Address Data 7 6 5 4 3 2 1 0
098h A1h M MS
09Ah 01h R DI PI AI SI HV LV NV
09Ch 55h X Mantissa Exponent
09Eh 08h Length in 256 byte units (LSB)
0A0h 00h Length in 256 byte units (MSB)
0A2h 20h X R P RO A
0A4h 1Bh CISTPL_CFTABLE_ENTRY
0A6h 06h CISTPL_LINK
0A8h 00h I
0AAh 01h M MS
0ACh 21h R DI PI AI SI HV LV NV
0AEh B5h X Mantissa Exponent
0B0h 1Eh X Extension
0B2h 4Dh X Mantissa Exponent
Transcend Information Inc.
0
0
0
IR IO T Power
T
D Configuration Index
IR IO T Power
Description of Contents
M=1: misc info present
MS=1: 2 byte memory length
IR=0: no interrupt is used
IO=0: no I/O space is used
T=0: no timing info specified
Power=1: VCC info, no VPP
DI: no power-down current
PI:no peak current info
AI: no average current info
SI: no static current info
HV:no max voltage info
LV:no min voltage info
NV=1: nominal voltage info
Nominal voltage 5.0V
Length of memory space is 2
Kbyte
X=0: no more misc fields
P=1: power-down supported
RO=0:read/write media
A=0: audio not supported
T=0: max twins is 0
Configuration tuple
Link length is 6 bytes
Memory mapped configuration,
index=0
Power=1: VCC info, no VPP
PI=1: peak current info
NV=1: nominal voltage info
X=1: extension byte present
Nominal voltage 3.30V
Peak current 45 mA
76
80X CompactFlash Card
CIS function
Feature Selection
Byte TPCE_FS
Power Description
Structure Parameter
Selection Byte
TPCE_PD
Memory space
descr. TPCE_MS
Miscellaneous
features TPCE_MI
Tuple code
Link to next tuple
TPCE_INDX
TPCE_FS
TPCE_PD
