Metra Electronics 95-8910S Installation Instructions

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8" Phillips screws • E) (4) Panel clips

Metra. The World's Best Kits.

Subaru Legacy/Outback

Visit

MetraOnline.com

for more detailed information about the product and up-to-date vehicle

specific applications

KIT FEATURES

• ISO DDIN radio provision

• Painted silver to match the factory finish

• Includes a pocket to replace the factory radio controls

MetraOnline.com

2010-2012

(with NAV)

95-8910S

I N S TA L L AT I O N I N S T R U C T I O N S

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Assembly ..........................................................3

WIRING & ANTENNA CONNECTIONS (sold separately)

Wiring Harness: 70-7553†

Antenna Adapter: 40-SB10-18

† Reference note in Kit Assembly

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

Attention!

Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

REV. 11/27/18 INST95-8910S

Table of Contents

Need help?

Do you have a question about the 95-8910S and is the answer not in the manual?

Page 1 When testing the aftermarket equipment, ensure that all factory equipment is connected before cycling the key to ignition. Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 11/27/18 INST95-8910S...
Page 2 DASH DISASSEMBLY 1. Unclip and remove the a/c vent trim panel surrounding the radio. (Figure A) 2. Remove (6) Phillips screws securing the radio/display. Slide the radio/display out, then unplug and remove the radio/display. Note: The antenna cable is connected down lower by the floorboard.
Page 3 KIT ASSEMBLY 1. Secure the radio brackets to the radio 4. Secure the radio assembly to the dash using the screws supplied with the using the factory screws. radio. (Figure A) 5. Attach the (4) panel clips provided onto 2. Secure the pocket to the bottom portion the radio trim panel, then clip the radio of the radio brackets using the (4) #8 x trim panel onto the radio assembly.
Page 4 Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 11/27/18 INST95-8910S...
