Transcend CF 80X TS32M~1GCF80 Datasheet page 78

T S 3 2 M ~ 1 G C F 8
T S 3 2 M ~ 1 G C F 8
T S 3 2 M ~ 1 G C F 8
Address Data 7 6 5 4 3 2 1 0
0C4h F0h S P
0C6h FFh IRQ7..0
0C8h FFh IRQ15..8
0CAh 20h X
0CCh 1Bh CISTPL_CFTABLE_ENTRY
0CEh 06h CISTPL_LINK
0D0h 01h I D
0D2h 01h M MS IR IO T
0D4h 21h R DI PI AI SI HV LV NV
0D6h B5h X Mantissa Exponent
0D8h 1Eh X Extension
0DAh 4Dh X Mantissa Exponent
0DCh 1Bh CISTPL_CFTABLE_ENTRY
0DEh 0Fh CISTPL_LINK
0E0h C2h I D
Transcend Information Inc.
0
0
0
L M V B I
R P RO A T
Configuration Index
Power
Configuration Index
Description of Contents
N S=1: interrupt sharing logic
P=1: pulse mode supported
L=1: level mode supported
M=1: masks V..N present
V=0: no vendor unique IRQ
B=0: no bus error IRQ
I=0: no I/O check IRQ
N=0: no NMI
Interrupt signal may be
Assigned to any host IRQ
X=0: no more misc fields
P=1: power-down supported
RO=0:read/write media
A=0: audio not supported
T=0: max twins is 0
Configuration tuple
Link length is 6 bytes
I/O mapped, index=1
Power=1: VCC info, no VPP
PI=1: peak current info
NV=1: nominal voltage info
X=1: extension byte present
Nominal voltage 3.30V
Peak current 45 mA
Configuration tuple
Link length is 15 bytes
I/O mapped, index=2
I =1: Interface byte follows
D=1: Default entry
78
80X CompactFlash Card
CIS function
TPCE_IR
TPCE_MI
Tuple code
Link to next tuple
TPCE_INDX
TPCE_FS
TPCE_PD
Tuple code
Link to next tuple
TPCE_INDX
V 1 . 1
