Non-metal Distance controller user manualV2.1`
The user is sure to read this manual before using the controller
●The contents of this manual is the system operating manual
●Read the manual carefully to ensure proper electrical connection
LFS-ANM-T43 Non-metal distance
controller user manualV2.1
Shenzhen Ruida Technology Co., Ltd.
RuiDa Technology Co., Ltd
Add:
1TH
FLOOR,5TH
TIANAN INDUSTRIAL ZONE,SHENZHEN
Tel:
0755--26066687
Fax:
0755--26982287
E-mail: sales@rd-acs.com
Web:
www.rd-acs.com
I
BUILDING,NANYOU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LFS-ANM-T43 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruida Technology LFS-ANM-T43

Summary of Contents for Ruida Technology LFS-ANM-T43

  • Page 1 ●The contents of this manual is the system operating manual ●Read the manual carefully to ensure proper electrical connection LFS-ANM-T43 Non-metal distance controller user manualV2.1 RuiDa Technology Co., Ltd Add: FLOOR,5TH BUILDING,NANYOU TIANAN INDUSTRIAL ZONE,SHENZHEN Tel: 0755--26066687 Fax: 0755--26982287 E-mail: sales@rd-acs.com Web: www.rd-acs.com Shenzhen Ruida Technology Co., Ltd.

  • Page 2: Copyright Declaration

    2. Ruida Technology is entitled to increase or reduce and modify the products and functions of this product stated herein as well as amend any documents attached to this product, without prior notification.
  • Page 3 Version History Version Date Describe 2.01.000 2017/03/02 LFS-ANM-T43 Non-metal distance controller 2.01.001 2017/06/13 When the height is out of range of the sensor, the tracing function is still valid if user has enabled the tracing. Shenzhen Ruida Technology Co., Ltd.

  • Page 4: Table Of Contents

    4.1 Non-metal distance controller trial operation................16 4.2 Cutting test..........................17 Chapter 5 Alarm message descriptions....................20 5.1 System error...........................20 5.2 Upper and lower limit trigger....................20 5.3 Reset error..........................20 5.4 Beyond detection range......................20 5.5 Emergency stop........................21 5.6 Multiple errors........................21 Shenzhen Ruida Technology Co., Ltd.
  • Page 5 6.1 Controller Installation dimensions:..................22 6.2 Sensor Installation dimensions:..................... 22 6.3 Laser Displacement Sensor Installation Instructions.............23 6.3.1 Laser Displacement Sensor Instructions................ 23 6.3.2 Installation diagram......................23 6.3.3 Laser displacement sensor installation procedure............24 Appendix: Usual Fault & Disposing Method.................. 25 Shenzhen Ruida Technology Co., Ltd.

  • Page 6: Chapter 1 Introduction

    Non-metal Distance controller user manualV2.1` Chapter 1 Introduction 1.1 System Introduction LFS-ANM-T43 Non-metal distance controller（hereinafter referred to as”Non-metal distance controller”） It is a non-metallic cutting automatic distance system based on laser displacement sensing technology. It can work with RDC633XM for non-metal cutting control system. The system mainly consists of the following parts：...
  • Page 7 This product is not suitable for the following occasions：  Highly reflective material  The material that absorbs infrared light at a wavelength of 650 nm  Transparent material  The slope changes dramatically occasion Shenzhen Ruida Technology Co., Ltd.

  • Page 8: Chapter 2 Function Introduction

    It use serial communication for data communication between non-metal distance controller and touch screen. RuiDa Technology has been equipped cable connection in the product accessories. The standard length of cable is 1.5 meter. The user only needs to connect according to interface.

  • Page 9: Function Introduction

     controller software version number “System time”：it can change the system time。  2.2.2 Parameters Setting It can set the parameters from “Menu” main interface. Including process parameters, height parameters, speed parameters, machine parameters etc. Shenzhen Ruida Technology Co., Ltd.
  • Page 10 It is used to set the direction of the motor rotation. Polarity Machine Acceleration It is used to set the acceleration when moving. Para Screw pitch, the parameters need to be set according Screw Pitch to the actual situation of the machine. Shenzhen Ruida Technology Co., Ltd.

  • Page 11: Parameter Management

    In this interface, user can check the details of alarm record (Including the time to trigger the alarm and the type of alarm).it can record at most 9 times the non-metal booster alarm information. You can press the "clear" button to clear the alarm Shenzhen Ruida Technology Co., Ltd.

  • Page 12: Blowing Test

    Remarks: When testing, please make sure the system is idle, otherwise it cannot be tested. 2.2.6 System Information In the main interface, press“system information” enter into the interface . Under this interface, user can set system language (Chinese and English) and to know the version of software version. Shenzhen Ruida Technology Co., Ltd.

  • Page 13: System Time

    Under this interface, user can set date and time. When entering the interface, user will get the current touch screen time. If it is not the current time, you can set it then press“enter”. Shenzhen Ruida Technology Co., Ltd.

  • Page 14: Chapter 3 Non-Metal Distance Controller Connection Description

    Non-metal Distance controller user manualV2.1` Chapter 3 Non-metal distance Controller connection description 3.1 Controller Ports Introduction System overall wiring diagram as following: Shenzhen Ruida Technology Co., Ltd.

  • Page 15: Non-Metal Distancecontroller Outside View

    The laser displacement sensor is connected to the CN1 interface of the nonmetal distance controller. The brown line is connected to the OVCC interface, the gray line is connected to the CT interface. The shield layer and the blue line are connected to the GND interface. Shenzhen Ruida Technology Co., Ltd.

  • Page 16: Cn2 Is Power Input Interface

    Can be used to trigger open cover protection, low PIN4 FocSwt General IO input level active. — PIN5 ModeSwt Function Reserved — Signal reference PIN6 ground Shenzhen Ruida Technology Co., Ltd.

  • Page 17: Cn5 External Output Interface

    Servo alarm INPUT When 0V, servo alarm invalid. PIN3( Orange ) Servo on output When 0V, servo working PIN4(Light green ) Encoder A- Encoder input PIN5( Brown ) Encoder B- Encoder input PIN6red) Encoder C- Encoder input Shenzhen Ruida Technology Co., Ltd.
  • Page 18 If connect servo motor, connecting it with relative way according servo driver model and set the servo drive parameters correctly.  The servo drive is set to position mode  Direction and pulse polarity settings  To set the number of pulses per rotation of the motor Shenzhen Ruida Technology Co., Ltd.

  • Page 19: Sensor Control Interface

    Emergency stop switch input, valid when connect to GND, and invalid when it is in air. The light turns on when press, and off when loosen Lmt- connect to normally open contact, triggered when closed, the light turns on Shenzhen Ruida Technology Co., Ltd.
  • Page 20 Servo alarm input, the light turns on when ALM working. Servo enable output status Direction signal output instructions PULSE Pulse signal output instructions System System status instruction System running instruction CRASH Reserved Reserved Shenzhen Ruida Technology Co., Ltd.

  • Page 21: Chapter 4 Trial Operation

    MetalCut, “file”—“vendor setting”—“other”， Click“Enable open cover protection” As showing in below: In the software of MetalCut, “file”—“vendor setting”—“ special” In the check follow up and check follow ,choose “using trigger”, in the height controller type, choose “common”.To check the illustration as follow: Shenzhen Ruida Technology Co., Ltd.

  • Page 22: Cutting Test

    Please view to RDC633XM motherboard and MetalCut User's Manual for details. Follow the steps as below to cutting test: Open MetalCu, on the left side of the software, use a common drawing tool to draw a simple graphic, take a rectangle as an example: Shenzhen Ruida Technology Co., Ltd.
  • Page 23 Non-metal Distance controller user manualV2.1` Set the layer parameters correctly: After set a correctly vendor parameters, user parameters and processing parameters, which can be cutting. To set the user parameters correctly: Shenzhen Ruida Technology Co., Ltd.
  • Page 24 7) Cutting When the functional tests are normal, press the "Start" button on the panel to start cutting. Shenzhen Ruida Technology Co., Ltd.

  • Page 25: Chapter 5 Alarm Message Descriptions

    5.4 Beyond detection range When the cutting head is out of the effective detection range of the sensor, it will show that the detection range is exceeded. The cutting head height can be adjusted to the appropriate Shenzhen Ruida Technology Co., Ltd.

  • Page 26: Emergency Stop

    5.6 Multiple errors When two or more errors occur simultaneously, "multiple errors" will be displayed. When multiple errors occur, you can view the detailed alarm information by clicking on the "Alarm Information" of the touch screen. Shenzhen Ruida Technology Co., Ltd.

  • Page 27: Chapter 6 Installation Instructions

    Non-metal Distance controller user manualV2.1` Chapter 6 installation instructions 6.1 Controller Installation dimensions: 6.2 Sensor Installation dimensions: Front view Side view Shenzhen Ruida Technology Co., Ltd.

  • Page 28: Laser Displacement Sensor Installation Instructions

    Therefore, the laser head of the nozzle part to try to fine and sharp, to ensure that try not to block the red light. Shenzhen Ruida Technology Co., Ltd.

  • Page 29: Laser Displacement Sensor Installation Procedure

    0, where the position of the sensor is the correct mounting position. The user can fine adjust the focus offset setting via the touch screen. Shenzhen Ruida Technology Co., Ltd.

  • Page 30: Appendix: Usual Fault & Disposing Method

    To check the touch screen screen and non-metal distance distance controller connection controller When Do connection of PGND of following,shaking Big interference of machine non-metal distance controller and serious machine shell and GND Shenzhen Ruida Technology Co., Ltd.
  • Page 31 The filter factor is set too large Reduce the filter coefficient Servo drive rigid setting is too Reduces servo rigidity large Misoperation trigger beyond the detection Alarm filter factor is too small To set suitable alarm filter range during cutting Shenzhen Ruida Technology Co., Ltd.
  • Page 32 Thank you very much for using the product from Shenzhen RuiDa Technology! All parts of this manual description, all rights reserved by Shenzhen RuiDa Technology Co., Ltd. Without our permission, any company or individual shall not reprint, copy or distribute the content related to this product manual.
