Seaside Casual MAD 271 Assembly Instructions

MAD Tables
(271 40" x 85" Dining)
(272 40" x 85" Balcony)
(273 40" x 85" Bar)
(274 40" Dining)
(275 40" Balcony)
(276 40" Bar)
(277 33" Dining)
(278 33" Balcony)
(279 33" Bar)
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
Tools Required:
Table Top Assembly
4mm Allen Wrench
Actual Size
Part Code: 4MMALLEN
Part Code: 316-1/4-10-80HL
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
Rubber Mallet
Leg Assembly
x 1
x 1
80mm Hex Lag
Actual Size
271, 272, 273, 275, 276, 278, 279
x 2
5/8" Bung
x 8
274, 277
x 16
275, 276, 278, 279
x 32
271, 272, 273
Part Code: 316-8X1-3/4PFDS
x 8
274, 277
x 16
275, 276, 278, 279
x 32
Part Code:
271, 272, 273
Leg Stretchers
274, 277
Cross Stretchers
271, 272, 273
Angle Braces
271, 272, 273
1-3/4" Phillips Head Screw
Actual Size
271, 272, 273
3/4" Phillips Pan Head Screw
Actual Size
316-8X3/4PPDS
Part Code: 316-8X3/4PTS
x 4
x 2
x 4
x 2
x 8
x 12
Page 1
