MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS
Thank you for purchasing the MADISON TRUNDLE BED.
Please read the instructions carefully to ensure safe operation of the product.
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list.
Do not destroy any of the packaging until you are certain that you have all the necessary parts
for the assembly.
CAUTION:There are small components used in the construction of this unit.These loose items should
be kept away from young children whilst assembling your unit to avoid the danger of choking hazards.
Tools Required
4mm Allen key x 1
(INCLUDED)
W1900mm×D950mm×H350mm 3ft
COLOUR: WHITE
Spanner x 1
(INCLUDED)
Batch no:WMI16394 (PO#2508)
x2
Page 1 of 9
SINGLE
1.5Hour
Set Up
Advertisement
Related Manuals for GFW MADISON TRUNDLE BED
Summary of Contents for GFW MADISON TRUNDLE BED
-
Page 1: Tools Required
MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS Thank you for purchasing the MADISON TRUNDLE BED. Please read the instructions carefully to ensure safe operation of the product. W1900mm×D950mm×H350mm 3ft SINGLE COLOUR: WHITE PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction. -
Page 2: Care Information
MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. INFORMATION This product is intended for a maximum person’s weight of 100kg per side. Do not exceed • this weight. Due to the size of this product we recommend that it is assembled in the room intended for use. - Page 3 MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS Please check the pack contents before assembling the product.If any components are missing,please contact your retailer.The fittings pack contains small items that should be kept away from small children. Batch no:WMI16394 (PO#2508) Page 3 of 9...
- Page 4 MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS Parts Description:HORIZONTAL METAL Description:METAL SUPPORT Description:End Rail RAIL LEG RAIL Qty:2PCS Qty:2PCS Qty:2PCS Dimension: 900*80*30MM Dimension: 1900*50*50MM Dimension: 955*330*60MM Description:ROLLER WHEEL Description:Stopper Description:Wooden Slat Qty:4PCS Qty:4PCS Qty:13PCS Dimension: 80*70*20MM Dimension: 40*30*20MM Dimension: 895*55*10MM Description:Single Plastic Cap...
- Page 5 MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS Fixings (to scale) Dimensions Bolt-M8x75MM Bolt-M6x15MM Flat Washer- Ø 8x16MM 8 Nut-M8x13MM (Not to scale) 4mm Allen Key Spanner CAUTION: There are many small components used in the construction of this product. Please keep these components away from young children whilst assembling this product .
- Page 6 MADISON DAY BED ASSEMBLY INSTRUCTIONS Layout Parts on Soft Surface Lay out all 4 sides on a soft surface i.e. Rug, Carpet or Packaging Carton. Batch no:WMI16394 (PO#2508) Page 6 of 9...
- Page 7 MADISON TRUNDLE BED ASSEMBLY INSTRUCTIONS...
- Page 8 Step3 Parts Required HORIZONTAL METAL RAIL x2 METAL SUPPORT LEG RAIL x2 Stopper x4 Wooden Slat x13 Single Plastic Cap x26 Batch no:WMI16394 (PO#2508) Page 8 of 9...
-
Page 9: Complete Assembly
COMPLETE ASSEMBLY Your MADISON TRUNDLE BED is now completely assembled. Periodically check to ensure that the components are in their proper position, free from damage. Also, make sure the connectors are tight and secure. Keep instructions for future reference Batch no:WMI16394 (PO#2508)
