Summary of Contents for TRENDnet TEG-S3000i
- Page 1 Quick Installation Guide TEG-S3000i...
-
Page 2: Table Of Contents
Table of Contents English ... 1. Before You Start 2. Chassis Modules ... 3. How to Connect ... 4. Using the Chassis ... Troubleshooting ... Version: 11.09.05... -
Page 3: English
2. TCP/IP protocol installed in all workstations 3. A web browser such as Internet Explorer or Netscape Navigator 4. RJ-45 Network Patch Cable to connect your workstations to the TEG-S3000i Back Panel Optional Modules (Gigabit Slot) 3-Slot Gigabit Layer 2... -
Page 4: Chassis Modules
2. Chassis Modules TRENDnet offers an exclusive line of modules for flexible and scalable configuration. Any of our modules below can easily be integrated into your current network topology. TEG-S3M8TX 8-Port 10/100Mbps RJ-45 Module TEG-S3M8FX 8-Port 100Base-FX SC Type Multi-Mode Fiber Module... -
Page 5: How To Connect
3. How to Connect In this example, the TEG-S3M8TX is used. Please use applicable cables (i.e. fiber or copper) to connect the TEG-S3000i to your main network. 2. Slowly slide the module in and push the module all the way to end of the chassis. After locking the module in place, tighten the thumb screws. -
Page 6: Using The Chassis
4. Using the Chassis 1. Go to Start ? Settings ? Control Panel. 2. Double-Click the Network Connection Icon. 3. Right-Click Local Area Connection, and select Properties. English... - Page 7 4. Click the General tab, select Internet Protocol(TCP/IP), and click Properties. Change the IP address to 192.168.16.222 and click OK to apply the settings. 5. Open your web browser, type http://192.168.16.1, and press Enter. 6. User Name: root Password: root 7.
-
Page 8: Troubleshooting
Port. Once you reach the command line interface, perform a factory reset and try again. I performed a factory reset on the TEG-S3000i, but I still cannot access the web configuration page. What should I do? If you are configuring more than one TEG-S3000i, then it is possible that you are experiencing IP conflict between these two switches. - Page 9 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
- Page 10 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S...
- Page 11 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 3135 Kashiwa Street Torrance, CA 90505 Copyright ©2006. All Rights Reserved. TRENDnet.
