Transcend CF 80X TS32M~1GCF80 Datasheet page 75

T S 3 2 M ~ 1 G C F 8
T S 3 2 M ~ 1 G C F 8
T S 3 2 M ~ 1 G C F 8
Address Data 7 6 5 4 3 2 1 0
07Eh 0Ch Reserved
080h 0Fh R
082h 1Ah CISTPL_CONFIG
084h 05h TPL_LINK
086h 01h RFS RMS RAS
088h 03h TPCC_LAST
08Ah 00h TPCC_RADR (LSB)
08Ch 02h TPCC_RADR (MSB)
08Eh 0Fh TPCC_RMSK
090h 1Bh CISTPL_CFTABLE_ENTRY
092h 08h CISTPL_LINK
094h C0h I
096h C0h W R
Transcend Information Inc.
0
0
0
D U S V
I E N P
D Configuration Index
P B Interface type
Description of Contents
D=0: single drive on card
U=1: unique serial number
S=1: silicon device
V=00: no VPP required
I=0: twin IOIS16# unspecified
E=0: index bit not emulated
N=0: I/O includes 0x3F7
P=F(1111):low power, sleep, standby, idle
supported
Configuration Tuple
Link length is 5 bytes
RFS: reserved
RMS: 1 byte register mask
RAS: 2 bytes base address
Last configuration entry is 03H
Configuration registers are
Located at 0200H
Configuration registers 0 to 3
are present
Configuration tuple
Link length is 8 bytes
Memory mapped configuration,
index=0
I=1: Interface byte follows
D=1: Default entry
W=1: wait required
R=1: ready/busy active
P=0: WP not used
B=0: BVD1, BVD2 not used
Type=0: Memory interface
75
80X CompactFlash Card
CIS function
TPLFE_TYPE
TPLFE_TYPE
Tuple code
Link to next tuple
Size of fields
TPCC_SZ
Last entry index
Configuration
Register location
Configuration register
present mask
Tuple code
Link to next tuple
Configuration Table
Index Byte
TPCE_INDX
Interface
Description
TPCE_IF
V 1 . 1
