDnet TEG-S3000i Specifications

FEATURES
• 3-Front Slot Supports Optional 10/100Mbps RJ45 or 100Base-Fiber modules.
• 1-Back Slot Supports Gigabit Copper or Fiber (SX/LX) modules
• IGMP (v1 and v2) Snooping Support for Multi-Media Application (up to 256 groups)
• Stack Management via One IP Address (up to 8 units), Easy Management by Web GUI
• Supports Port Bandwidth Control (per level 100k)
• Supports GVRP Function and Broadcast Storm Filter
• Supports Port Based VLAN, IEEE 802.1Q VLAN and IEEE 802.1v Protocol VLAN
• Supports Port Mirroring (max 25 entries) and Port Security
• Supports IEEE 802.3x Flow Control and IEEE 802.3ad Port Trunk with LACP (up to 7 groups, max 4 ports)
• Supports IEEE 802.1p Class of Service and IEEE 802.1d Spanning Tree Protocol
• Supports IEEE 802.1x User Authentication (Reject, Accept, Authorize, Disable)
• Store-and-Forward Switching Architecture with Non-Blocking Wire-Speed Performance
• Configuration via RS-232 Console Port, Telnet, SNMP and Web Browser (HTTP)
• Supports TFTP or Console Firmware Upgrade Feature
• 19" Rack Mount Design (kit included)
• 5-Year Warranty
Optional
TEG-S3M8TX: 8-Port 10/100Mbps Auto-MDIX RJ45 Port Module
Modules
TEG-S3M8FX: 8-Port 100Base-FX SC Type Multi-Mode Fiber Port Module
TEG-S3M8S15: 8-Port 100Base-FX SC Type Single-Mode Fiber Port Module (15km)
TEG-S3M2CG: 2-Port 10/100/1000Mbps Auto-MDIX RJ45 Port Module
TEG-S3M2MG: 2-Port 1000Base Mini-GBIC Slot (SX/LX) Module
TEG-S3M11CF: 1-Port Copper & 1-Port SX Fiber SC Type Multi-Mode Gigabit Port Module
4-Slot Gigabit Layer 2 Managed Chassis
TEG-S3000i
The 4-Slot Gigabit Layer 2 Managed Chassis offers a cost-effective
solution for an enterprise backbone network. With 3 line card slots
and a wide range of hot-swappable modules, the switch provides an
easy scalable expansion as your needs grow. Features include port
trunking, load balancing, SNMP, IGMP, VLAN, Virtual Cable testing,
and other network management features.
TEG-S3000i
rev:01.09.2007
