Acaia Lunar
User Manual
FW 2.6.005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lunar and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for acaia Lunar

Summary of Contents for acaia Lunar

  • Page 1 Acaia Lunar User Manual FW 2.6.005...

  • Page 2: Table Of Contents

    Contents In the Box Introduction Scale overview Getting Started Placement Power on/off Tare weight Switch mode Product Care Information Battery charge Calibration Mode Introduction Mode 1 - Weighing Mode Mode 2 - Dual Display Mode Mode 3 - Timer Starts with Flow Mode ( Mode 4 - Auto Tare Timer Starts with Flow Mode ( Mode 5 - Auto-Tare Auto-Start Timer Mode ( Mode 6 - Auto-Tare Mode (...

  • Page 3: In The Box

    In the Box Introduction Thank you for choosing our scale. The Acaia Lunar is designed and manufactured to the most rigorous standard to give you the best coffee brewing experience. Start by checking that your Acaia Lunar box contains all the parts listed below:...

  • Page 4: Getting Started

    Getting Started Placement Select a work place that is stable, vibration-free and, if possible, a horizontal location for the weighing platform. Power on/off [Press] to turn on the scale. [Double tap] to turn off the scale. Tare weight [Short press] to tare/zero the weight.

  • Page 5: Product Care Information

    • Battery percentage can be viewed via the Acaia apps. * Note: Using a “fast-charging” charging block or charging hub (a charging block/hub delivering over 5v at 1A) could damage your Acaia scale’s circuit board. Calibration Turn on scale...

  • Page 6: Mode Introduction

    Mode Introduction Mode 1 - Weighing Mode In the Weighing Mode, the scale will only display weight, in either grams or ounces. • There are two different weighing units in Weighing Mode: gram and ounce. A dot will appear in the upper right of the LED display and the scale will read 0.000 when weighing in ounces.

  • Page 7: Mode 3 - Timer Starts With Flow Mode

    Mode 3 - Timer Starts with Flow Mode ( ) - Droplet When the scale detects the flow of espresso, the timer starts. The timer will stop when the flow stops. *Please note: The flow detection mode is designed to detect the slow trickle of a shot of espresso.

  • Page 8: Mode 4 - Auto Tare Timer Starts With Flow Mode

    Mode 4 - Auto Tare Timer Starts with Flow Mode ( Droplet and Square This mode is designed for baristas who would like to measure the time of the shot starting from the first few drops of espresso. When a stable weight is detected, the scale will perform the auto-tare operation.

  • Page 9: Mode 5 - Auto-Tare Auto-Start Timer Mode

    Mode 5 - Auto-Tare Auto-Start Timer Mode ( Triangle and Square This mode is for baristas to measure the total time of a shot including the pre-infusion time. After a stable weight such as a cup is placed on the weighing pan, the scale performs auto-tare and starts the timer.

  • Page 10: Mode 6 - Auto-Tare Mode

    Mode 6 - Auto-Tare Mode ( ) - Square In this mode, the scale will only perform auto-tare without automatically starting the timer. Put the cup on the scale and auto-tare will be performed. Pull the shot of espresso as usual. When the cup is removed from the scale, the display flashes the final beverage weight and also shows the tare weight of the cup.
  • Page 11 Note: 1. In all three Auto Start Modes (Timer Starts With Flow Mode, Auto-Tare Timer Starts With Flow Mode and Auto-Tare Auto-Start Timer Mode), the timer will stop when the espresso flow stops. 2. In all Auto Start Modes, if you do not operate the scale for 30 seconds, it will reset timer and perform tare operation.

  • Page 12: Configuration

    Configuration Enter settings 1. Press and hold Power button while the LED display shows [ :ACAIA ] and then changes to [ SEt ]. 2. Tap T button to enter Settings. The first setting is [ SLEEP ]. 3. Please refer to the following table for key operations...
  • Page 13 2. When Zero Range is set to 2, the range for zero-setting will be 2% of the capacity, i.e., +/- 40 g for Acaia Lunar. By pressing the tare button, any weight within +/- 40 g is zeroed out by zero opera- tion while any weight that lies outside the range is tared out by tare operation.
  • Page 14 1. OFF: Bluetooth is disabled. The scale does not allow any Bluetooth connection. 2. ON: Bluetooth is enabled. The scale allows Bluetooth connection. The user may connect the scale with Acaia apps. Battery Saving [ bAttSAvE ] 1. Save up to 20% of your battery by dimming the display after some time. It will return to its origi- nal brightness when the scale detects objects on it.
  • Page 15 Auto-Start Sensitivity [ SEnSE ] 1. Minimum weight is decreased for more sensitivity. This is ideal for slower espresso shots in the droplet icon modes. Stability depends on environmental noise. The previous firmware started the timer at ~0.6 g into an espresso shot. 2.

  • Page 16: Appendix

    Appendix Buttons Function Example Turn on Press and hold for 0.5 seconds to turn on Power the scale. Button Turn off Double-tap to turn off the scale. Switch Mode While the scale is turned on, press and hold for one second to switch modes. Start/Stop/Reset Timer Tap to start/stop/reset timer.

  • Page 17: Led Indicators

    LED Indicators Ounce Indicator Battery Charge Timer Starts with Flow Tare Operation Timer Starts with Tare Bluetooth Connected Auto-tare Operation Battery Charge/Charge Error The orange indicator on the upper left turns on when the battery is charging and turns off when the battery is fully charged.

  • Page 18: Error Codes

    Access Code Error, unrecognized access code. EEPROM error, unable to access memory. Please contact Acaia support. AD error, unable to access weighing signal. Please contact Acaia support. Unable to find acceptable starting Zero point, most likely due to loadcell damage caused by excessive force or drop. Please contact Acaia support.

  • Page 19: Specifications

    Aluminum, Acrylic Material Bluetooth 4.0 Connectivity 2 Years Warranty Acaia Lunar Coffee Scale (Black / Silver) x 1 Inside the Package Heat Resistant Pad (Black) x 1 Micro USB Charging Cable x 1 Acaia Calibration Weight 100 g x 1...
  • Page 20 This user manual is protected by copyright. All rights reserved. No part of this manual may be reproduced, processed, duplicated or published in any form by photocopying, microfilming, reprinting or any other method, in particular electronic means, without the written consent of Acaia. © Acaia, California, 2020.
