INSTALLATION MANUAL
For crystalline solar photovoltaic modules
"According with IEC61215 edition 2 & IEC61730 standards"
CHANGZHOU TRINA SOLAR ENERGY COMPANY LIMITED
Address: No.2 Trina Road, Trina PV Park, New District, Changzhou, Jiangsu, P.R. China
Website: http://www.trinasolar.com (NYSE:TSL)
E-mail：sales@trinasolar.com
Tel: 0086-519-88227799
1/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trina Solar TSM Series
Summary of Contents for Trina Solar TSM Series
- Page 1 INSTALLATION MANUAL For crystalline solar photovoltaic modules “According with IEC61215 edition 2 & IEC61730 standards” CHANGZHOU TRINA SOLAR ENERGY COMPANY LIMITED Address: No.2 Trina Road, Trina PV Park, New District, Changzhou, Jiangsu, P.R. China Website: http://www.trinasolar.com (NYSE:TSL) E-mail：sales@trinasolar.com Tel: 0086-519-88227799...
- Page 2 Solar does not assume responsibility for loss, damage, injury or expense resulting from improper installation, handling, use or maintenance. Trina Solar assumes no responsibility for any infringement of patents or other rights of third parties that may result from use of the module. No license is granted by implication or under any patent or patent rights.
-
Page 3: Tilt Angle
Trina Solar SPV modules produce the most power when they are pointed directly at the sun. For installations where the SPV modules are attached to a permanent structure, the SPV modules should be tilted for optimum winter performance. As a rule, if the system power production is adequate in winter, it will be satisfactory during the rest of the year. - Page 4 CHANGZHOU TRINA SOLAR ENERGY CO.,LTD INSTALLATION MANUAL FOR CRYSTALLINE SOLAR PHOTOVOLTAIC MODULES Rev.G 10. Mechanical drawing of SPV module Frame cross section (long side) Frame cross section (short side) Figure2. SPV module Mechanical drawing* SPV module Cell type Cell Dimensions...
- Page 5 Trina Solar SPV modules can be mounted using the following methods: （Note: All installation methods herein are only for reference, and Trina solar will not provide related BOS components, the system installer or trained professional personnel must be responsible for the PV system’s design, installation, and mechanical load calculation and security of the system.）...
- Page 6 CHANGZHOU TRINA SOLAR ENERGY CO.,LTD INSTALLATION MANUAL FOR CRYSTALLINE SOLAR PHOTOVOLTAIC MODULES Rev.G module type Cell type Cell quantity Dimensions Installation hole A*B*C (mm) E*F(mm) TSM-***DC01 Mono-crystalline 6*12 1581*809*40 948*754 TSM-***DC03 Mono-crystalline 1316*992*46 941*800 TSM-***DC05 Mono-crystalline 6*10 1650*992*46 990*941 TSM-***PC03...
- Page 7 CHANGZHOU TRINA SOLAR ENERGY CO.,LTD INSTALLATION MANUAL FOR CRYSTALLINE SOLAR PHOTOVOLTAIC MODULES Rev.G module type Cell type Cell Dimensions (mm) quantity TSM-***DC01 Mono-crystalline-Si 6*12 1581*809 0.5～2 2.5～3 TSM-***DC03 Mono-crystalline-Si 1316*992 0.5～2 2.5～3 TSM-***DC05 Mono-crystalline-Si 6*10 1650*992 0.5～2 2.5～3 TSM-***PC03 Multi-crystalline-Si 1316*992 0.5～2...
- Page 8 CHANGZHOU TRINA SOLAR ENERGY CO.,LTD INSTALLATION MANUAL FOR CRYSTALLINE SOLAR PHOTOVOLTAIC MODULES Rev.G Fringe modules installation Clamp Frame (short side) Middle modules installation Mounting rail M6 screw Figure5. SPV module installed at landscape orientation with Clamp fitting method * module type...
-
Page 9: Warning And Notes
SPV module, thereby minimizing module heating and array current losses. Currently, Trina Solar SPV modules are equipped with bypass diodes in the junction box. The diode type is 10SQ050（for RenHe junction box）or F1200D (for Tyco junction box 2-1394723-1& 1-1394723-8) or SL1010 (for Tyco junction box 1740699-6) or SL1515 (for Tyco junction box 1740971-1). -
Page 10: Module Wiring
CHANGZHOU TRINA SOLAR ENERGY CO.,LTD INSTALLATION MANUAL FOR CRYSTALLINE SOLAR PHOTOVOLTAIC MODULES Rev.G Artificially concentrated sunlight should not be shown on the SPV module. The electrical characteristics are indicated value of Pmax under standard test conditions (Irradiance of 1000W/m , AM 1.5 spectrum, and cell temperature of 25°C). -
Page 11: Specifications
CHANGZHOU TRINA SOLAR ENERGY CO.,LTD INSTALLATION MANUAL FOR CRYSTALLINE SOLAR PHOTOVOLTAIC MODULES Rev.G 17. SPECIFICATIONS: Electrical Performance @ STC Max- Module Series Max- Max- Open- Short- Model Max- Fuse Power Power Circuit Circuit Series Power Voltage Current Voltage Current 160±3% 34.9...
