JOURNEY QUAD
FOUR PERSON TENT
Assembly Instructions
2 Silver Tipped
Poles
1 Orange Tipped
Pole
2
4
3
1
5
20 Alloy Stakes
Lay out the footprint before
erecting the tent.
Unroll the outer tent, locate
the pole bag, separate the poles,
clip the sections together making
continuous poles. The poles are
held together by elastic.
Pole Placement
1. Insert the silver tipped
pole with silver section to
silver trim edging.
2. Insert the other silver
tipped pole with silver
section to silver trim
edging.
3. Insert the large orange
tipped pole with orange
section to orange trim
edging.
4. Insert the pole ends
into the grommets in the
corresponding webbing
straps.
5. When all the pole ends are
inserted into the grommets
take the ultralight alloy
stakes included
Journey Quad, stake down
the corners and webbing
straps with grommets. Add
additional stakes to other
stake points as required.
with the
