Metra Electronics 99-5830B Installation Instructions Manual

Installation instructions for part 99-5830B
Ford F-150 2013-up
KIT FEATURES
• ISO DIN radio provision with pocket
• Double DIN radio provision
• Painted Matte Black
• Integrated button and LCD climate control panel
• Integrated hazard button and passenger airbag light
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8" Phillips screws for pocket
• E) (4) #8 x 3/8" Phillips screws for OE display to housing
A B
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • AX-ADBOX1 Interface • AX-ADBOX2 Interface • AX-ADFD02 Harness
Antenna Adapter: • 40-EU10 Multi-App Antenna Adapter
METRA. The World's best kits.
APPLICATIONS
With factory 4.2 inch LCD screen
99-5830B
C
®
D E
metraonline.com
U.S. PATENT # D727,889
Table of Contents
Dash Disassembly
– Ford F-150 2013-up ............................................ 2
Kit Assembly
– ISO DIN radio provision with pocket ...................... 3
– Double DIN radio provision ................................... 3
– Color adjustment .................................................. 4
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket Wrench • Torx screwdrivers
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
