USING THE SIFTER+SCALE ATTACHMENT

ASSEMBLING THE SIFTER+SCALE ATTACHMENT

1
TIP: Aligning the handle tab on the chute with one of the notches as you lower the swivel
chute into the sifter housing will help you to line up the marks.
2
3
4

WEIGHING AND SIFTING INGREDIENTS

lb
1
W11221346A_01_EN.indd 11
To install the swivel chute: Lower the swivel chute
into the sifter housing at an angle, aligning the marks
on the swivel chute with the marks above the notches
on the inside of the sifter housing. Properly installed,
swivel chute will be seated securely in the sifter
housing and will rotate easily.
To install the sifter assembly: Lower the sifter into the
sifter housing at an angle so that the drive shaft can
be inserted into the sifter housing. Once the shaft is
inserted all the way, press down on the sifter, opposite
of the shaft, to click it into place.
To install the scale: Place the scale on top of the sifter
housing with the digital scale display facing away from
the Stand Mixer, and slightly left of centre. Twist the
scale counterclockwise until it locks into place.
To install the ingredient hopper: Align the ingredient
valve with the corresponding notch on the scale, and
lower the hopper onto the scale until fully seated.
oz
g
Press
lb/oz/g
display reads 0.
USING THE SIFTER+SCALE ATTACHMENT | 11
(On/off), then press
(Tare) until the
2/6/2019 1:31:21 PM
