INSTALLATION MANUAL
IEC Version
THE
Screw
Clamp
MODULE
TSM-DEG6HC.27(II)
TSM-DEG15HC.27(II)
TSM-DEG6HC.20(II)
TSM-DEG15HC.20(II)
TSM-DEG6MC.27(II)
TSM-DEG15MC.27(II)
TSM-DEG6MC.20(II)
TSM-DEG15MC.20(II)
TSM-NEG6MC.20(II)
TSM-NEG6MC.27(II)
TSM-NEG15MC.20(II)
TSM-NEG15MC.27(II)
TSM-DEG6HC.07(II)
TSM-DEG15HC.07(II)
TSM-DEG6HC(II)
TSM-DEG15HC(II)
TSM-DEG6MC.07(II)
TSM-DEG15MC.07(II)
TSM-DEG6MC(II)
TSM-DEG15MC(II)
TSM-NEG6MC(II)
TSM-NEG6MC(II)
TSM-NEG15MC(II)
TSM-NEG15MC.07(II)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Duomax Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trina Solar Duomax Series

Summary of Contents for Trina Solar Duomax Series

  • Page 1 INSTALLATION MANUAL IEC Version MODULE TSM-DEG6HC.27(II) TSM-DEG15HC.27(II) TSM-DEG6HC.20(II) TSM-DEG15HC.20(II) TSM-DEG6MC.27(II) TSM-DEG15MC.27(II) Screw TSM-DEG6MC.20(II) TSM-DEG15MC.20(II) TSM-NEG6MC.20(II) TSM-NEG6MC.27(II) TSM-NEG15MC.20(II) TSM-NEG15MC.27(II) TSM-DEG6HC.07(II) TSM-DEG15HC.07(II) TSM-DEG6HC(II) TSM-DEG15HC(II) TSM-DEG6MC.07(II) TSM-DEG15MC.07(II) Clamp TSM-DEG6MC(II) TSM-DEG15MC(II) TSM-NEG6MC(II) TSM-NEG6MC(II) TSM-NEG15MC(II) TSM-NEG15MC.07(II)

  • Page 2: Table Of Contents

    CONTENT DISCLAIMER OF LIABILITY ..........................- 3 - SAFETY PRECAUTIONS ............................. - 3 - UNPACKING AND STORAGE ..........................- 3 - PRODUCT IDENTIFICATION ........................... - 4 - ENVIRONMENTAL CONDITIONS AND SITE SELECTION ................ - 4 - CLIMATE CONDITION .......................... - 4 - SITE SELECTION ............................

  • Page 3: Disclaimer Of Liability

    2. Trina Solar requires that every DUOMAX series PV module string should be fused prior to be connected with other strings. For the maximum fuse rate, please refer to the detailed SPEC in the last page.

  • Page 4: Product Identification

    2400Pa (245 Kg/m²) Max from the front side 2400Pa from the rear. * Mechanical load bearing specifications of the module is based on Trina Solar mounting methods. A professional system installer must be responsible for the mechanical load calculations based on the specific system design.
  • Page 5 These components are only for use in the installation example in this section Item Name Picture Size （mm） Material Length and width Clamp 1 Aluminum alloy 6063 150*35.8 Clamp Block Length and width Aluminum alloy 6063 150*35.8 Length and width Clamp 2 Aluminum alloy 6063 150*50.9...

  • Page 6: Mounting Methods

    Grounding screw GB845-85-ST4.2*13-F- Grounding H+ , #5 star washer, Components 5#flat washer, 5# ground wire Frame can Frame protect the DG Material: modules and Aluminum 6063 easily for installation. Racking Material: Q235B (Supply By EPC or Racking suppliers, Rails, support the suggested specification: PV modules.
  • Page 7 Remove the bottom connector parts. Connector parts: M8 Nut, spring washer and washer. STEP 2: Install the clamp Put the clamp bolts into the installation holes, and then tighten the nuts. Repeat, put all clamp on the rail, keep the distance between two clamps can install the PV modules.
  • Page 8 The following examples illustrate how to evaluate Trina Clamp compatibility with various racking systems. Please find the dimension below to evaluate the racking system, contact Trina Solar if you want to change the size of the screw. Please note that all dimensions below are in mm units.
  • Page 9  available including T-shape nuts. *NOTE: Please consult with a Trina Solar engineer before installing with the frameless clamps PV modules can be mounted to the substructure using either corrosion-proof M8 bolts placed through the mounting holes on the rear of the module or specially designed module clamps.
  • Page 10 5) HEX Stainless Nut B. Mounting with Clamps • Trina Solar has tested its modules with a number of clamps from different manufacturers and recommends the use of clamps which have an EPDM or similar insulating washer, fixing bolt of at least M8.
  • Page 11 6.2.1.2 CLAMP OPTIONS Clamps should be connected to the module between 300 and 400 mm from the edge of the module. This distance is from the module edge to the middle of the clamp. *NOTE: Need two support rails below the PV module to make sure the Mechanical load. 60Pcs MODULES (frameless) Mechanical Safety...
  • Page 12 72Pcs MODULES (frameless) Mechanical Safety Load Length Of The Clamp Mounting Direction Factor Pressure +1600 Pa 150mm /-1600 Pa （Half-cut Module） *NOTE: The above-described distance is from the module edge to the middle of the clamp. *NOTE: Need two support rails below the PV module to make sure the mechanical load.
  • Page 13 1. Lift up the modules 2. Insert the bolt into the holes 1. Lift up the module; ensure the bolt over the racking. 2. Aim the bolt to racking. 3. Insert the bolt into the holes； DOWN Step 3: Push the modules to the right position Push the PV modules to the right position, so that the bottom two screws are in the middle of the...
  • Page 14 6.2.2.2 TRINA FRAME COMPATIBILITY WITH VARIOUS RACKING SYSTEMS. The following examples illustrate how to evaluate Trina Frame compatibility with various racking systems. Please pay attention to the size from component battery to the edge of the frame, and the bracket or pad ...

  • Page 15: Screw

    6.2.2.3 SCREW OPTIONS CLAMP OPTIONS 60Pcs MODULES (frame) Mechanical Safety Load Length Of The Clamp Mounting Direction Factor Pressure +1600 Pa / 150mm -1600 Pa （Half-cut Module） *NOTE: The above-described distance is from the module edge to the middle of the clamp. *NOTE: Need two support rails below the PV module to make sure the Mechanical load.
  • Page 16 72Pcs MODULES (frame) Mechanical Safety Load Length Of The Clamp Mounting Direction Factor Pressure +1600 Pa 150mm /-1600 Pa （Half-cut Module） *NOTE: The above-described distance is from the module edge to the middle of the clamp. *NOTE: Need two support rails below the PV module to make sure the mechanical load.
  • Page 17 CLAMP OPTIONS 60Pcs MODULES (frame) Mechanical Safety Mounting Direction Load Pressure Factor Fixed by bolt +1600 Pa / 1/2 module length -1600 Pa （Cut-half Module） 72Pcs MODULES (frame) Mechanical Safety Load Mounting Direction Factor Pressure Date: 2019.5.6 Doc No: PS-M-0691 Ver. A Page - 17 - of 21...

  • Page 18: Grounding

    Codes. The grounding conductor must then make a connection to earth using a suitable earth ground electrode. • Trina Solar modules can be installed with the use of third party listed grounding devices for grounding the metallic frames of PV modules. The devices have to be installed in accordance with the grounding device manufacturer’s specified instructions.

  • Page 19: Install Effect Chart

    6.4 INSTALL EFFECT CHART The install effect chart is as follows. Please consult with Trina Solar engineers to confirm whether the rails match Trina clamp/frame or not. And confirm there are no shelter on the back of the modules. MODULE WIRING Each module has two 4mm diameter type standard 90°C sunlight resistant output cables each terminated with plug &...

  • Page 20: Maintenance And Care

    Trina Solar is a member of the European PV Cycle Association. Through the pre-financed PV Cycle program, Trina Solar PV modules will be taken back and treated in an environmentally sustainable manner.*Applicable only to participating countries within the Europe Union.
