Autostart AS-1795 Quick Installation Manual

Flashes
Doors locked, starter kill armed.
Run time has expired.
1 button pressed.
TRUNK
Start signal received by the module.
Cold weather mode cancelled.
Remote start attempt cancelled by remote.
Doors unlocked, starter kill disarmed.
2 Exiting ignition valet
Exiting remote valet
Power-up reset
Entering cold weather mode.
Entering ignition valet.
3
Entering remote valet.
Entering extended run time.
3 slow flashes... ...after a failed start attempt
+12 V detected on the brake input wire either while cranking or during run time.
4
Entering multi-speed tach programming.
5 Slow
Start attempt failed because no tach signal has been programmed.
5 Fast Tach signal programmed.
6 A remote start was attempted while a tach-before-crank signal was detected before cranking.
8 Unit reset see "Resetting the Module" (p.Error! Bookmark not defined.)
10 A ground (-) signal was detected on the hood pin input wire.
1 pause
1 pause
5 flashes
[During the Transmitter has been programmed.
transmitter
programming
procedure]
There was a remote start attempt while the vehicle was in valet mode.
1 – pause – 2
Failed start: vehicle's low battery voltage.
ON SOLID for 3 ...followed by 1 flash
seconds....
...followed by 3 flashes
ON continuously
Idle mode: Idle mode is engaged
Run time: The vehicle has been remote started and is in run time.
While the brake
ON continuously pedal is Confirms that cold weather mode is engaged
pressed.
The hood has been opened and a ground (-) signal has been detected on the hood pin input
ON 2 seconds
wire.
ON 4 seconds
Locking or unlocking a door (with Door pulses configured to 4 sec.)
ON 20 seconds The hood pin has been flashed and you are now in the programming centre.
Constant flashes
Panic mode was triggered.
up to 25 sec.
P. 8
Description
The module did not detect a tach signal.
Exiting cold weather mode
Entering cold weather mode
Installation Guide
THE INSTALLER ...
Press and hold the hood pin for 4 seconds.
Release the hood pin.
While the parking lights are on, press down the hood pin once more
and release the hood pin immediately, before the parking lights turn off.
You now have 20 seconds to select one of the sub-menus
1. Flash the hood pin (see above) -- the parking lights will stay on for up to 20 seconds.
2. Before the lights go out, turn the ignition key to the
IGNITION ON
3. Press and hold the button and keep it down until the parking lights flash 5 times quickly.
LOCK
4. The transmitter has been stored in memory.
5. To exit: close the hood.
To program a transmitter on the second vehicle for multi-car operation, you must press the
or ) in step 3 of the transmitter programming procedure:
UNLOCK
1. Flash the hood pin switch (see on page 1) the parking lights will stay on for up to 20 seconds.
2. Before the lights go out, press and hold the brake pedal and then press one of the following buttons:
.................................................. to access mode 1;
LOCK
.......................................... to access mode 2 or;
UNLOCK
................................................ to access mode 3.
TRUNK
3. The parking lights will flash and the horn will honk (if programmed) once, twice or three times to confirm entry into a mode.
4. Release the brake pedal.
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of the product, be that either
damage to the vehicle itself or to the unit. This unit must be installed by a certified technician using all safety devices supplied. Please
note that this guide has been written for properly trained Autostart technicians: a certain level of skills and knowledge is therefore
assumed. Please review the installation guide carefully before beginning any work.
This Remote Car Starter is designed for vehicles with a manual Transmission only. Before installing the Unit, test that the OEM Door
Switch contacts of the vehicle work well, and that the Parking Brake system operates properly.
DOC.1.02 – January 9, 2007
THE MODULE ...
Parking Lights "ON"
"ON" for 20 seconds
( ) position and immediately to the position.
RUN OFF
button (instead of
TRUNK
DL Lp Manufactured in Canada by Autostart
LOCK
